Specifications - Emotiva Gen 2 XPA-2 User Manual

XPA-2

Specifications

Topology:
Fully discrete, dual differential, high current, short signal path Class A/B.
Number of Channels:
2; Stereo Mode.
1; Bridged Mode.
Power Output (rated power; THD < .1%):
300 watts per channel; both channels driven; into 8 Ohms (Stereo Mode).
500 watts per channel; both channels driven; into 4 Ohms (Stereo Mode).
1000 watts (1 channel); into 8 Ohms (Bridged Mode).
Rated Power Bandwidth (at rated power; 8 Ohm load):
20 Hz to 20 kHz + / - 0.07 dB.
Minimum Recommended Load Impedance:
4 Ohms; Stereo Mode (which equals one 4 Ohm load or two paralleled 8 Ohm loads).
8 Ohms; Bridged Mode.
Frequency Response:
10 Hz to 80 kHz (+ 0 / - 2 dB).
THD + noise:
< 0.03%.
Signal to Noise Ratio (8 Ohm load):
> 97 dB at 1 watt (A-weighted).
> 121 dB at rated power (A-weighted).
Damping Factor (8 Ohm load):
> 500.
Speaker Output Connections:
Audiophile grade, gold plated, 5-way binding posts.
Page 17
