MAIN UNIT DISPLAY

2 3
4 5
1 POWER ON Button
CLEAN AIR MODE Button /INDICATOR LIGHT
a
CLEAN AIR & HUMIDIFY MODE Button / INDICATOR LIGHT
b
CLEAN ION SHOWER MODE Button / INDICATOR LIGHT
c
2 LIGHT CONTROL Button
Plasmacluster Ion ON / OFF Button /
3
INDICATOR LIGHT
FILTER RESET Button /
4
INDICATOR LIGHT

ILLSTRARATIVE DIAGRAM

Humidity Monitor
Indicates approximate humidity level
in the room.
Humidity setting cannot be adjusted.
Humidify Light
Humidity ON
green
Humidity OFF
off
need to supply water
red
(Flashing)
1
a b
(green)
(red)
E-5
6 7
c
(green)
(green)
(green)
CHILD-LOCK Button /
5
INDICATOR LIGHT
6 Plasmacluster Sign
FAN SPEED Button /
7
INDICATOR LIGHT
8 POWER OFF Button
Odour Monitor*
Indicates the odour intensity of the
room in 3 stages colours.
green
Faint
* KC-A60E, KC-A50E ONLY
Dust Moniter
Indicates the air purity of the room
in 5 stages colours.
Clean
Impure
8
(green)
(green)
red
Strong
green
red
