5700 USER MANUAL ENG(b)
4/22/02
[1] POWER
Press to turn the power ON or OFF.
[2] DUB SPEED
Press to select the dubbing speed.
[3] TRAY OPEN/CLOSE [ ]
Press to open or close TRAY I or TRAY II.
[4] MANUAL/AUTO
Press to select automatic or manual track division.
[5] TRACK SKIP [
][
Press to skip tracks. Or press and hold down to scan forwards
or backwards within a track.
[6] CD SYNC
Press to set up synchronized recording with an external
digital source.
[7] RECORD
Press to enter record pause mode. (Recording is armed,
but does not start.)
[8] RECORD LEVEL
Adjust to set the recording level from external sources.
[9] TRAY II PLAYBACK CONTROLS
PLAY (ENTER): [
finalizing or erasing.
PAUSE: [
]
Press to pause playback or recording.
STOP: [
I
]
Press to stop playback or recording.
7:41 PM
Page 7

Player Button Functions

]
] Press to start playback, recording,
[10] ERASE
Press to erase or unfinalize a disc.
(Only CD-RW discs can be unfinalized.)
[11] FINALIZE
Press to finalize a CD-R or CD-RW disc.
[12] TRAY I PLAYBACK CONTROLS
PLAY: [ ]
Press to start playback.
PAUSE: [
]
Press to pause playback.
STOP: [
]
I
Press to stop playback.
[13] INPUT SELECTOR
Press to select the input (analog, coaxial digital or optical
digital) through which you wish to record.
[14] PHONES
Connect headphones for private listening.
[15] REMOTE SENSOR
Sensor for the remote control. Do not block.
7
