Crankcase Assembly - Generac Power Systems 941-2 Service Manual

MODEL
CYLINDER BORE:
DESIGN DIAMETER
VALVE TAPPET BORE:
DESIGN DIAMETER
CRANKSHAFT SLEEVE
BEARING:
DESIGN DIAMETER
*(WHERE APPLICABLE)
GOVERNOR ARM
BORE:
DESIGN DIAMETER
CAMSHAFT BEARING:
DESIGN DIAMETER
GOVERNOR ARM
DIAMETER:
DESIGN DIAMETER:
*Later model small frame GN engines have no crankshaft sleeve bearing.
MODEL
CRANKSHAFT BEARING
BORE:
DESIGN DIAMETER
CAMSHAFT BEARING
BORE:
DESIGN DIAMETER
GOVERNOR GEAR
SHAFT DIAMETER
OIL PUMP INNER ROTOR
SHAFT DIAMETER:
DESIGN DIAMETER

CRANKCASE ASSEMBLY

CRANKCASE COVER ASSEMBLY
SPECIFICATIONS & CHARTS
GV-220
2.953-2.954 inch
(75.000-75.025mm)
0.295-0.296 inch
(7.494-7.520mm)
1.104-1.106 inch
(28.044-28.099mm)
0.239-0.240 inch
(6.07-6.10mm)
1.024-1.025 inch
(26.00-26.03mm)
0.235-0.237 inch
(5.97-6.03mm)
GV-220
1.104-1.105 inch
(28.040-28.065mm)
1.299-1.300 inch
(33.00-33.03mm)
0.236-0.237 inch
(6.004-6.012mm)
0.353-0.354 inch
(8.969-8.987mm)
