Player Button Functions - TDK DA-5900 User Manual

Digital audio cd recorder
Hide thumbs

Advertisement

[1]
[2]
[15]
[16]
[1] POWER
Press to turn the power ON or OFF.
[2] TRAY OPEN/CLOSE (TRAY I AND TRAY II)
Press to open or close TRAY I or TRAY II.
[3] TRAY I PLAYBACK CONTROLS
STOP: [
I
]
Press to stop playback.
PLAY: [ ]
Press to start playback.
PAUSE: [
]
Press to pause playback.
TRACK SKIP: [
][
]
Press to skip tracks. Or press and hold down to scan forward
or backwards within a track.
[4] TRAY II PLAYBACK CONTROLS
STOP: [
I
]
Press to stop playback or recording.
PLAY: [ ]
Press to start playback, recording, finalizing or erasing.
PAUSE: [
]
Press to pause playback or recording.
TRACK SKIP: [
][
]
Press to skip tracks. Or press and hold down to scan forward
or backwards within a track.
[5] SPEED
Press to select the dubbing speed.
[6] AUTO DUB
Press to enter record pause mode. (Recording is armed, but
does not start.)

Player Button Functions

[TRAY I]
[3]
[9]
[5]
[8]
[10]
[DISPLAY PANEL]
[TRAY II]
[6]
[7]
[12]
[11]
[13]
[7] ENTER
Press to begin the recording process. (if recording has been
armed).
[8] INPUT
Press to select the input (analog, coaxial digital or optical)
through which you wish to record.
[9] EXTERNAL RECORD
Press to select recording from an external source.
[10] MANUAL / AUTO
Press to select automatic or manual track division.
[11] ERASE
Press to erase or unfinalize a disc. (Only CD-RW discs can be
unfinalized.)
[12] FINALIZE
Press to finalize a CD-R or CD-RW disc.
[13] CD SYNC
Press to set up synchronized recording with an external digital
source.
[14] RECORD LEVEL
Adjust to set the recording level from external sources.
[15] HEADPHONE JACK
Connect headphones for private listening.
[16] HEADPHONE VOLUME
Adjusts volume of headphone output.
[14]
[4]
[2]
7
