Clipper C13E Owner's Manual

Small concrete saw
Hide thumbs
Table of Contents

Advertisement

Quick Links

OWNERS
MANUAL
Small Concrete Saw
MODEL:
C13E
FORM <<C13E
11/2005

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the C13E and is the answer not in the manual?

Questions and answers

Related Manuals for Clipper C13E

Summary of Contents for Clipper C13E

  • Page 1 OWNERS MANUAL Small Concrete Saw MODEL: C13E FORM <<C13E 11/2005...
  • Page 2 WARRANTY Norton warrants all products manufactured by it against defects in workmanship or materials for a period of one (1) year from the date of shipment to the customer. The responsibility of Norton under this warranty is limited to replacement or repair of defective parts at Norton's Gainesville, Georgia factory, or at a point designated by it, of such part as shall appear to us upon inspection at such point, to have been defective in material or workmanship, with expense for transportation borne by...

  • Page 3: Table Of Contents

    Table Of Contents CONTENTS PAGE I. Preparation A. Safety Precautions B. Assembly C. C13E Series Concrete Saw Specifications D. Engine Specifications E. Pointer Alignment II. Operation A. Blade Installation 9-10 B. Starting The Engine C. Water Supply 10-11 D. Operating The Saw E.

  • Page 4: Preparation

    I. PREPARATION A. Safety Precautions Important! The following safety precautions must always be observed. Hazard Symbols Fuel (gasoline) is extremely flammable and its vapors can explode if ignited. Store gasoline only in approved containers, in well- ventilated, unoccupied approved areas, and away from sparks or flames.

  • Page 5: Dust And Silica Warning

    Dust and Silica Warning Grinding/cutting/drilling of masonry, concrete, metal and other materials can generate dust, mists and fumes containing chemicals known to cause serious or fatal injury or illness, such as respiratory disease, cancer, birth defects or other reproductive harm. If you are unfamiliar with the risks associated with the particular process and/or material being cut or the composition of the tool being used, review the material safety data sheet and/or consult your employer, the material manufacturer/supplier, governmental agencies such as OSHA and...
  • Page 6 1. Before mounting any blade on the saw, the blade should be inspected for any damage which might have occurred during shipment, handling or previous use. The blade collars and arbors should be cleaned and examined for damage before mounting the blade. 3.

  • Page 7: Assembly

    I. PREPARATION B. Assembly The compact concrete saws are shipped completely assembled and ready for use except for diamond blade, gasoline, oil, and handle bar. Inspect the saw for shipping damage. If any damage is found, contact the shipper immediately and file a freight claim. The Norton Company is not responsible for any freight-related damages.

  • Page 8: C13E Series Concrete Saw Specifications

    C. C13E Series Concrete Saw Specifications Dimensions/Weight Length (Working) 50” (1270 mm) Length (Transport) 40.5” (1029 mm) Width 20.5” (521 mm) Height 41” (1041 mm) Weight 200 lbs (90.7 kg) Engine Engine Mfg. Honda Model GX390 Spec No. GX390K1QXC9 Engine Type...

  • Page 9: Pointer Alignment

    D. Engine Prior to attempting to operate the engine, read the information contained in the engine owner's manual. An engine owners manual is supplied with every gasoline powered concrete saw. 1. Check Oil: Add oil if low. Refer to the engine owner's manual for the recommended SAE viscosity grades.

  • Page 10: Starting The Engine

    6. Tighten the blade shaft nut (counter-clockwise) securely against the outside collar and remove the Blade Shaft Locking Pin. 7. Reconnect the spark plug. Blades Use Only Clipper Diamond Blades B. Starting the Engine 1. Refer to the engine owner's manual for the proper starting procedures.

  • Page 11: Operating The Saw

    stability. The water tank adds additional blast (weight) to the machine, which aids in keeping the diamond blade in the cut and reducing vibrations. We recommend that the water tank to be filled with water at all time the machine is in use. •...

  • Page 12: Cutting Technique

    13. When moving the saw to a new location, be sure the blade is not touching the ground. Always pay close attention to where you are moving and where the blade is at all times. E. Cutting Technique Lower the blade into the concrete to the required depth by turning the hand wheel clockwise.

  • Page 13: Maintenance

    III. MAINTENANCE A. Engine Follow the below schedule for engine maintenance. NOTE: Check the Honda Engine manual that came with the engine for any changes to the maintenance schedule. If the charts have any differences, follow the chart in the Honda Engine Manual. The Norton Company does not warranty the engine.

  • Page 14: Bearings

    Always refer to the engine manual for more detailed information on checking the oil, changing oil, and oil capacity, air filter changes, and fuel type to use. Use only Honda air filters. Do not clean the air filter with gasoline or other flammable solvents.

  • Page 15: V-Belts

    For best results, bearings should be relubricated while in operation. Note: Due caution for personal safety must be observed when servicing rotating equipment. The grease should be pumped in slowly until a slight bead forms around the seals. This bead, in addition to acting as an indicator of adequate relubrication, provides additional protection against the entry of foreign matter.

  • Page 16: Depth Control

    7. Line up the straight edge along the outside face of both pulleys as shown in the drawing. 8. Misalignment will show up as a gap between the pulley face and the straight edge. 9. Make sure that the width of the outside land (area between the belt and the edge of the pulley) is equal on both pulleys.

  • Page 17: Parts List Section

    105377 Wrench 32mm 82910 Wrench 17mm 72279 NOTE: All Parts Are Sold As Individual (each) Unless Noted Otherwise Blades Use Only Clipper Diamond Blades. Contact your local Clipper Distributor or Clipper at 1-800-554-8003 for the best blade for the application.

  • Page 18: Parts Drawing

    C13E Parts Drawing...
  • Page 19 C13E Parts Drawing...

  • Page 20: Service Parts List

    Service Parts List C13E Service Parts List C13E Description Description Blade Shaft (Alone) 083280 24 Fit Barb Hose 3/4MPT X 1/2M 9600017 Nut Blade Shaft ¾'' Lefthand Thread 227156 25 RaiseTube (No Hardware) 83276 Bearings Blade Shaft (1) with Hardware 72474 Screw M12 x 80 1.75 DIN933 (ea)
  • Page 21 NOTES:...
  • Page 22 Clipper 2770 West Washington Street, Stephenville, TX 76401 Phone: 1-800-554-8003 Fax: 800-443-1092...
