ITEM
QTY
DESCRIPTION
1
1
PLATE, DIVIDER
2
32
CRIMPTITE 10-24 x 1/2"
3
3.5'
SEAL, RUBBER EXTRUSION
4
1
BOX, WRAPPER
5
31
TAPTITE, M5-.8 x 10MM
6
2
MOUNTING RAILS
7
12
M8 LOCK WASHER
8
4
M8-1.25 x 35MM HEX HD. CAPSCR.
9
3
HHCS M5-0.8 x 40MM
11
1
WRAPPER, END PANEL
12
1
SPARK ARRESTER
17
1
DEFLECTOR, AIR OUT
18
1
ASSEMBLY, MUFFLER
19
1
HOUSING, LOWER FAN
20
1
SKIRT, CARB. BAFFLE
21
1
COVER, ROCKER COVER
22
1
SKIRT, SPARK PLUG SIDE
23
1
PAN, BELLY
24
1
FRAME
25
1
GROUND STRAP
26
1
PLATE, BASE COVER
27
1
BARBED EL 90 3/8NPT X 3/8 VS
29
5
HEX NUT, 1/4"-20
30
9
LOCK WASHER-1/4"-M6
31
1
CONTACTOR, STARTER
32
1
BOOT, CONTACTOR
33
1
SEAL, OIL FILTER HOLE
34
1
RETAINER, SEAL
35
4
FLAT WASHER-M8
36
1
REGULATOR
37
1
HOSE CLAMP #5.5
38
1
SNAP BUSHING
39
2
SPECIAL LOCK WASHER, M5
40
2
#8-32 HEX NUT
41
2
#8 LOCK WASHER
42
2
HEX HD. CAPS., M6-1.0 x 16MM-W/L-
WASHER
43
7
FLAT WASHER #10/M5
PARTS LIST FOR SHEET METAL (GASOLINE UNITS)
ITEM
QTY
DESCRIPTION
44
3
SPECIAL LOCK WASHER, M6
45
1
GROUND STRAP, UNIT
47
1
HOSE-3/8" I.D. x 11-1/2" LONG
48
1
BRACKET, MUFFLER HANGER
49
2
STREET ELBOW 45 DEG. 3/4" NPT
50
1
PIPE NIPPLE 3/4" x 2"
51
2
U BOLT W / SADDLE & 2-NUTS
53
1
STARTER CONTACTOR GROUND
WIRE
54
1
SEAL, WASHER EXHAUST PIPE
55
1
FUEL SOLENOID 12V DC
57
2
5/16" FLAT WASHER
58
1
BRACKET L/P
59
2
CAPSCR., HEX HD.-1/4"-20 x 1/2"
60
1
LP HOOK-UP FITTING
61
2
CUSTOMER MOUNTING BRACKET
62
4
VIBRATION MOUNT
63
2
EARTHING STRAP
64
8
HEX NUT-M8
65
3
VIBRATION MOUNT
66
1
COVER, IGNITION BRACKET
67
1
1/4"-20 TAPTITE 1-1/4"
68
1
TAG, BOLT REMOVAL
70
1
BRACKET, IGNITION SYSTEM
71
2
SPACER, IGNITION COIL
72
1
MODULE, IGNITION
73
1
ASSEMBLY, IGNITION COIL
74
2
M6-1.0 x 35MM HEX HD. CAPSCREW
75
4
M6-1.0 HEX NUT
76
2
M5-0.8 x 12MM PHILLIPS PAN HD.
MACH. SCR.
77
2
M5-0.8 HEX NUT
78
5
LOCK WASHER, M5
79
.5
RUBBER "U" CHANNEL
80
1
CRIMPTITE #10-24 x 3/8"
81
1
WIRE ASSEMBLY, BLOCKING DIODE
Section 1.7
SHEET METAL
Page 1.7-5
