LAN2 External LED Connector (CN4)

Pin
1
2
3
4
5

LAN1 External LED Connector (CN5)

Pin
1
2
3
4
5

VGA Connector (CN6)

CN6 is a DB15 connector commonly used for the CRT
Monitor.
Pin Signal
1 Red
4 NC
7 GND
10 GND
Horizontal Sync
13
Jumpers and Connectors
SHB111 Arrandale Full-Size SBC User's Manual
Signal
+ 3.3V_SBY
LINK_ACT
100, Low Active
+ 3.3V_SBY
1000, Low
Active
Signal
+ 3.3V_SBY
LINK_ACT
100, Low Active
+ 3.3V_SBY
1000, Low
Active
Pin Signal
2 Green
5 GND
8 GND
11 NC
14 Vertical Sync
Pin Signal
3 Blue
6 DETECT
9 VCC
12 DDC DATA
15 DDC CLK
15
