- Page 1 OWNERS MANUAL Small Concrete Saw MODEL: FORM <<7418 3/2005...
-
Page 2: Warranty
WARRANTY Norton warrants all products manufactured by it against defects in workmanship or materials for a period of one (1) year from the date of shipment to the customer. The responsibility of Norton under this warranty is limited to replacement or repair of defective parts at Norton's Gainesville, Georgia factory, or at a point designated by it, of such part as shall appear to us upon inspection at such point, to have been defective in material or workmanship, with expense for transportation borne by... -
Page 3: Table Of Contents
Table Of Contents CONTENTS I. Preparation A. Safety Precautions B. Assembly C. C9 Series Concrete Saw Specifications D. Engine Specifications E. Pointer Alignment II. Operation A. Blade Installation B. Starting The Engine C. Water Supply D. Operating The Saw E. Cutting Technique III. -
Page 4: Preparation
Never tamper with the governor components of settings to increase the maximum speed. Severe personal injury and damage to the engine or equipment can result if operated at speed above maximum. Always obey the maximum speed rating of blade. DO NOT LIFT THE SAW BY THE HANDLE BARS... -
Page 5: Dust And Silica Warning
Dust and Silica Warning Grinding/cutting/drilling of masonry, concrete, metal and other materials can generate dust, mists and fumes containing chemicals known to cause serious or fatal injury or illness, such as respiratory disease, cancer, birth defects or other reproductive harm. If you are unfamiliar with the risks associated with the particular process and/or material being cut or the composition of the tool being used, review the material safety data sheet and/or consult your employer, the material manufacturer/supplier, governmental agencies such as OSHA and... - Page 6 9. When starting the saw, the operator should stand away and to the side of the blade. 10. If for any reason the saw should stall in the cut, raise the blade out of the cut. Check the outside blade shaft collar and nut for tightness.
-
Page 7: Assembly
B. Assembly The compact concrete saws are shipped completely assembled and ready for use except for diamond blade, gasoline, oil, and handle bar. Inspect the saw for shipping damage. If any damage is found, contact the shipper immediately and file a freight claim. The Norton Company is not responsible for any freight-related damages. -
Page 8: C9 Series Concrete Saw Specifications
C. C9 Series Concrete Saw Specifications Dimensions/Weight Length (Working) Length (Transport) Width Height Weight Engine Engine Mfg. Model Spec No. Engine Type Horse Power Max Torque Cooling System Oil Capacity Fuel Capacity Fuel Type Low Oil Sensor Air Filtration Characteristics... -
Page 9: Engine Specifications
1. Use a straight edge, and carefully mark a line 12 feet long on a smooth level surface. 2. Place the saw blade on the marked line, move the saw to the center of the marked line and then lower the blade until it is about 1/16” above the marked line 3. -
Page 10: Starting The Engine
Pressurized source: Turn the water control to full "ON" when using wet cutting blades. The required flow rate is 4-6 gallons per minute. Water Tank on saw: This supply is designed for use with dry blades to keep the dust levels down. The tank will not supply the proper water flow rates when used with wet cut only blades. -
Page 11: Operating The Saw
B. Starting the Engine. 2. Check the Engine Oil level. 3. Raise the saw to the full upright position. Do not let the blade come in contact with the ground. 4. Maneuver the saw to the desired starting point. -
Page 12: Cutting Technique
If the saw begins to stall, reduce the forward movement until full rpm is restored to the blade. If the saw stalls, raise the blade out of the cut before restarting. Avoid excessive side pressure or twisting of the blade in the cut. -
Page 13: Maintenance
III. MAINTENANCE A. Engine Follow the below schedule for engine maintenance. NOTE: Check the Honda Engine manual that came with the engine for any changes to the maintenance schedule. If the charts have any differences, follow the chart in the Honda Engine Manual. The Norton Company does not warranty the engine. -
Page 14: A. Engine
Always refer to the engine manual for more detailed information on checking the oil, changing oil, and oil capacity, air filter changes, and fuel type to use. Use only Honda air filters. Do not clean the air filter with gasoline or other flammable solvents. -
Page 15: V-Belts
For best results, bearings should be relubricated while in operation. Note: Due caution for personal safety must be observed when servicing rotating equipment. The grease should be pumped in slowly until a slight bead forms around the seals. This bead, in addition to acting as an indicator of adequate relubrication, provides additional protection against the entry of foreign matter. -
Page 16: Depth Control
7. Line up the straight edge along the outside face of both pulleys as shown in the drawing. 8. Misalignment will show up as a gap between the pulley face and the straight edge. 9. Make sure that the width of the outside land (area between the belt and the edge of the pulley) is equal on both pulleys. -
Page 17: Iv. Parts List Section A. Ordering Information
Common Replacement Parts Description Belts V-belts XPA 710LW (set of 3) Blade Shaft Nut ¾-16 Left Hand Thread (Operators Right Side Of Saw) Collar Tight (Operators Right Side) Collar Loose Assembly (With Pin) Drive Pin ∅3/8 x 1 Bearing Blade Shaft (1) -
Page 18: Parts Drawing
C9 Parts Drawing... - Page 19 C9 Parts Drawing...
-
Page 20: Service Parts List
Service Parts List C9 Description Blade Shaft (Alone) Nut Blade Shaft ¾'' Lefthand Thread Bearings Blade Shaft (1) with Hardware Screw M12 x 70 1.75 DIN931(ea) Washer M12 DIN125 (ea) Lock Washer M12 DIN127 (ea) Nut M12 1.75 DIN934(ea) Screw M12 x 45 1.75 DIN933 (ea) - Page 21 NOTES...
- Page 22 Norton Construction Products PO Box 2898 Gainesville, GA 30503 Phone: 800-554-8003 or 770-967-3954 (8:00 A.M. to 7:00 P.M. Eastern Time) Fax: 800-443-1092 or 770-967-7287...
