- Page 1 DVI Booster USER MANUAL www.gefen.com...
- Page 2 6265 Variel Ave. Woodland Hills, CA 91367-9897 Notice Gefen Inc. reserves the right to make changes in the hardware, packaging and any accompanying documentation without prior written notice. DVI Booster is a trademark of Gefen Inc. © 2006 Gefen Inc., All Rights Reserved...
-
Page 3: Table Of Contents
TABLE OF CONTENTS Introduction Features Panel Descriptions Connecting and Operating the DVI Booster Specifications Warranty... -
Page 4: Introduction
Our Commitment Gefen will always offer the finest quality product at the best possible price. Included in that price is a lifetime of free support from a team of outstanding engineers. -
Page 5: Features
FEATURES Features • Connects DVI computers with DVI outputs to DVI compatible displays or projectors • Maintains highest DVI single link video resolution • Supports DDWG standard for DVI compliant monitors • Installs in minutes Includes: DVI Booster User's Manual... -
Page 6: Panel Descriptions
PANEL DESCRIPTIONS... -
Page 7: Connecting And Operating The Dvi Booster
How to Connect the DVI Booster 1- Connect the long DVI cable from the source into the “DVI In” on the front of the DVI Booster. The DVI Booster is placed next to your display to regenerate the DVI cable. -
Page 8: Specifications
SPECIFICATIONS Video Amplifier Bandwidth ....................1.65 Gbps Video Pixel Rate ……………………………………………………………………………………. 165 Mhz Input Video Signal ......................1.2 volts p-p Input DDC Signal ....................... 5 volts p-p (TTL) Maximum Single Link Range ................1920 x 1200 x 60hz DVI Input/Output Connector Type ............ DVI-I 29 pin female (digital only) Dimensions .................... -
Page 9: Warranty
Gefen Inc. warrants the equipment it manufactures to be free from defects in material and workmanship. If equipment fails because of such defects and Gefen Inc. is notified within one (1) year from the date of shipment, Gefen Inc. will, at its option, repair or replace the equipment, provided that the equipment has not been subjected to mechanical, electrical, or other abuse or modifications. - Page 10 *MA-DVI-141b* 6265 Variel Avenue Woodland Hills, CA 91367 1-800-545-6900 818-884-6294 fax: 818-884-3108 www.gefen.com gsinfo@gefen.com...
