Summary of Contents for Emotiva Gen 2 XPA-5
-
Page 3: Important Safety Precautions And Explanation Of Symbols
Important Safety Precautions and Explanation of Symbols The exclamation point within an equilateral triangle is intended to alert the user to the presence of important installation, operation, and service instructions in this manual. The lightning flash with arrowhead symbol within an equilateral triangle is intended to alert the user to the presence of uninsulated dangerous voltages within the enclosure that may be of sufficient magnitude to constitute a risk of electrical shock to the user. - Page 4 Only replace the fuse(s) in the XPA-5 with fuse(s) of proper value and voltage rating. The XPA-5 should only be cleaned as directed in the manual. Avoid spraying liquids directly onto the unit and NEVER spray liquids into the vents. Care should be taken so that small objects do not fall into the inside of the unit.
-
Page 5: Table Of Contents
XPA-5 Inputs (Rear Panel) ................... 10 Quick Start ........................11 Connections ........................12 Configuration and Operation ................... 13 Care and Maintenance ....................14 Specifications ........................15 Troubleshooting ......................18 Emotiva Audio Corporation Five-Year Limited Warranty ........ 19 Accessories ........................21 Notes ..........................22 Page 1... - Page 6 XPA-5 Page 2...
-
Page 7: Introduction
XPA-5 Introduction Thank you for purchasing the new and improved second generation Emotiva XPA-5 five channel power amplifier. The XPA-5 is the perfect amplifier to form the basis of a truly superb 5.1 channel surround sound system. The XPA-5 is also the ideal amplifier to partner with a pair of our XPA-1 monoblocks, or one of our XPA-2’s, to make a fantastic audiophile 7.1 channel system. -
Page 8: About This Manual
XPA-5 About This Manual This manual will provide you with the information you need to get started enjoying your XPA-5 stereo power amplifier. We suggest that you read through the entire manual; we kept things as short and direct as possible. -
Page 9: Features
A/B output section, and all of the advanced engineering and high quality construction you’ve come to expect from Emotiva. The new second generation XPA-5 includes all of the cutting-edge engineering and exceptional sound quality of our original XPA-5, but adds a few extra refinements that make it even better. -
Page 10: Unpacking
Your XPA-5 was carefully packed and should reach you in perfect condition. If you notice any shipping damage or other issues when you unpack it, please contact Emotiva immediately. Gently remove your XPA-5 from the packing carton and remove all wrappings and shipping material. -
Page 11: Xpa-5 Front Panel
XPA-5 XPA-5 Front Panel 1. Status Display Window This window houses the status LEDs. Note: The status lEDs can be disabled by the status Indicator switch on the rear panel. 2. Standby Button Press to switch the amplifier On; press again to return to Standby; the halo ring around the button (and the “E”... -
Page 12: Xpa-5 Rear Panel
XPA-5 XPA-5 Rear Panel 1. Trigger Input and Trigger Output The XPA-5 is switched On (from Standby) when a trigger signal is presented at the Trigger Input; the XPA-5 returns to Standby when the trigger signal is removed. When the XPA-5 is on, a 12 VDC signal is sent from the Trigger Output to control other devices. -
Page 13: Speaker Terminals
XPA-5 6. Speaker Terminals Gold plated audiophile quality five-way binding posts with clear shields accept banana plugs, lugs, or bare wire. 7. IEC Power Cord Receptacle Accepts a standard removable IEC AC power cable (a high-quality commercial power cable is included). -
Page 14: Xpa-5 Inputs (Rear Panel)
XPA-5 XPA-5 Inputs (Rear Panel) Note: Each channel has separate Balanced and Unbalanced inputs and an independent Input selector switch. one channel is shown for clarification. 1. Unbalanced (RCA) Input Audiophile quality gold plated machined RCA input connector (accepts a line level unbalanced input). -
Page 15: Quick Start
XPA-5 Quick Start To get the most from your XPA-5, we urge you to read the entire manual. If you just can’t wait to listen to it, this section will cover the basics you need to get started. • Find a secure location for your XPA-5. •... -
Page 16: Connections
• Emotiva offers very high-quality, pre-made speaker cables at reasonable prices. You will find them in the Interconnects section of our website at www.emotiva.com. Connecting an input source to your XPA-5 Your XPA-5 amplifier has both balanced (XLR) and unbalanced (RCA) inputs; switches independently select which input is active for each channel. -
Page 17: Configuration And Operation
XPA-5 Configuration and Operation Line Voltage The XPA-5 can operate from line voltages of 115 VAC +/- 10% or 230 VAC +/- 10%. The amplifier will automatically detect which line voltage it is connected to and configure itself accordingly. The Line Voltage indicators will tell you which line voltage the XPA-5 has detected. -
Page 18: Care And Maintenance
XPA-5 Care and Maintenance Periodic Maintenance Your XPA-5 requires no periodic maintenance or calibration. Cleaning your XPA-5 • If necessary, the XPA-5 should be cleaned gently with a soft rag. • If something sticky gets on the front panel or case of the XPA-5, it should be cleaned with a mild cleaning solution applied to a soft rag, followed by wiping with a clean rag dampened with plain water and drying with a soft dry rag or cloth. -
Page 19: Specifications
XPA-5 Specifications Topology: Fully discrete, dual differential, high current, short signal path Class A/B. Number of Channels: Power Output (rated power; THD < .1%): 200 watts per channel; all channels driven; into 8 Ohms. 300 watts per channel; all channels driven; into 4 Ohms. Rated Power Bandwidth (at rated power;... -
Page 20: Input Connections
XPA-5 Input Sensitivity (for rated power; 8 Ohm load): 1.8 V. Gain: 29 dB. Input Connections: Unbalanced (RCA); balanced (XLR); one each per channel, independently selectable. Input Impedance: 33 kohms (balanced). 23.5 kohms (unbalanced). Trigger: Trigger Input: 5 - 20 V (AC or DC); <10 mA input current required. Trigger Output: 12 VDC;... - Page 21 XPA-5 Dimensions: 17” wide x 7.75” high x 19” deep; unboxed (includes feet and binding posts). 23-1/2” wide x 12” high x 24-3/4” deep (boxed). Weight: 70.4 pounds unboxed (81.5 pounds boxed). Page 17...
-
Page 22: Troubleshooting
XPA-5 Troubleshooting The XPA-5 is carefully designed and manufactured from high-quality precision components to ensure years of trouble free operation. We really doubt you’ll ever have any problems with your XPA-5, but if you do, here are a few things you could try: Problem: No output (nothing is lit). -
Page 23: Emotiva Audio Corporation Five-Year Limited Warranty
Term. A claim shall not be valid (and Emotiva has no obligation related to the claim) if it is not made within the Term and if it is not made in strict compliance with the requirements of the “How do you get service?”... - Page 24 The CSR will provide you with a returned material authorization number (“RMA”). Ship the product to Emotiva at the following address, with the RMA written in large, bold numbers on the outside of the box, and with the letters “RMA” written before the number.
-
Page 25: Accessories
Using high-quality speaker cables and audio interconnects will ensure that you get the best sound quality and maximum reliability from your XPA-5 amplifier and the speakers connected to it. Emotiva Audio offers high-quality speaker cables and audio interconnects that feature solid engineering, premium build quality, excellent performance, and reasonable cost. -
Page 26: Notes
Notes All information contained in this manual is accurate to the best of our knowledge at the time of publication. In keeping with our policy of ongoing product improvement, we reserve the right to make changes to the design and features of our products without prior notice. User Manual Revision 2.3 July 2013...
