HUSKY LINERS 47951 Mounting Instructions

Jeep Wrangler Spare Tire Carrier Mounting Instructions
Tools Required for Installation:
Socket Wrench
18 MM Socket
13 MM Socket
3/4" Socket
5/8" Socket
1/2" Socket
18 MM Wrench
9/16" Wrench
3/4" Wrench
5/8" Wrench
1/2" Wrench
T-30 Torx Wrench
3/16" Allen Wrench
Jack and/or Jack Stand
Phillips Head Screwdriver
Package Contents
Bumper X 1
Bumper Mount nut plate X 2
7/16" X 1" hex bolt X 4
7/16" flat washer X 8
7/16" nylock nut X 4
1/2" X 1-1/4" hex bolt X 2
1/2" X 1-1/2" hex bolt X 3
Striker Plate/Pin Assembly X 1
Before beginning installation, check to make sure all components listed above are included in packaging.
Package Contents (Continued):
Bumper Pack Contents (Continued)
Striker Nut Plate
_" Flat Washers X 5
Bumper End Plugs
U-Clips X 6
#10 X _" Washer Head Screw X 6
Bumper Surround Tabs
Swing Arm X 1
1/4" X 3/4" Allen bolt X 1
1/4" plastic washer X 1
3/8" X 1/2" fine thread hex bolt X 1
3/8" fender washer X 1
Jack Support Upright
Jack Support Spacers (3/4" & 1" Lengths)
3/8"-16 X 2-1/2" full thread hex bolt X 1
Jack Mount Hand Knob X 2
3/8" flat washer X 2
Tire Mount Assembly X 1
Washer Plates Assembly
Brake Light Mount X 1
5/16" X 1" hex bolt X 4
5/16" fender washer X 8
5/16" nylock nut X 4
5/16" plastic washer X 2
Cable Tie Mount X 3
