PART NAMES

FRONT / BACK

1
2
3
4
5
6
7
8
1 Air Outlet
(2 Locations)
2 Handle
(Internal)
3 Sensor
•Dust Senser
•Temperture / Humidity Senser
•Odour Senser
(KC-A60E•KC-A50E ONLY)
Water Tank
4
5 Humidifying Filter
INCLUDED
• Operation manual
• Slipper
1
2
3
6
7
8
9
10
11
12
13
×4
1 Main Unit Display
2
Front Monitor
3
Main Unit
(Shape of plug depends on country.)
Float
Humidifying Tray
(4 Locations)
Caster
(white)
HEPA Filter
Deodorizing Filter
Back Panel
(Pre-Filter)
Air Inlet
Power Cord / Plug
E-4
(Ref.E-5)
9
10
11
12
13
(black)
