Owner's Manual
WARNING: Follow all leak check
procedures carefully in this manual prior
to barbecue operation. Do this even if
barbecue was dealer assembled.
NOTICE TO INSTALLER: These
instructions must be left with the owner
and the owner should keep them for
future use.
THIS GAS APPLIANCE IS DESIGNED FOR
OUTDOOR USE ONLY.
WARNING: Do not try to light this
appliance without reading "Lighting"
instructions section of this manual.
SP-100
®
LP Gas Barbecue
Serial Number
Please use this number in registering your warranty and
any correspondence with the factory.
E
F
National
PROPANEGAS
FOR YOUR SAFETY
1. Do not store or use gasoline or other
flammable vapors and liquids in the
vicinity of this or any other appliance.
2. An LP tank not connected for use shall
not be stored in the vicinity of this or
any other appliance.
FOR YOUR SAFETY
If you smell gas:
1. Shut off gas to the appliance.
2. Extinguish any open flame.
3. Open lid.
4. If odor continues, immediately call
your gas supplier or your fire
department.
®
gama
Association
6271801
10/94

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SP 100 LP and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Weber SP 100 LP

Summary of Contents for Weber SP 100 LP

  • Page 1 SP-100 LP Gas Barbecue ® ® Owner's Manual Serial Number Please use this number in registering your warranty and any correspondence with the factory. ® gama National PROPANEGAS Association WARNING: Follow all leak check FOR YOUR SAFETY procedures carefully in this manual prior 1.

  • Page 2: Warnings

    Improper assembly may be dangerous. Please carefully follow the assembly instructions in this manual. After a period of storage, and/or nonuse, the Weber Gas Barbecue should be checked for gas leaks and burner obstructions before using. See instructions in this manual for correct procedures.

  • Page 3: Warranty & Patents

    There are no other express warrants except as warrants to the ORIGINAL PURCHASER of set forth herein and any applicable implied this Weber Gas Barbecue that it will be free of warranties of merchantability and fitness are defects in material and workmanship from the...

  • Page 4: Patents And Trademarks

    , Genesis, Flavorizer and Crossover are registered U.S. trademarks; Perma-Mount, Gas Catcher, FlameCheck, Steam-N-Chips, Spider Stopper, and Warm-Up are U.S. trademarks of Weber-Stephen Products Co., 200 East Daniels Road, Palatine, IL 60067-6266. U.S.A. Genesis Gas Barbecues are covered under the following patent nos.: U.S.A. #4,677,964;...

  • Page 5: Table Of Contents

    Convenient tables and racks. IMPORTANT NEW FEATURES: b) Heavy gauge porcelain-on-steel lid seals in heat. Your Weber Gas Barbecue is equipped with a new c) Rapid read thermometer for precision cooking and improved LP tank connection, that has measures grill temperature, and can be removed additional safety features.

  • Page 6: General Instructions

    LP tank stored outdoors in a well-ventilated space. The Weber Gas Barbecue is portable so you can easily change its location in your yard or on your patio. LP tanks must be stored outdoors in a well- Portability means you can take your Weber Gas ventilated area out of the reach of children.

  • Page 7: Assembly

    While we give much attention to our products, unfor- Bottom tray tunately an occasional error may occur. If a part is missing, do not go back to the store. Call the Weber Customer Service Center toll free 1-800-446-1071 to receive immediate assistance. Have your owner’s manual and serial number of the barbecue available for reference.
  • Page 8 Left frame Five long Flavorizer Bars Eight short Flavorizer Bars Right frame Tank panel assembly Wheel frame Front panel Caster frame Catch pan holder Two frame connectors Catch pan Work table Two drip pans Swing table assembly Manifold bracket Support rod Thermometer Axle Two wheels...
  • Page 9 Check contents of hardware packs Two plastic buttons (actual size) Three burner control knobs 1/4-20 keps nut Three tool holders Two 1/4-20 wing nuts (actual size) Five tubing plugs (two are spares) Fourteen 1/4 inch nylon washers Support rod holder Two hair pin cotters Swing table end bracket Two wheel hubcaps...
  • Page 10 Tap on one hubcap. Put one wheel on the axle, WEBER side toward the Lay the leg pieces as shown so the leg tabs point up. hubcap. Slide the axle through the frame. Add the other Figure 2.
  • Page 11 Step 4 Step 5 Continue frame assembly Complete frame assembly You will need: caster frame, wheel frame, four 1/4-20 x You will need: partial frame assembly, two frame 1/2 inch bolts, four nylon washers and a 7/16 inch connectors, four 1/4-20 x 2 inch bolts, four nylon wrench.
  • Page 12 Step 6 Step 7 Insert casters Add front panel You will need: frame assembly and two casters. You will need: front panel and two plastic buttons. Push the casters firmly into the inserts in the ends of the Turn frame assembly right side up. caster legs.
  • Page 13 Step 8 Your Weber Gas Barbecue burner assembly has been factory assembled, pressure and flame tested. As a Add cooking box safety precaution we recommend you check the burner alignment: You will need: frame assembly, cooking box (assembly), 1/4-20 x 2 inch bolt, 1/4 inch nylon washer, a) Do the valves fit into the ends of the burners? 1/4-20 keps nut, pliers and a 7/16 inch wrench.
  • Page 14 Step 9 Step 10 Install manifold bracket Install tank panel assembly You will need: manifold bracket You will need: tank panel assembly, 1/4-20 x 1 1/4 inch bolt, 1/4-20 hex nut, nylon washer and a 7/16 inch Hook the bracket onto the manifold at the center burner wrench.
  • Page 15 Step 11 Step 12 Add fuel scale assembly Install igniter You will need: fuel scale assembly, two 1/4-20 wing nuts Note - The igniter wires are already attached to the Gas Catcher Ignition Chamber and the igniter. This was done and two nylon washers.
  • Page 16 If the tank manufacturer has not resolved the issue valve.) One series of tanks mounts with the valve facing to your satisfaction, then call Weber-Stephen Products front. The other tanks mount with the valve facing away Co., Customer Service Center.
  • Page 17 Step 15 Route the hose so it will not interfere with the scale indicator rod. Check that all burner valves are off The hose and regulator are connected in the following You will need: one burner control knob. manner: Valves are shipped in the OFF position, but you should Slide back the collar of the quick disconnect on the tank check to be sure.
  • Page 18 The burners have the source and rinse connections with water. been flame tested. As a safety precaution you should recheck all fittings for leaks before using your Weber Gas Barbecue. Shipping and handling may have loosened or damaged a gas fitting.
  • Page 19 Step 18 Step 19 Install the bottom tray Install Flavorizer Bars and Cooking Grates You will need: bottom tray, catch pan holder, catch pan You will need: five long Flavorizer Bars, eight short and one drip pan. Flavorizer Bars and two cooking grates. Set the long Flavorizer Bars side to side in the lower position, then set the short Flavorizer Bars front to back in the upper position in the cooking box.
  • Page 20 Step 20 Step 21 Install Lid Add tool holders, control panel and burner control knobs You will need: lid, two hinge pins and two hair pin cotters. You will need: two tool holders, control panel and three burner control knobs. Set the lid in place.
  • Page 21 Step 22 Insert one end of the hinge rod into the hole in the frame. Figure 29 (a). Install swing table Insert the other end into the hole in the swing table end You will need: swing table assembly, support rod, bracket.
  • Page 22 Step 23 Complete accessory installation You will need: warming rack, work table, accessory rack, three tubing plugs, thermometer and a hammer. Set the warming rack into the slots at the rear of the cooking box. Figure 30 (a). Set the work table onto the left side rails. Figure 30 (b). Set the accessory rack in place between the two frame connectors.

  • Page 23: Operating Instructions

    If up which can cause serious bodily injury the hose is found to be damaged in any way, do not use the barbecue. Replace using only Weber or death. authorized replacement manifold assembly. Order 4) Turn the tank on by turning the tank valve from Weber-Stephen Products Co., Customer...
  • Page 24 Manual Lighting 4) Turn the tank on by turning the tank valve counterclockwise. DANGER 5) Strike a match and put the flame into the matchlight Failure to open lid while igniting the hole in the front of the cooking box. barbecue, or not waiting 5 minutes to allow the gas to clear if the barbecue WARNING: Do not lean over open barbecue.

  • Page 25: Cooking

    (See Section "Annual cooking you would use (MOM) (FRONT at medium, Maintenance.") CENTER off, and BACK at medium). See your Weber cookbook for detailed cooking instructions. Note: The temperatures inside your cooking box, for the first few uses, while surfaces are still very reflective, may be hotter than those shown in your cookbook.

  • Page 26: Troubleshooting & Maintenance Lp Tank Information

    Refilling the LP tank Connecting the LP tank WARNING: Make sure that the LP tank valve is We suggest that you refill before the fuel scale indicator closed. Close by turning clockwise. reaches “E.” DANGER Note - If you run out of fuel, check the indicator setting and/or adjust the fuel scale indicator setting with the Do not use an open flame to check for scale setting wing nut while the tank is empty so you do...
  • Page 27 If leak does not stop, turn off the gas and contact valve. Figure 5 (a). Push the male fitting of the Weber-Stephen Customer Service. Do not use the regulator into the quick disconnect, and maintain barbecue.

  • Page 28: Safe Handling Tips For Lp Gas

    The LP tank and connections supplied with your Liquid Propane (LP) gas is a petroleum product as Weber Gas Barbecue have been designed and are gasoline and natural gas. LP gas is a gas at tested to meet government, American Gas regular temperatures and pressures.

  • Page 29: Annual Maintenance

    When leak checks are complete, turn gas supply OFF at found to be damaged in any way, do not use the the source and rinse connections with water. barbecue. Replace using only Weber authorized replacement manifold assembly. Order from Weber- Stephen Products Co., Customer Service Center or authorized dealer.

  • Page 30: General Maintenance

    Weber Spider Stopper Guards set for the correct air and gas mixture. The correct flame Your Weber Gas Barbecue, as well as any outdoor gas pattern is shown in Figure 10. appliance, is a target for spiders and other insects. They Tips occasionally yellowish can nest in the venturi section of the burner tubes.
  • Page 31 View from behind cooking box CAUTION: If the Spider Stopper Guards do not fit tightly, contact Weber-Stephen Customer Service. CAUTION: After reinstalling the gas lines, they should be leak checked with a soap and water solution before using the barbecue. See Step“Check Wing nuts for gas leaks”.

  • Page 32: Troubleshooting

    Fuel scale shows that there is gas in the LP Check adjustment of fuel scale. Fuel scale must be adjusted tank, but tank is empty. with an empty tank. If problems cannot be corrected by using these methods, please contact Weber-Stephen Customer Service.
