- Page 1 DVI Audio Extender U S E R M A N U A L www.gefen.com...
- Page 2 6265 Variel Ave. Woodland Hills, CA 91367-9897 Gefen Inc. reserves the right to make changes in the hard ware, packaging and any accompanying doc u men ta tion without prior written notice. The DVI Audio Extender is a trademark of Gefen Inc.
-
Page 3: Table Of Contents
Introduction DVI Audio Extender Sender Panel Descriptions DVI Audio Extender Receiver Panel Descriptions How To Connect The DVI Audio Extender Dip Switch Usage Guide CAT5 Link Cable - Wiring Diagram Frequently Asked Questions Terminology Specifi cations Warranty TABLE OF CONTENTS... - Page 4 • If you do not need DDC data you can use a single CAT-5 cable for the video only. The DDC will not be connected. An additional 5V DC power supply will be needed for the receiver side. • If the source requires EDID present, you can use the Gefen DVI Detective to provide EDID information.
-
Page 5: Introduction
INTRODUCTION The DVI Audio Extender sender unit sits next to your computer, DVD player or any set-top box with a DVI output. The cable supplied with the DVI Audio Extender connects your DVI source to the send unit. The DVI Audio Extender receiver unit sits next to your DVI display - up to 200 feet at 1280x1024/1080i ( 150 feet at 1920x1200/1080p). -
Page 6: Dvi Audio Extender Sender Panel Descriptions
DVI AUDIO EXTENDER SENDER PANEL DESCRIPTIONS... -
Page 7: Dvi Audio Extender Receiver Panel Descriptions
DVI AUDIO EXTENDER RECEIVER PANEL DESCRIPTIONS... -
Page 8: How To Connect The Dvi Audio Extender
HOW TO CONNECT THE DVI AUDIO EXTENDER Connect your source to the DVI Audio Extender sender unit using the included DVI Cable. Connect the audio from your source to the DVI Audio Extender sender using the included analog RCA cables or optional digital audio cable. Connect your display to the DVI Audio Extender receiver unit using a DVI Cable. -
Page 9: Dip Switch Usage Guide
Gefen CAT5 Extreme products (sender and receiver) both contain a pair of dip switches located underneath the unit. These dip switches are used to select from sets of confi gurations that will equalize the signal to best match the conditions in your setup. -
Page 10: Cat5 Link Cable - Wiring Diagram
CAT5 LINK CABLE - WIRING DIAGRAM... -
Page 11: Frequently Asked Questions
TROUBLESHOOTING Frequently Asked Questions What kind of CAT-5e cable should I be using? Solid core CAT-5e cable rated at 350 Mhz 568a or 568b is the minimum requirement. CAT-6 cables are also a viable cable to use. Higher resolutions and transmission lengths greater then 80 feet might require low skew cables for optimum performance. -
Page 12: Terminology
TERMINOLOGY CAT-5 Category 5 cable, commonly known as Cat 5, is an unshielded twisted pair type cable designed for high signal integrity. The actual standard defi nes specifi c electrical properties of the wire, but it is most commonly known as being rated for its Ethernet capability of 100 Mbit/s. -
Page 13: Specifi Cations
SPECIFICATIONS Video Amplifi er Bandwidth ... 1.65 Gbps Input Video Signal ... 1.2 volts p-p Input DDC Signal ... 5 volts p-p (TTL) Single Link Range ...1080p / 1920 x 1200 DVI Connector Type ... DVI-I 29 pin female (digital only) Digital Audio Connectors...SPDIF and TOSLink Analog Audio Connectors...L+R Analog RCA Link Connector ... -
Page 14: Warranty
Gefen Inc. warrants the equipment it manufactures to be free from defects in material and workmanship. If equipment fails because of such defects and Gefen Inc. is notifi ed within one (1) year from the date of shipment, Gefen System will, at its option, repair or replace the equipment, provided that the equipment has not been subjected to mechanical, electrical or other abuse or modifi... - Page 15 6265 Variel Avenue Woodland Hills, CA 91367 1-800-545-6900 818-884-6294 fax: 818-884-3108 www.gefen.com gsinfo@gefen.com...
