5. Momentarily jump Wire #15 (located at the fuse holder) to Wire
#56 (located at the Starter Contactor). This will initiate cranking
of the engine. The generator will start, but the throttle will need
to be controlled manually. Hold the throttle at about a half load
setting.
6. Set a VOM to measure AC. Measure the AC voltage at the tim-
ing winding connector (orange and grey wires). The voltage
should be between 15 and 20 VAC.
7. If results are lower, there is a possible stator problem. Proceed
to Test 34.
TEST 34 -STATOR RESISTANCE VALUES
Refer to Part 1, Section 1.4 and 1.5 for test procedures.
AC1 to AC2 ................................................. 0.414 to 0.465 ohms
SL1 to SL2................................................... 0.414 to 0.465 ohms
#55 to #66 ................................................... 0.095 to .108 ohms
#55 to #77 ................................................... 0.095 to 0.108 ohms
TIM1 to TIM2 ............................................... 0.102 to 0.116 ohms
PS1 to PS2.................................................. 0.206 to 0.227 ohms
TEST 35 - BRIDGE RECTIFIER TEST
1. Disconnect the Red-Black-Blue-Green DC Link wires from
either the connection in the control panel or at the inverter.
Isolate the DC Link wires.
2. Turn CB1 to the OFF position.
3. Disconnect the 3-pin connector at J4 on the A6060 circuit
board.
ENGINE DC CONTROL SYSTEM / AC TROUBLESHOOTING
4. Instal paper clips in connector to use as a test point.
5. Set a VOM to the DIODE test range.
6. Attach the negative test lead of the VOM to the Red Wire and
the positive test lead to the Blue Wire.
7. The voltage measured across the Bridge Rectifier should be
approximately 1.000 VDC. Any voltage reading higher or lower
indicates a defective diode assembly. Disassemble the Bridge
Rectifier and test each diode individually.
1. Turn CB1 to the OFF position.
2. Set a VOM to measure AC Volts.
3. Connect one test lead to the bottom Grey wire (AC1) on CB1.
Connect the other test lead to the Yellow wire (AC2) located on
the Bridge Rectifier.
4. Start the generator.
5. The measured AC voltage reading should be approximately
187 VAC.
6. Connect one test lead to the bottom Orange Wire (SL1) on
CB1. Connect the other test lead to the Brown wire (SL2) locat-
ed on the Bridge Rectifier.
7. Start the generator.
8. The measured AC voltage reading should be approximately
187 VAC.
9. If a lower voltage is measured, proceed to Test 34.
TEST 36 - AC POWER WINDING TEST
AC1/AC2/SL1/SL2
Section 7.2
Page 7.2-19
