Section 6.2
A6060 CIRCUIT BOARD
CIRCUIT BOARD CONNECTIONS
(CONTINUED)
RECEPTACLE J4:
The A6060 circuit board mounts a 3-pin receptacle
J4. A 3-pin connector plug connects to the A6060.
This harness then connects to Bridge Rectifier. DC
Link Voltage is supplied to the circuit board for volt-
age sensing.
RECEPTACLE J5:
The A6060 circuit board mounts a 2-pin receptacle
J5. A 2-pin connector plug connects to the A6060.
This harness then connects to TIM1/TIM2. The
A6060 circuit board uses this signal for speed
sensing.
Page 6.2-2
