ITEM
QTY
DESCRIPTION
1
1
PLATE, DIVIDER
2
2
M6-1.0 HEX NUT
3
1
SEAL RUBBER EXTRUSION 3.5 FT
4
1
WRAPPER, BOX
5
31
TAPTITE, M5- .8 x 10MM LONG
6
2
MOUNTING RAILS
7
12
M8 LOCK WASHER
8
4
M8-1.25 x 35MM HEX HD. CAPSCR.
9
2
HHCS M5-0.8 x 40MM
12
1
SPARK ARRESTOR
13
1
U-BOLT, W/SADDLE & NUTS
17
1
DEFLECTOR, AIR OUT
18
1
ASSEMBLY, MUFFLER
19
1
HOUSING, LOWER FAN
20
1
SKIRT, CARB. BAFFLE
21
1
COVER, ROCKER COVER
22
1
SKIRT, SPARK PLUG SIDE
23
1
PAN, BELLY
24
1
FRAME
25
1
GROUND STRAP
26
1
PLATE, BASE COVER
27
1
PUMP, FUEL
28
1
BARBED 90 1/8" x 1/4"
29
3
HEX NUT 1/4"-20
30
7
LOCK WASHER-1/4"-M6
31
1
CONTACTOR, STARTER
32
1
BOOT, CONTACTOR
33
1
SEAL, OIL FILTER HOLE
34
1
RETAINER, SEAL
35
4
M8 FLAT WASHER
36
1
1/4" FUEL LINE-4" LONG
37
5
1/4" HOSE CLAMP
38
1
SNAP BUSHING
39
4
SPECIAL LOCK WASHER, M5
40
2
#8 HEX NUT
41
2
#8 LOCK WASHER
PARTS LIST FOR SHEET METAL (GASOLINE UNITS)
ITEM
QTY
DESCRIPTION
42
2
HEX HD. CAPSCR. M6-1.0 x 16MM-
W/LOCKWASHER
44
3
SPECIAL LOCK WASHER, M6
45
1
GROUND STRAP, UNIT
47
1
1/8" x 3/16" NPT 90 DEG.
BARBED FITTING
48
1
BRACKET, MUFFLER HANGER
49
1
1/4" FUEL LINE (8" LONG)
50
1
3/16" CARBURETOR LINE (4" LONG)
51
1
FUEL FILTER
53
1
STARTER CONTACTOR GROUND
WIRE
54
1
SEAL, WASHER EXHAUST PIPE
57
1
PANEL, WRAPPER BOX
59
13
CRIMPTITE #10-24 x 1/2"
60
1
HEX HD. CAPSCR., M5-0.8 x 12 G8.8
61
2
CUSTOMER MOUNTING BRACKET
62
4
VIBRATION MOUNT
63
2
EARTHING STRAP
64
8
HEX NUT M8
65
3
VIBRATION MOUNT
67
2
TAPTITE 1/4"-20 x 1-1/4"
68
2
TAG, REMOVE BOLT
69
6
FLAT WASHER #10-M5
70
1
BRACKET, IGNITION SYSTEM
71
2
SPACER, IGNITION COIL
72
1
MODULE, IGNITION
73
1
ASSEMBLY, IGNITION COIL
74
2
M6-1.0 x 35MM HEX HD. CAPSCREW
75
4
M6-1.0 HEX NUT
76
2
M5-0.8 x 12MM-PPHMS
77
2
M5-0.8 HEX NUT
78
4
LOCK WASHER M5
79
1
RUBBER "U" CHANNEL 0.5 FT
80
1
CRIMPTITE #10-24 x 3/8"
81
1
COVER, IGNITION SYSTEM
Section 1.7
SHEET METAL
Page 1.7-3
