- Page 1 KODAK PROFESSIONAL Large Format 3000 Series Inkjet Printers USER’S GUIDE Part Number 6B4653...
- Page 3 Kodak warrants printers (“PRODUCT”) to be free from defects in workmanship and materials for a period of one year from the date of purchase. Kodak reserves the right to make changes or improvements to products without incurring any obligation to similarly alter products previously purchased.
-
Page 5: Table Of Contents
..........................1 NTRODUCTION Product Overview........................1 About this Guide........................3 How to Get Help in the United States and Canada..............4 Kodak Professional Support Centers Outside the United States and Canada.......4 ..................5 EGULATORY AND AFETY NFORMATION EMC Statement for CE Marking ....................5 FCC Compliance........................5... -
Page 6: Introduction
A sample roll of media is included with the printer. NOTE You may also refer to the Kodak Web site for updates on the availability of KODAK PROFESSIONAL Enhanced Imaging (EI) Inkjet Media. Use the path: http://www.kodak.com/go/lfinkjet... - Page 7 Introduction KODAK PROFESSIONAL Large Format 3000 Series Inkjet Printers Print Quality You can select a print resolution of 360 x 360 dpi, 720 x 720 dpi, or 1440 x 720 dpi depending upon your image quality and productivity needs. In high speed mode the printer produces an A0 size 720 x 720 dpi print in 18 minutes or an A0 size 360 x 360 dpi print in 9 minutes.
-
Page 8: About This Guide
Introduction KODAK PROFESSIONAL Large Format 3000 Series Inkjet Printers ABOUT THIS GUIDE This guide provides the information you need to install, set up, operate, maintain, and troubleshoot the printer. This guide is organized as follows: Introduction—describes the printer, how to use this guide, and how to get help. -
Page 9: How To Get Help In The United States And Canada
Format 3000 Series Inkjet Printers HOW TO GET HELP IN THE UNITED STATES AND CANADA Your dealer of KODAK products is the best source for information about setting up, operating, and obtaining supplies for your printer. Please contact your dealer with any questions you have. -
Page 10: Regulatory And Safety Information
Regulatory and Safety Information KODAK PROFESSIONAL Large Format 3000 Series Inkjet Printers REGULATORY AND SAFETY INFORMATION EMC STATEMENT FOR CE MARKING WARNING: This is a class A product. In a domestic environment this product may cause radio interference in which case you may be required to take adequate measures. -
Page 11: Bsmi Statement
Regulatory and Safety Information KODAK PROFESSIONAL Large Format 3000 Series Inkjet Printers BSMI STATEMENT... -
Page 12: Material Safety Data Sheet
To obtain information on the proper use, handling, and disposal of KODAK PROFESSIONAL links, consult the material safety data sheet (MSDS) which was included with your first ink order. MSDSs can also be obtained from the Kodak Environmental Services Web page (http://www.kodak.com/go/kes) by using the product name or catalog number. -
Page 13: Safety Labels
Regulatory and Safety Information KODAK PROFESSIONAL Large Format 3000 Series Inkjet Printers SAFETY LABELS SAFETY LABELS, SYMBOLES DE SÉCURITÉ SICHERHEITSSYMBOLE, SIMBOLI DI SICUREZZA, SÍMBOLO’S DE SEGURIDAD, ETIQUETAS DE SEGURANÇA, Safety labels are attached to the internal area of the printer cover 1 (see page 18), to back top side of the printer and to the top of ink cassettes cover 9 (see page 18) to alert you to potentially hazardous situations or conditions. - Page 14 Regulatory and Safety Information KODAK PROFESSIONAL Large Format 3000 Series Inkjet Printers...
- Page 15 Regulatory and Safety Information KODAK PROFESSIONAL Large Format 3000 Series Inkjet Printers CAUTION, ATTENTION, ACHTUNG, ATTENZIONE, CUIDADO, CUIDADO, Sharp edges. Keep fingers, hands, and loose articles of clothing and jewelry away from the edges of the print head transport belts.
- Page 16 Regulatory and Safety Information KODAK PROFESSIONAL Large Format 3000 Series Inkjet Printers CAUTION, ATTENTION, ACHTUNG, ATTENZIONE, CUIDADO, CUIDADO, Sharp edge at the end of knife guide. Avoid contact. Keep fingers away. Arête vive à la fin du guide à couteau. Evitez tout contact. Ne pas toucher.
- Page 17 Regulatory and Safety Information KODAK PROFESSIONAL Large Format 3000 Series Inkjet Printers CAUTION, ATTENTION, ACHTUNG, ATTENZIONE, CUIDADO, CUIDADO, Mechanical hazard; moving parts. Keep fingers, hands, and loose articles of clothing and jewelry away from the entrance slot of the unit.
- Page 18 Regulatory and Safety Information KODAK PROFESSIONAL Large Format 3000 Series Inkjet Printers CAUTION, ATTENTION, ACHTUNG, ATTENZIONE, CUIDADO, CUIDADO, Sharp points below ink cartridges. Take care in replacing cartridges. Keep fingers and hands away from the inside of the cartridge unit.
-
Page 19: Installing The Printer
Installing the Printer KODAK PROFESSIONAL Large Format 3000 Series Inkjet Printers INSTALLING THE PRINTER SELECTING A LOCATION FOR THE PRINTER Make sure that the location for the printer meets following conditions: Power supply: - Voltage: 200 to 240 VAC or 100 to 120 VAC - Frequency: 50/60 Hz ±... -
Page 20: Unpacking The Printer
Installing the Printer KODAK PROFESSIONAL Large Format 3000 Series Inkjet Printers UNPACKING THE PRINTER The printer and stand are packed in two separate boxes. Unpack the printer first. CAUTION: When unpacking the printer, make sure that all the parts described in the parts list are included in the box. Notify your dealer if anything is missing. - Page 21 Installing the Printer KODAK PROFESSIONAL Large Format 3000 Series Inkjet Printers 4. Remove all plastic materials wrapped around the printer. 5. Open the printer stand box. Make sure that the parts listed in the parts list are included in the box. Notify your dealer if anything is missing.
-
Page 22: What's In The Box
Installing the Printer KODAK PROFESSIONAL Large Format 3000 Series Inkjet Printers WHAT’S IN THE BOX? The box includes: Printer Stand (packed separately) Scroller including plastic flanges Media cutter (pre-installed in head) Media basket The Accessories kit includes: Power cable Set of ink cassettes User’s guide... -
Page 23: The Printer Parts And Components
Installing the Printer KODAK PROFESSIONAL Large Format 3000 Series Inkjet Printers THE PRINTER PARTS AND COMPONENTS Figure 1 Figure 2... - Page 24 Installing the Printer KODAK PROFESSIONAL Large Format 3000 Series Inkjet Printers Part Description Cover Protects the printer. Opening the cover immediately pauses printing. Printing resumes when you close the cover. Control Panel Positive touch keyboard with integrated LCD display. Media Hold Lever Lowers/releases pressure rolls to load/unload media.
-
Page 25: Assembling The Printer
Installing the Printer KODAK PROFESSIONAL Large Format 3000 Series Inkjet Printers ASSEMBLING THE PRINTER CAUTION: Before lifting the printer out of the box, remove all plastic wrapping materials to prevent the printer from slipping from your hands. 1. Using the six hexagon bolts and the hex wrench, attach the legs to the cross bars. - Page 26 Installing the Printer KODAK PROFESSIONAL Large Format 3000 Series Inkjet Printers NOTE: The bottom of the printer has four knobs that fit into the holes in the stand. The front of the stand is the side where the castor wheels are located.
- Page 27 Installing the Printer KODAK PROFESSIONAL Large Format 3000 Series Inkjet Printers 7. Remove the lever block. See Figure 7. Figure 7...
- Page 28 Installing the Printer KODAK PROFESSIONAL Large Format 3000 Series Inkjet Printers Assembling the Paper Basket 1. Insert the metal bars into the paper basket sleeves. 2. Install the front metal bar into the metal basket support. 3. Install the end caps on the front metal bar.
- Page 29 Installing the Printer KODAK PROFESSIONAL Large Format 3000 Series Inkjet Printers 6. After setting up the printer, move it to the desired location and lock the caster wheels. See Figure 10. Figure 10...
-
Page 30: Setting Up The Printer
Setting up the Printer KODAK PROFESSIONAL Large Format 3000 Series Inkjet Printers SETTING UP THE PRINTER CONNECTING THE INTERFACE CABLES CAUTION: When connecting the printer to your computer, make sure that both your printer and your computer are turned OFF. - Page 31 Setting up the Printer KODAK PROFESSIONAL Large Format 3000 Series Inkjet Printers Connecting an Ethernet Cable The printer comes with a preinstalled 10/100 network interface card that allows network transmission speeds up to 12.5 MB/s. To connect the network interface card to a 10/100TX network, you need a 10/100TX Ethernet hub with at least one unused port and an appropriate length of RJ45 modular cable.
-
Page 32: Connecting The Power Cable
Setting up the Printer KODAK PROFESSIONAL Large Format 3000 Series Inkjet Printers CONNECTING THE POWER CABLE 1. Make sure the printer’s power switch is turned OFF. 2. Plug the printer-end of the power cable into the connector on the back of the printer. -
Page 33: Installing The Ink Cassettes
When you use the printer for the first time, install the four or six cassettes in the slots on the back of the printer. Use only KODAK PROFESSIONAL ink cassettes. Damage that occurs as a result of using other inks will not be covered under the warranty. - Page 34 Setting up the Printer KODAK PROFESSIONAL Large Format 3000 Series Inkjet Printers NOTE: Unpack the ink cassettes just before installing them in the printer. After the ink cassettes are installed, do not remove them until you replace them. The ink cassettes must be used within two years from the date printed on the cassette.
- Page 35 Setting up the Printer KODAK PROFESSIONAL Large Format 3000 Series Inkjet Printers Installing the Ink Cassettes 1. Locate the power switch on the right side of the printer below the printer. Turn the switch ON, and put the hold lever in the DOWN position.
- Page 36 Setting up the Printer KODAK PROFESSIONAL Large Format 3000 Series Inkjet Printers 2. From the back of the printer, install the ink cassettes from right to left in the correct slots. For a printer that uses four ink cassettes, install them as follows: Slot 1 –...
- Page 37 If initial ink replenishment fails, clean the head. If the ink replenishment does not start after several head cleaning cycles, contact your dealer. If the control panel displays “not original ink” contact your ink supplier to order KODAK PROFESSIONAL ink cassettes.
-
Page 38: Loading Media
If the media is larger than standard size, it can touch the floor, and will affect the quality of your prints. Always make sure that you are printing on the printable side of the media. KODAK PROFESSIONAL media is packaged with the printable side out. - Page 39 Setting up the Printer KODAK PROFESSIONAL Large Format 3000 Series Inkjet Printers Loading Cut Sheet Media 1. Open the cover, and make sure that the hold lever is in the UP position. Selecting the Media 1. Press the Media key.
- Page 40 Setting up the Printer KODAK PROFESSIONAL Large Format 3000 Series Inkjet Printers Aligning the Media IMPORTANT: The baseline holes are a guideline. You are allowed about 0.25 in. (5 mm) of play to the left and right of the center of the baseline holes.
- Page 41 Setting up the Printer KODAK PROFESSIONAL Large Format 3000 Series Inkjet Printers 5. Lower the media hold lever by tilting it down. NOTES: Always remove the roll media and scroller from the scroller receiver before loading a cut sheet. Install the media straight so that the printer can accurately read the actual media size.
- Page 42 Setting up the Printer KODAK PROFESSIONAL Large Format 3000 Series Inkjet Printers Removing the Media 1. Open the cover. Lift the media hold lever UP, and remove the media. Loading Roll Media 1. Open the cover, and lift the hold lever to the UP position.
- Page 43 5. Move the movable flange over the scroller, and firmly press the flange inside the roll media core. NOTE: All KODAK PROFESSIONAL roll media are packaged with the printable side facing out. When the cut sheet indicator light is ON when loading a roll, the control panel displays a media search error after feeding the media for about 9.5 ft.
- Page 44 Setting up the Printer KODAK PROFESSIONAL Large Format 3000 Series Inkjet Printers Loading Roll Media NOTE: Handle the media by the edges, or wear protective gloves. 1. Feed the media into the media feed gap and between the pressure rollers and the drive roller.
- Page 45 Setting up the Printer KODAK PROFESSIONAL Large Format 3000 Series Inkjet Printers Aligning the Media 1. Check the position of the left side of the media to make sure that it is at least 0.25 in. (5 mm) from the edge of the pressure roller.
- Page 46 Setting up the Printer KODAK PROFESSIONAL Large Format 3000 Series Inkjet Printers IMPORTANT: If the roll media has not been fed straight or incorrectly, messages such as, “media error” or “media jam error” are shown on the control panel. If necessary, reload the media following the instructions above.
- Page 47 Setting up the Printer KODAK PROFESSIONAL Large Format 3000 Series Inkjet Printers 3. Repeat the the following procedures: Pulling Out the Media Checking the Position of the Roll Media Aligning the Media Checking that the Media is Parallell Adjusting the Roll Media Position Making a Test Print 1.
- Page 48 Setting up the Printer KODAK PROFESSIONAL Large Format 3000 Series Inkjet Printers 6. The printer displays [Pattern B: 4]. Using the [VALUE +] and [VALUE -] keys, enter the number of the best image for Pattern B. Press [ENTER]. 7. The printer displays [Pattern C: 4].
-
Page 49: Understanding The Control Panel And Printer Controls
Understanding the Control KODAK PROFESSIONAL Large Panel and Printer Controls Format 3000 Series Inkjet Printers UNDERSTANDING THE CONTROL PANEL AND PRINTER CONTROLS LOOKING AT THE CONTROL PANEL The printer has a direct access control panel so that you can access all the frequently... - Page 50 Understanding the Control KODAK PROFESSIONAL Large Panel and Printer Controls Format 3000 Series Inkjet Printers Description Data LED: Monitors DATA status. LED ON indicates that data is being received. LED FLASHING indicates that data is being processed. Error LED: Displays after an ERROR has occurred to indicate a possible hazardous situation.
- Page 51 Understanding the Control KODAK PROFESSIONAL Large Panel and Printer Controls Format 3000 Series Inkjet Printers Quality / Speed: Press to change the output quality and speed. Each time you press the key the LED indicator shows the current status: High Quality, Normal and High Speed (Economy) The set-up can only be changed while in idle status.
- Page 52 Understanding the Control KODAK PROFESSIONAL Large Panel and Printer Controls Format 3000 Series Inkjet Printers Activates the Head adjustment, Roll feed, Color Shift-button: Pallette, Test print or Setup sheet. Back out of menu levels or switch back to ONLINE level from top menu level when in menu-mode operation.
-
Page 53: Menu Mode Operation
Understanding the Control KODAK PROFESSIONAL Large Panel and Printer Controls Format 3000 Series Inkjet Printers MENU MODE OPERATION Menu mode operation is used to access settings that cannot be controlled from the direct access keys. As soon as media is loaded, the printer is ONLINE and ready to receive data. - Page 54 Understanding the Control KODAK PROFESSIONAL Large Panel and Printer Controls Format 3000 Series Inkjet Printers Menu Structure – overview Online Command Command MH-GL2 / MHGL2, GL2 / RTL- Printer command language selection. PASS PlotArea Normal / Expand Sets hard clip area depending on media size.
- Page 55 Understanding the Control KODAK PROFESSIONAL Large Panel and Printer Controls Format 3000 Series Inkjet Printers Cut Pos. Data / Standard Specifies cutting position on roll media following data or standard media size. Media Cut Off / Auto / Manual Sets up automatic sheet-off set up.
-
Page 56: Maintaining The Printer
Maintaining KODAK PROFESSIONAL Large the Printer Format 3000 Series Inkjet Printers MAINTAINING THE PRINTER REPLACING THE INK CASSETTES CAUTION: You should avoid any direct contact with the inks. If you come in contact with the inks, do the following: Eye contact: Rinse out the ink with a large quantity of water, and consult your doctor. - Page 57 O: Light Cyan or Orange K : Black 2. Unpack a new ink cassette. NOTE: Only use original KODAK PROFESSIONAL ink cassettes. Each cassette has a correct slot and a correct inserting direction. Open the ink cassette just before inserting it into the slot.
-
Page 58: Emptying The Waste Box
Maintaining KODAK PROFESSIONAL Large the Printer Format 3000 Series Inkjet Printers EMPTYING THE WASTE BOX The waste box is located at the back of the printer and collects the waste ink. Replace the box when it is full. 1. If the control panel displays this message CHECK WASTE BOX when you turn the printer on, check the waste box. - Page 59 Maintaining KODAK PROFESSIONAL Large the Printer Format 3000 Series Inkjet Printers 7. Press Enter. The control panel displays the following message when you complete the procedure successfully: PLOT OK CAUTION: The waste box can be disposed as a non-flammable item.
-
Page 60: Switching Between Dye Inks And Pigmented Inks
Maintaining KODAK PROFESSIONAL Large the Printer Format 3000 Series Inkjet Printers SWITCHING BETWEEN DYE INKS AND PIGMENTED INKS Proceed as follows when switching the ink type: 1) To switch from DYE ink to PIGMENTED ink: Remove the DYE ink cassettes and replace them with PIGMENTED ink cassettes. - Page 61 Maintaining KODAK PROFESSIONAL Large the Printer Format 3000 Series Inkjet Printers Step 2: If DYE ink cassettes were removed, insert the PIGMENTED ink cassettes. If CLEANING cassettes were removed, insert the DYE ink cassettes. Step 3: Use the (Value +) and (Value -) control panel keys to (Switch ink : Yes) answer “Yes”...
- Page 62 Maintaining KODAK PROFESSIONAL Large the Printer Format 3000 Series Inkjet Printers Step 4 Bring up the "Head Wash" item by pressing the [Menu Up !] Key or HeadW: Black & the [Menu Down "] Key. Colour Step 5 HeadW: Black Press the [VALUE+] key or the [VALUE-] key to specify “Black&Colour”.
- Page 63 Maintaining KODAK PROFESSIONAL Large the Printer Format 3000 Series Inkjet Printers Step 18 Change Waste Ink Remove the waste ink box from the printer unit and set a new waste ink box to the printer unit. Step 19 Change Tank? Press the [VALUE+] key or the [VALUE-] key to select "Yes."...
- Page 64 Maintaining KODAK PROFESSIONAL Large the Printer Format 3000 Series Inkjet Printers Step 11 Remove Wash Cartridge Remove the cleaning cassettes from their slots. Step 12 Head Wash The rest of the cleaning fluid in the printer unit is discharged when the cleaning cassettes are removed.
-
Page 65: Cleaning The Head Cleaning Wiper
Maintaining KODAK PROFESSIONAL Large the Printer Format 3000 Series Inkjet Printers CLEANING THE HEAD CLEANING WIPER When the head is cleaned, debris on the cleaning wiper may cause the printing to become faint or blemished. Do the following procedure to clean the head cleaning wiper. - Page 66 Maintaining KODAK PROFESSIONAL Large the Printer Format 3000 Series Inkjet Printers CAUTION: Make sure that you do not touch the head cap unit that is near the cleaning wiper. Oil may get on the cleaning wiper and it will be unable to clean the head properly.
-
Page 67: Replacing The Media Cutter Blade
Maintaining KODAK PROFESSIONAL Large the Printer Format 3000 Series Inkjet Printers REPLACING THE MEDIA CUTTER BLADE Depending upon the roll media used, dust gathers in the cutter slot and on the cutter blade edge causing irregular cuts. If necessary, replace or clean the cutting blade and clean the cutter slot. - Page 68 KODAK PROFESSIONAL Large the Printer Format 3000 Series Inkjet Printers 3. Insert a new cutting blade in the hole of the media cutter. While pushing the cutting blade down, move the cutter arm back over the cutting blade. A cutting blade can only be inserted in one direction.
- Page 69 Maintaining KODAK PROFESSIONAL Large the Printer Format 3000 Series Inkjet Printers...
-
Page 70: Troubleshooting
Troubleshooting KODAK PROFESSIONAL Large Format 3000 Series Inkjet Printers TROUBLESHOOTING POSSIBLE PRINTER PROBLEMS AND THEIR SOLUTIONS This chapter describes the problems you may occasionally have with your printer and how to resolve them. 1. After turning the power switch ON, the printer does not start. - Page 71 Troubleshooting KODAK PROFESSIONAL Large Format 3000 Series Inkjet Printers 4. When data is sent from your computer, the printer displays an error and does not print. Possible Cause Solution Reference Does your printer match the Select the correct printer on printer you selected on your your computer.
- Page 72 Troubleshooting KODAK PROFESSIONAL Large Format 3000 Series Inkjet Printers 8. Cannot cut the roll media cleanly. Possible Cause Solution Reference Is your cutting blade still Replace your cutting blade. Maintaining the sharp enough? Printer Does the media have static Remove the static electricity.
- Page 73 Troubleshooting KODAK PROFESSIONAL Large Format 3000 Series Inkjet Printers Is the Scroller installed Install the Scroller correctly. Installing the Printer correctly? Are the driver rollers clean? Clean the driver rollers. Maintaining the Printer Is the media sensor dirty? Clean the media sensor.
- Page 74 Troubleshooting KODAK PROFESSIONAL Large Format 3000 Series Inkjet Printers 14. Using the wrong media size. Possible Cause Solution Reference Are you using approved Use only approved media. Setting Up the Printer media? Is the hold lever down? Make sure to hold the lever Setting Up the Printer down.
- Page 75 Troubleshooting KODAK PROFESSIONAL Large Format 3000 Series Inkjet Printers 17. Bad quality of printed lines. Possible Cause Solution Reference Are you using approved Use only approved media. Setting Up the Printer media? Are you printing on the Make sure to load the media...
-
Page 76: Index
INDEX Accessories included ........17 Kodak Professional’s Enhanced Imaging (EI) Inkjet Media ............1 Cancel Key ............ 45 Centronics interface......... 25 Liquid Crystal Display ........47 network interface card........2 Cleaning............45 Control Panel ..........44 Media ............46 cut sheet media checking correct position of ...... - Page 77 Supported media types ........1 Switching ink types ......... 55 Quality / Speed..........46 TCP/IP............2 Resolution ............. 46 Troubleshooting..........65 RIP software ............ 2 Roll Media checking position of ........39 Used waste liquid box Roll Media Position disposing of ..........53 adjusting ...........
- Page 79 EASTMAN KODAK COMPANY Rochester, New York 14653 Kodak and Kodak Professional are trademarks of Eastman Kodak Company. Part No. 6B4653 © Eastman Kodak Company, 2000...
