Summary of Contents for Clipper C13
- Page 1 OWNERS MANUAL Small Concrete Saw MODEL: FORM <<7317 3/2005...
-
Page 2: Warranty
WARRANTY Norton warrants all products manufactured by it against defects in workmanship or materials for a period of one (1) year from the date of shipment to the customer. The responsibility of Norton under this warranty is limited to replacement or repair of defective parts at Norton's Gainesville, Georgia factory, or at a point designated by it, of such part as shall appear to us upon inspection at such point, to have been defective in material or workmanship, with expense for transportation borne by... -
Page 3: Table Of Contents
Table Of Contents CONTENTS I. Preparation A. Safety Precautions B. Assembly C. C13 Series Concrete Saw Specifications D. Engine Specifications E. Pointer Alignment II. Operation A. Blade Installation B. Starting The Engine C. Water Supply D. Operating The Saw E. Cutting Technique III. -
Page 4: Preparation
I. PREPARATION A. Safety Precautions Important! The following safety precautions must always be observed. Hazard Symbols Fuel (gasoline) is extremely flammable and its vapors can explode if ignited. Store gasoline only in approved containers, in well- ventilated, unoccupied approved areas, and away from sparks or flames. -
Page 5: Dust And Silica Warning
Dust and Silica Warning Grinding/cutting/drilling of masonry, concrete, metal and other materials can generate dust, mists and fumes containing chemicals known to cause serious or fatal injury or illness, such as respiratory disease, cancer, birth defects or other reproductive harm. If you are unfamiliar with the risks associated with the particular process and/or material being cut or the composition of the tool being used, review the material safety data sheet and/or consult your employer, the material manufacturer/supplier, governmental agencies such as OSHA and... - Page 6 1. Before mounting any blade on the saw, the blade should be inspected for any damage which might have occurred during shipment, handling or previous use. The blade collars and arbors should be cleaned and examined for damage before mounting the blade. 3.
-
Page 7: Assembly
I. PREPARATION B. Assembly The compact concrete saws are shipped completely assembled and ready for use except for diamond blade, gasoline, oil, and handle bar. Inspect the saw for shipping damage. If any damage is found, contact the shipper immediately and file a freight claim. The Norton Company is not responsible for any freight-related damages. -
Page 8: C13 Series Concrete Saw Specifications
C. C13 Series Concrete Saw Specifications Dimensions/Weight Length (Working) Length (Transport) Width Height Weight Engine Engine Mfg. Spec No. Engine Type Horse Power Max Torque Model Model Cooling System Oil Capacity Fuel Capacity Fuel Type Low Oil Sensor Air Filtration... -
Page 9: Engine Specifications
D. Engine Prior to attempting to operate the engine, read the information contained in the engine owner's manual. An engine owners manual is supplied with every gasoline powered concrete saw. 1. Check Oil: Add oil if low. Refer to the engine owner's manual for the recommended SAE viscosity grades. -
Page 10: Starting The Engine
2. Remove the blade shaft nut, (Turn clockwise) , and remove the outside collar. 3. Clean off any foreign particles on the clamping surfaces of both collars and on the mounting surface of the blade. 4. Place the blade on the blade shaft, lining up the drive pin hole in the blade with the drive pinhole in the inside collar. -
Page 11: Operating The Saw
use of water greatly decreases the amount of dust produced during the cutting process, aids in the cooling of the blade, and provides additional stability. D. Operating the Saw 1. For blade installation instructions see section II. Operation sub heading A. Installing the Blade. -
Page 12: Cutting Technique
13. When moving the saw to a new location, be sure the blade is not touching the ground. Always pay close attention to where you are moving and where the blade is at all times. E. Cutting Technique Lower the blade into the concrete to the required depth by turning the hand wheel clockwise. -
Page 13: Maintenance
III. MAINTENANCE A. Engine Follow the below schedule for engine maintenance. NOTE: Check the Honda Engine manual that came with the engine for any changes to the maintenance schedule. If the charts have any differences, follow the chart in the Honda Engine Manual. The Norton Company does not warranty the engine. -
Page 14: A. Engine
Always refer to the engine manual for more detailed information on checking the oil, changing oil, and oil capacity, air filter changes, and fuel type to use. Use only Honda air filters. Do not clean the air filter with gasoline or other flammable solvents. -
Page 15: V-Belts
For best results, bearings should be relubricated while in operation. Note: Due caution for personal safety must be observed when servicing rotating equipment. The grease should be pumped in slowly until a slight bead forms around the seals. This bead, in addition to acting as an indicator of adequate relubrication, provides additional protection against the entry of foreign matter. -
Page 16: Depth Control
7. Line up the straight edge along the outside face of both pulleys as shown in the drawing. 8. Misalignment will show up as a gap between the pulley face and the straight edge. 9. Make sure that the width of the outside land (area between the belt and the edge of the pulley) is equal on both pulleys. -
Page 17: Iv. Parts List Section A. Ordering Information
IV. PARTS LIST SECTION A. Ordering Information 1. List model number and serial number of machine. 2. List part number and serial number of part not the item number. 3. Wherever alternate parts are shown due to product improvement, inspect the part you have and provide additional description as necessary. -
Page 20: Service Parts List
Item DESCRIPTION Basic Frame Rear axle assy. Rear Wheel Rear axle Front wheel complete Bushing Iglidur 20/23/11 Bushing Iglidur (set of 2) Screw Feed.Spindle Raise-lower screw + key 10 Bearing + Screw 11 Stop ring A20 12 Depth screw locking 13 Handwheel + nut 14 Handle 15 Handwheel + Handle... - Page 21 NOTES...
- Page 22 Norton Construction Products PO Box 2898 Gainesville, GA 30503 Phone: 800-554-8003 or 770-967-3954 (8:00 A.M. to 7:00 P.M. Eastern Time) Fax: 800-443-1092 or 770-967-7287...
