Specifications - Generac Power Systems CENTURION SERIES Specification

ES Standby Generator System - 7 kW
Generator
Model
Rated Maximum Continuous Power Capacity (LP)
Rated Maximum Continuous Power Capacity (NG)
Rated Voltage
Rated Maximum Continuous Load Current – 240 Volts
Main Line Circuit Breaker
Phase
Number of Rotor Poles
Rated AC Frequency
Power Factor
Battery Requirement (not included)
Unit Weight (Pounds/Kilos)
Dimensions (L x W x H) in./mm
Sound output in dB(A) at 23 ft. (7m) with generator operating at normal load**
Engine
Type of Engine
Number of Cylinders
Displacement
Cylinder Block
Valve Arrangement
Ignition System
Governor System
Starter
Oil Capacity Including Filter
Operating RPM
Fuel Consumption
Natural Gas ft³/hr (m³/hr)
1/2 Load
Full Load
ft 3 /hr (gal/hr) [Liters/hr]
Liquid Propane
1/2 Load
Full Load
Note: Fuel pipe must be sized for full load. Required fuel pressure to generator fuel inlet at all load ranges - 5-7" water column (9-13mm mercury) for natural gas, 10-12" water column (19-22mm
mercury) for LP gas.
For Btu content, multiply ft 3 /hr x 2500 (LP) or ft 3 /hr x 1000 (NG)
For Megajoule content, multiply m³/hr x 93.15 (LP) or m³/hr x 37.26 (NG)
Controls
Digital LED Indicators
Mode Switch: Auto
Off
Manual/Test (start)
Engine Start Sequence
Engine Warm-up
Engine Cool-Down
Starter Lock-out
2.5 Amp Timed Trickle Battery Charger
Automatic Voltage Regulator w/Overvoltage Protection
Automatic Low Oil Pressure Shutdown
Overspeed Shutdown
High Temperature Shutdown
Overcrank Protection
Safety Fused
**Sound levels are taken from the front of the generator. Sound levels taken from other sides of the generator may be higher depending on installation parameters. Rating definitions - Standby: Applicable
for supplying emergency power for the duration of the utility power outage. No overload capability is available for this rating. (All ratings in accordance with BS5514, ISO3046 and DIN6271). * Maximum
wattage and current are subject to and limited by such factors as fuel Btu/megajoule content, ambient temperature, altitude, engine power and condition, etc. Maximum power decreases about 3.5 percent for
each 1,000 feet (304.8 meters) above sea level; and also will decrease about 1 percent for each 6° C (10° F) above 16° C (60°F).
005888-0
7,000 Watts*
6,000 Watts*
240
29.2 / 25
30 Amp
1
2
60Hz
1.0
Group 26R, 12 Volts and 525 CCA Minimum
250/113.4
24.4 x 30.2 x 33/618.5 x 767.5 x 837
67
GENERAC OHV
1
432cc
Aluminum w/Cast Iron Sleeve
Overhead Valve
Solid-state w/Magneto
Mechanical
12 VDC
Approx. 1.1 Qts./1.0L
3,600
85 (2.41)
148 (4.19)
36 (0.99) [3.75]
46 (1.26) [4.79]
Simple user interface for ease of operation.
Automatic Start on Utility failure. 7 day exerciser.
Stops unit. Power is removed. Control and charger still operate.
Start with starter control, unit stays on. If utility fails, transfer to load takes place.
Cyclic cranking: 16 sec. on, 7 rest (90 sec. maximum duration)
5 sec.
1 min.
Starter cannot re-engage until 5 sec. after engine has stopped.
Standard
Standard
Standard
Standard, 72Hz
Standard
Standard
Standard

specifications

3 of 5
