CONFIGURING SATA FOR RAID

Configuring SATA Hard Drive(s) for RAID Function
®
(Controller: Intel
Please follow up the steps below to configure SATA hard drive(s):
(1) Install SATA hard drive(s) in your system.
(2) Enter the BIOS Setup to configure SATA controller mode and boot
sequence.
(3) Configure RAID by the RAID BIOS.
(4) Install the SATA controller driver during the OS installation.
Before you begin the SATA configuration, please prepare:
(a) Two SATA hard drives (to ensure optimal performance, it is
recommended that you use two hard drives with identical model
and capacity). If you do not want to create RAID with the SATA
controller, you may prepare only one hard drive.
(b) An empty formatted floppy disk
(c) Windows XP setup disk
(1) Installing SATA hard drive(s) in your system
Connect one end of the SATA signal cable to the rear of the SATA
hard drive, and the other end to available SATA port(s) on the
board. Then, connect the power connector of power supply to the
hard drive.
(2) Configuring SATA controller mode and boot sequence by the
BIOS Setup
You have to make sure whether the SATA controller is configured
correctly by system BIOS Setup and set up BIOS boot sequence for
the SATA hard drive(s).
Configuring SATA for RAID Function
