HUSKY LINERS 47952 Installation Instructions Manual

HUSKY STORAGE BOX INSTALLATION INSTRUCTIONS
Please check contents and read instructions before beginning (some contents inside drawer of box)
You have received hardware for both Excursion and Suburban installation (not all hardware will be used)
1- Drawer Unit
1- Cam Spacer
1- 3/8"-24 Lock Nut
3- #8 X 1_" Stainless Steel Wood Screw
2- 4" Long Straps
1- 45_" Channel Iron
1- Cam latch
2- 8" Long Straps (2000-06 GM Products)
2- M10 X 60 Allen Bolts (2000-2007 GM Products)
2- 1" Round Spacers (2000-2007 GM Products)
4- 3/8" X 2" Hex Bolts (2007 GM Products)
2- 5" Long Nut Plates (2007 GM Products)
2- 3/8" Flat Washers—notched edge (GM Products)
1/8" Allen Wrench
3/8" Combination End Wrench
9/16" Socket and Ratchet
Phillips Head Screwdriver
1) Before beginning installation, check factory positioning of jack and jack tools. If Storage Box will block
access to these items when installed, remove them before installing Storage Box. These items may be stored
in your Storage Box once installation is completed.
2) Remove Storage Box from packaging. Check to insure you have received all the above listed
Contents and that no damage has occurred during shipping.
3) Position Storage Box top side down, placing it on a flat, non-marring surface. Remove shipping blocks and
Channel Iron from bottom of drawer using Phillips Head Screwdriver. Removing block will allow drawer to
slide out so use caution and avoid tilting Drawer Unit.
4) Turn Storage Box back over (right side up and laying flat on a non-marring surface) and extend the drawer to
the full open position.
5) Remove Detent Pin from each drawer slide by applying downward pressure on Detent Pin (see note #1).
Detent Pins will be re-inserted later so do not dispose of them.
6) Remove drawer from the Storage Box and stand it vertically on its back wall (once again on a non-marring
surface). Using a 1/8" Allen Wrench and 3/8" End Wrench, remove the two 10-32 flathead bolts and nuts from
handle installation area. Note that there are spacers (thick washers) located between the front and rear
extrusions that make up the drawer face. Should the spacers move out of position when the bolts are removed,
PACKAGE CONTENTS
TOOLS REQUIRED
INSTALLATION
1- Handle Assembly
4- 3/8" X 3_" Hex Bolts
2- _" X 1" Nut Plates
1- Cargo Liner Retention Block
1- Cargo Liner
1- Drawer Liner (Foam)
2- 4" Square plates (Excursion)
2- M6 X 40 Allen Bolts (Excursion)
2- _" Flat Washers (Excursion)
6- 3/8" Flat Washers
2- 3"X 6-1/4" Clamps (2007 GM Products)
5mm Allen Wrench (Excursion)
T-30 Torx Wrench (Excursion)
T-50 Torx Wrench (Suburban)
8mm Allen Wrench (Suburban)
Package
