  • Page 1 AV Receiver DTR-80.2 DTR-70.2 Instruction Manual...

  • Page 2: Introduction

    Introduction WARNING: WARNING AVIS RISK OF ELECTRIC SHOCK RISQUE DE CHOC ELECTRIQUE TO REDUCE THE RISK OF FIRE OR ELECTRIC DO NOT OPEN NE PAS OUVRIR SHOCK, DO NOT EXPOSE THIS APPARATUS TO The lightning flash with arrowhead symbol, within an RAIN OR MOISTURE.

  • Page 3: Precautions

    Precautions 1. Recording Copyright—Unless it’s for personal use For U.S. models only, recording copyrighted material is illegal without FCC Information for User the permission of the copyright holder. CAUTION: 2. AC Fuse—The AC fuse inside the unit is not user-ser- The user changes or modifications not expressly approved viceable.

  • Page 4: Supplied Accessories

    Supplied Accessories Thank you for purchasing an Integra AV receiver. Please read this manual thoroughly before making con- nections and plugging in the unit. Make sure you have the following accessories: Following the instructions in this manual will enable you...

  • Page 5: Table Of Contents

    Looking up for Remote Control Code ......96 Using the Home Menu..........27 Entering Remote Control Codes........98 Changing the Input Display .......... 28 Remote Control Codes for Integra/ Using Headphones............28 Onkyo Components Connected via ..... 98 Using Activities to Start Easy Macros......28 Resetting Remote Mode Buttons........

  • Page 6: Features

    • 220 Watts/Channel @ 6 ohms (IEC) • (DTR-80.2) 7 Digital Inputs (4 Optical/3 Coaxial) • 280 Watts/Channel @ 6 ohms (JEITA) • (DTR-70.2) 6 Digital Inputs (3 Optical/3 Coaxial) (DTR-70.2) • Component Video Switching (3 Inputs/1 Output) • 140 Watts/Channel @ 8 ohms (FTC) •...
  • Page 7 HD Radio™ and the HD Radio Ready logo are proprietary trademarks of iBiquity Digital Corporation. THX and the THX logo are trademarks of THX Ltd. which To receive HD Radio broadcasts, you must install an Onkyo may be registered in some jurisdictions. All rights reserved. UP-HT1 HD Radio tuner module (sold separately).

  • Page 8: Front & Rear Panels

    Front & Rear Panels Front Panel North American models Australian models The actual front panel has various logos printed on it. They are not shown here for clarity. The page numbers in parentheses show where you can find the main explanation for each item. On/Standby button Tuning Mode button (➔...

  • Page 9: Display

    Input selector buttons (BD/DVD, VCR/DVR, AUX Input HDMI jack (➔ CBL/SAT, Game, PC, AUX, Tape, Tuner, AUX Input jacks (Video, Audio L/R and Digital) TV/CD, Phono, Port and NET/USB) (➔ (➔ USB port (➔ 81, 91) RT/PTY/TP button (Australian models) (➔...

  • Page 10: Rear Panel

    Rear Panel Illustration is based on DTR-80.2. North American models UNIVERSAL PORT jack Composite video, S-Video and analog audio jacks (BD/DVD IN, VCR/DVR IN and OUT, CBL/SAT IN, IR IN (A/B) and OUT jacks GAME IN, PC IN, TAPE IN and OUT, TV/CD IN DIGITAL IN COAXIAL and OPTICAL jacks and PHONO IN) USB port (DTR-80.2)

  • Page 11: Remote Controller

    Controlling the AV Receiver To control the AV receiver, press Receiver to select Receiver mode. You can also use the remote controller to control Integra/Onkyo Blu-ray Disc/DVD player, CD player and other components. See “Entering Remote Control Codes” for more details (➔...

  • Page 12: About Home Theater

    About Home Theater Enjoying Home Theater Thanks to the AV receiver’s superb capabilities, you can enjoy surround sound with a real sense of movement in your own home—just like being in a movie theater or concert hall. With Blu-ray Discs or DVDs, you can enjoy DTS and Dolby Digital.

  • Page 13: Connections

    Connections Connecting the AV Receiver Speaker Connection Precautions Connecting Your Speakers Read the following before connecting your speakers: Speaker Configuration • You can connect speakers with an impedance of between 4 and 16 ohms. If the impedance of any of the connected The following table indicates the channels you should use speakers is 4 ohms or more, but less than 6 ohms, be sure depending on the number of speakers that you have.
  • Page 14 Connecting the Speaker Cables Screw-type speaker terminals Strip 1/2" to 5/8" (12 to 15 mm) of 1/2" to 5/8"(12 to 15 mm) insulation from the ends of the speaker cables, and twist the bare wires tightly, as shown. Using Banana Plugs (North American models) •...
  • Page 15 Using Dipole Speakers Normal speakers Dipole speakers You can use dipole speakers for the surround and surround back speakers. Dipole speakers output the same sound in two directions. TV/screen TV/screen Dipole speakers typically have an arrow printed on them to indicate how they should be positioned.
  • Page 16 Bridging the Front Speakers The FRONT L/R and SURR BACK/ZONE 3 L/R terminal posts can be used with front speakers and surround back speak- ers respectively, or bridged together to provide almost double the output power for the front speakers. •...

  • Page 17: About Av Connections

    About AV Connections Connected image with AV components HDMI cable Other cables : Video : Audio : Video & Audio AV receiver AV receiver Blu-ray Blu-ray Disc/DVD player Disc/DVD Game console Game console TV, projector, etc. TV, projector, etc. • Before making any AV connections, read the manuals supplied with your AV components. •...

  • Page 18: Connecting Your Components With Hdmi

    Connecting Your Components with HDMI VCR or DVD recorder/Digital Video Recorder Game console TV, projector, etc. Personal computer Blu-ray Disc/DVD player Camcorder Satellite, cable, set-top box, etc. Connect your components to the appropriate jacks. The default input assignments are shown below. ✔: Assignment can be changed (➔...

  • Page 19: Connecting Your Components

    Connecting Your Components Front Rear Connect your components to the appropriate jacks. The default input assignments are shown below. ✔: Assignment can be changed (➔ 52, 53). Jack Signal Components Assignable AUX Input Video Composite video Camcorder, etc Audio L/R Analog audio Digital Digital audio...

  • Page 20: Connecting Integra/Onkyo

    (➔ 41). Connecting Integra/Onkyo Components Note Step 1: Make sure that each Integra/Onkyo component is con- • Use only cables for connections. cables are supplied nected with an analog audio cable (connection in the with Integra/Onkyo players (DVD, CD, etc.).

  • Page 21: Connecting Antenna

    Connecting Antenna This section explains how to connect the supplied indoor FM antenna and AM loop antenna. The AV receiver won’t pick up any radio signals without any antenna connected, so you must connect the antenna to use the tuner. Caution (North American (Australian models)

  • Page 22: Which Connections Should I Use

    Which Connections Should I Use? The AV receiver supports several connection formats for compatibility with a wide range of AV equipment. The format you choose will depend on the formats supported by your components. Use the following sections as a guide. Video Connection Formats Video component can be connected by using any one of the following video connection formats: composite video, S-Video, PC IN (Analog RGB), component video or HDMI, the latter offering the best picture quality.
  • Page 23 ■ “Monitor Out” setting set to “Analog” Video Signal Flow Chart Video input signals flow through the AV receiver as shown, with composite video, S-Video and PC IN (Analog Blu-ray Disc/DVD player, etc. RGB) sources being upconverted for the component video output.

  • Page 24: Turning On & Basic Operations

    Turning On & Basic Operations Turning On/Off the AV Receiver On/Standby Standby indicator Standby Receiver Turning On Press On/Standby on the front panel. Press Receiver followed by On on the remote controller. The AV receiver comes on, the display lights, and the Standby indicator goes off. Pressing the remote controller’s On again will turn on any components connected via Turning Off Press On/Standby on the front panel.

  • Page 25: Basic Operations

    Basic Operations Displaying Source Information This manual describes the procedure using the remote controller unless otherwise specified. You can display various information about the current input source as follows. (Components connected to the Selecting the Language Used for the UNIVERSAL PORT jack are excluded.) Onscreen Setup Menus Press Receiver followed by Display repeatedly to You can determine the language used for the onscreen...

  • Page 26: Muting The Av Receiver

    Muting the AV Receiver Selecting Speaker Layout You can temporarily mute the output of the AV receiver. You can prioritize which speakers you want to use. Press Receiver followed by Muting. Press Receiver followed by SP Layout repeat- edly. The output is muted and the MUTING indicator flashes on the display.

  • Page 27: Using The Home Menu

    Using the Home Menu Note Only when you have selected “Custom” in the “Picture The Home menu provides you quick access to frequently 63), pressing Enter allows you to adjust the fol- Mode” (➔ used menus without having to go through the long stan- lowing items via the Home menu;...

  • Page 28: Changing The Input Display

    Changing the Input Display Using Activities to Start Easy Macros You can use Activities to execute a number of remote When you connect an -capable Onkyo component, you control operations with a single button. must configure the input display so that can work This button has the following two modes.

  • Page 29: Audyssey Multeq ® Xt32 Room Correction And Speaker Setup

    Turning Off the Components Audyssey MultEQ ® XT32 Room Correction and Speaker Setup Press All Off. With the supplied calibrated microphone, The playback component assigned to the Audyssey MultEQ XT32 automatically determines the last-pressed Activities, the AV receiver, and the TV number of speakers connected, their size for purposes of turn off.
  • Page 30 If you use a powered subwoofer(s), adjust the sub- woofer volume level to 75dB. Test tones are played through the subwoofer. Use the volume control on the subwoofer. Caution • When the “Subwoofer” setting is set to “1ch”, the left-hand subwoofer (SW1) alone will be measured. When the “Subwoofer”...
  • Page 31 Note • See “Speaker Configuration” for appropriate settings (➔ 13). • You can view the calculated settings for the speaker con- figuration, speaker distances, and speaker levels by using Changing the Speaker Settings Manually Disconnect the speaker setup microphone. You can manually make changes to the settings found dur- ing Audyssey MultEQ XT32 Room Correction and Speaker Setup.

  • Page 32: Listening To The Radio

    Listening to the Radio ■ Manual tuning mode This section describes the procedure using the but- tons on the front panel unless otherwise specified. Press Tuning Mode so that the AUTO indicator goes off on the display. Using the Tuner Press and hold Tuning / .

  • Page 33: Presetting Fm/Am Stations

    Presetting FM/AM Stations Listening to SIRIUS Satellite Radio ® (North American models) You can store a combination of up to 40 of your favorite FM/AM radio stations as presets. To listen to Satellite Radio, you’ll need to connect a SIR- IUS Satellite Radio tuner (sold separately) to your Sir- Tune into the FM/AM station that you want to ius-Ready receiver.
  • Page 34 Setting Up the SiriusConnect™ Home Tuner The optional SiriusConnect Home tuner kit includes Display everything for easy home installation, including the Sirius- Connect receiver, indoor/outdoor antenna with 21-foot cable, 8-pin mini DIN connector cable, and an AC power Tuner adapter. See the SiriusConnect Home tuner’s instructions for more information.
  • Page 35 Selecting Channels using the Remote Use / to select “SAT Radio Mode”, and Controller select “SIRIUS”. Pressing cycles through the following options: There are three ways to select SIRIUS Satellite Radio None: channels: Select if you’re not using Satellite Radio. 1.
  • Page 36 ■ Selecting the previously selected channel SIRIUS Parental Lock With SIRIUS Parental Lock, you can lock out channels Press Return to select the previously selected that you do not want to receive and use a 4-digit PIN num- channel. ber to prevent others from unlocking them. Selecting Channels on the AV Receiver Press Receiver followed by Setup.
  • Page 37 Use / to select “Parental Lock”, and then press to select a number on the screen, and Enter. then press Enter. The channel number, channel name, and the current Repeat this for each of the four digits in the PIN status are displayed.
  • Page 38 Displaying SIRIUS Satellite Radio Position the SiriusConnect Home antenna so that Information as many bars as possible (up to 3) appear on the Satellite signal strength meter. Press Display repeatedly to cycle through the available information. Antenna Aiming SIRIUS Satellite Terrestrial The following information can be displayed: Channel name and Channel number...

  • Page 39: Using Rds (Australian Models)

    Finding Stations by Type (PTY) Using RDS (Australian models) You can search for radio stations by type. RDS works only in areas where RDS broadcasts are available. Press RT/PTY/TP twice. The current program type appears on the display. When tuned into an RDS station, the RDS indicator lights. Use Preset to select the type of program you want.
  • Page 40 ■ RDS program types (PTY) Type Display None None News reports News Current affairs Affairs Information Info Sport Sport Education Educate Drama Drama Culture Culture Science and technology Science Varied Varied Pop music Pop M Rock music Rock M Middle of the road music Easy M Light classics Light M...

  • Page 41: Recording

    Recording This section explains how to record the selected input source to a component with recording capability, and how to record audio and video from different sources. Connecting a Recording Component Recording Separate AV Sources Here you can record audio and video from completely separate sources, allowing you to overdub audio onto your video recordings.

  • Page 42: Using The Listening Modes

    Using the Listening Modes Selecting Listening Modes See “About Listening Modes” for detailed information about the listening modes (➔ 43). Listening Mode Buttons Press Receiver first. Movie/TV, Music, Game Music Game Movie/TV Movie/TV button This button selects the listening modes intended for use with movies and TV.

  • Page 43: About Listening Modes

    About Listening Modes The AV receiver’s listening modes can transform your listening room into a movie theater or concert hall, with high fidel- ity and stunning surround sound. Explanatory Notes Sp Layout Front speakers Center speaker Surround speakers Listening Mode Subwoofer(s) Surround back speakers Front high speakers...

  • Page 44: Listening Modes

    Listening Modes Listening Mode Description Input Speaker Source Layout Direct In this mode, audio from the input source is output without surround-sound processing. The speaker configuration (presence of speakers), speaker dis- D i r e c t d i o P P o P P tances and A/V Sync settings are enabled, but much of the processing set via Home is disabled.
  • Page 45 Listening Mode Description Input Speaker Source Layout DTS-HD High (Continued from the previous page.) Resolution Audio D T S – H D H R DTS-HD Master Audio D T S – H D M S T R DTS Express D T S E x p r e s s D S D DTS 96/24...
  • Page 46 Listening Mode Description Input Speaker Source Layout Founded by George Lucas, THX develops stringent standards that ensure movies are reproduced in movie theaters and home theaters just as the direc- T H X C i n e m a tor intended. THX Modes carefully optimize the tonal and spatial character- istics of the soundtrack for reproduction in the home-theater environment.
  • Page 47 Listening Mode Description Input Speaker Source Layout Neural Surround This mode employs psychoacoustic frequency domain processing, which allows delivery of a more detailed sound stage, with superior channel separa- N R L S u r r o u n d tion and localization of audio elements.
  • Page 48 Onkyo-Original DSP Listening Modes Listening Mode Description Input Speaker Source Layout Orchestra Suitable for classical or operatic music, this mode emphasizes the surround channels in order to widen the stereo image, and simulates the natural rever- O r c h e s t r a beration of a large hall.

  • Page 49: Advanced Operations

    Advanced Operations Advanced Setup On-screen Setup Menus Common Procedures in Setup Menu This manual describes the procedure using the remote controller unless otherwise specified. Receiver MENU Enter 1. Input/Output Assign / / / 2. Speaker Setup 3. Audio Adjust 4. Source Setup Setup Return 5.

  • Page 50: Input/Output Assign

    Explanatory Notes Note • See “Video Connection Formats” (➔ 22) for charts showing Main Menu Speaker Setup how the “Monitor Out” and “Resolution” settings (➔ affect the video signal flow through the AV receiver. ■ Subwoofer ■ Monitor Out 1ch: Analog: Audio signal is outputted from SW1 jack Select this if your TV is connected to the COMPO-...

  • Page 51: Hdmi Input

    ■ Resolution HDMI Input You can specify the output resolution for the HDMI output If you connect a video component to an HDMI input, you and COMPONENT VIDEO MONITOR OUT and have must assign that input to an input selector. For example, if the AV receiver upconvert the picture resolution as neces- you connect your Blu-ray Disc/DVD player to HDMI sary to match the resolution supported by your TV.

  • Page 52: Component Video Input

    Component Video Input Note • For composite video, S-Video, and component video upconver- If you connect a video component to a component video sion for the HDMI output, the “Monitor Out” setting must be input, you must assign that input to an input selector. For set to other than “Analog”...

  • Page 53: Speaker Setup

    Digital Audio Input Note • To listen to the component connected to the multichannel input, If you connect a component to a digital audio input, you make the selection in the “Audio Selector” in the Home menu must assign that input to an input selector. For example, if (➔...
  • Page 54 ■ ■ Speaker Impedance Powered Zone 2, Powered Zone 3, Powered Zone 4 4ohms: 86). Select if the impedance of any speaker is 4 ohms or See “Setting the Powered Zone 2/3/4” (➔ more but less than 6. ■ Front High + Front Wide 6ohms: Yes: Select if the impedances of all speakers are between...

  • Page 55: Speaker Distance

    ■ ■ Front Double Bass Full Band 40Hz, 45Hz, 50Hz, 55Hz, 60Hz, 70Hz, 80Hz(THX), This setting is NOT set automatically by 90Hz, 100Hz, 110Hz, 120Hz, 130Hz, 150Hz, 200Hz Audyssey MultEQ ® XT32 Room Correction and Speaker Setup function (➔ 29). Note •...

  • Page 56: Level Calibration

    Level Calibration Equalizer Settings This setting is set automatically by This setting is set automatically by ® Audyssey MultEQ XT32 Room Correction and Speaker Audyssey MultEQ XT32 Room Correction and 29). Speaker Setup function (➔ 29). Setup function (➔ Here you can adjust the level of each speaker with the With the Equalizer settings, you can adjust the tone of built-in test tone so that the volume of each speaker is the speakers individually with a 15-band equalizer.

  • Page 57: Audio Adjust

    ■ THX Audio Setup Preserve THX Settings Yes: With the “Surr Back Speaker Spacing” setting, you can Audyssey Dynamic EQ ® specify the distance between your surround back speakers. ® Audyssey Dynamic Volume / Dolby Volume will If you’re using a THX-certified subwoofer, set the “THX not be active in THX listening mode.
  • Page 58 ■ Input Channel PLIIz Height Gain Left + Right: The Height Gain Control in Dolby Pro Logic IIz Both the left and right channels are output. enables the listener to select how much gain is applied to the front high speakers. There are three settings, Left: “Low”, “Mid”...

  • Page 59: Audyssey Dsx

    ■ Volume Leveler Audyssey DSX™ Off: ■ Volume Leveler off. Soundstage Low: –3dB to Reference to +3dB Low Compression Mode becomes active. With this setting, you can adjust the soundstage when using Mid: Audyssey DSX™. Medium Compression Mode becomes active. Note High: •...

  • Page 60: Source Setup

    ■ Direct Dynamic EQ Off: ■ Audyssey Dynamic EQ ® off. Analog Subwoofer Audyssey Dynamic EQ on. Off: The Dynamic EQ indicator will light (➔ Analog audio signals (bass signals) are not output. With Audyssey Dynamic EQ, you can enjoy great sound even when listening at low volume levels.
  • Page 61 ■ Dynamic Volume About Audyssey Dynamic Volume Off: Audyssey Dynamic Volume solves the problem of large Audyssey Dynamic Volume ® off. variations in volume level between television programs, Light: commercials, and between the soft and loud passages of Light Compression Mode becomes active. movies.

  • Page 62: A/V Sync

    IntelliVolume Name input area ■ IntelliVolume 4-4. Name Edit BD/DVD Name –12dB to 0dB to +12dB in 1 dB steps. With IntelliVolume, you can set the input level for each input selector individually. This is useful if one of your –...

  • Page 63: Picture Adjust

    ■ Picture Adjust Picture Mode Custom: Using “Picture Adjust”, you can adjust the picture qual- All settings can be performed manually. ity and reduce any noise appearing on the screen. ISF Day: To view the TV picture while setting, press Enter. To Setting when a room is bright.
  • Page 64 ■ Mosquito NR *2*3*4*6 1080p/24: Select this for 1080p output at 24 frames per second Off: and video conversion as necessary. When the “Mon- Mosquito noise reduction off. itor Out” is set to “Analog”, this setting will be Low: changed to “1080i”. Low mosquito noise reduction.

  • Page 65: Listening Mode Preset

    ■ ■ Blue Contrast *2*4 Analog/PCM With this setting, you can specify the listening mode to –50 to 0 to +50 With this setting you can adjust blue contrast. “–50” be used when an analog (CD, TV, LD, VHS, MD, turn- is the least.

  • Page 66: Miscellaneous

    OSD Setup Miscellaneous ■ On Screen Display Main menu Miscellaneous This preference determines whether operation details are displayed on-screen when an AV receiver function is Volume Setup adjusted. ■ Volume Display Displayed. Absolute: Off: Display range is “Min”, “0.5” through “99.5”, Not displayed.

  • Page 67: Hardware Setup

    1, 2, or 3 signal is output from the HDMI output. You may want to When several Integra/Onkyo components are used in turn this preference on if your TV is connected to the the same room, their remote ID codes may overlap. To...
  • Page 68 ■ ■ HDMI Control(RIHD) Power Control Off: Off: Power Control disabled. disabled. Power Control enabled. enabled. To link the power functions of -compatible com- This function allows -compatible components ponents connected via HDMI, select “On”. connected via HDMI to be controlled with the AV receiver (➔...

  • Page 69: Lock Setup

    Note Note • Perform the firmware update only when an announcement is posted on the Integra web site. See the Integra web site for latest • These settings are disabled when the “Audio TV Out” setting is information. set to “On”...
  • Page 70 Speaker Levels Late Night You can adjust the volume of each speaker while listening With the Late Night function, you can reduce the dynamic to an input source. range of Dolby Digital material so that you can still hear quiet parts even when listening at low volume lev- These temporary adjustments are cancelled when the AV els—ideal for watching movies late at night when you receiver is set to Standby.
  • Page 71 Screen Centered Dialog Audio Selector “Screen Ctr Dialog” is a function for moving the Center You can set priorities of audio output when there are both image of dialog etc. upwards through use of the front high digital and analog inputs. speaker to fix the image to the display height.
  • Page 72 Setting the Incoming Digital Signal (Fixed Mode) By pressing Enter while selecting “HDMI”, “COAX”, “OPT” in the “Audio Selector”, you can specify the input signal in the Fixed Mode. Pressing Enter again allows you to return to the “Audio Selector” setting. Normally, the AV receiver detects the signal format auto- matically.

  • Page 73: Net/Usb

    NET/USB About NET Connecting the AV Receiver The AV receiver is network-ready, which means you can To connect the AV receiver to your home network, plug hook it up to your home network with a standard Ethernet one end of a shielded CAT5 Ethernet cable into the AV cable and enjoy the music files stored on your computer or receiver’s ETHERNET port, and plug the other end into a media server.

  • Page 74: Listening To Internet Radio

    Listening to Internet Radio Note • When the NETWORK indicator flashes, confirm that the To receive Internet radio, you must connect the AV Ethernet cable is firmly connected to the AV receiver. receiver to a network with Internet access (➔ 73).

  • Page 75: Playing Music Files On A Server

    Enter the preset name and Internet address (URL). Display WEB Setup Menu Unit Information Preset Internet Radio Network setting Customer Setting Save Refresh Internet Radio Information Name NET/USB Tuner Internet Radio Delete Delete Delete Click “Save” to save the Internet radio station. Enter / / / Registering Presets...

  • Page 76: Windows Media Player 11 Setup

    Random Playback Use / to select an item, and then press Enter. The Random function can only be set while the PLAY A list of music files appears. screen is displayed. To play songs in random order, during playback (or while All Music playback is paused or stopped), press Random.
  • Page 77 ■ Supported Audio File Formats AAC stands for MPEG-2/MPEG-4 Audio. For server playback, the AV receiver supports the follow- • Sampling rates of 8 kHz, 11.025 kHz, 12 kHz, 16 kHz, ing music file formats: MP3, WMA, WAV, FLAC, Ogg 22.05 kHz, 24 kHz, 32 kHz, 44.1 kHz, 48 kHz, 64 kHz, Vorbis, AAC and LPCM.

  • Page 78: Remote Playback From Media Server/Personal Computer

    Server Requirements Remote Playback from Media Server/Personal Computer The AV receiver can play digital music files stored on a computer or media server and supports the following tech- Remote Playback means you can play the music files nologies: stored on the DLNA-certified device such as media server •...

  • Page 79: Network Settings

    Using Remote Playback Adjusting the Volume You can adjust the volume of your AV receiver by adjusting the volume bar in the “Remote playback” Start Windows Media Player 12. window. The default maximum volume for the AV Before remote playback, setup on Windows Media receiver is 82 (0dB).
  • Page 80 ■ IP Address Use / to select “Hardware Setup”, and then If you set the “DHCP” setting to “Disable”, you must press Enter. specify an IP address. Enter a static IP address provided The “Hardware Setup” menu appears. by your ISP. The IP address must be within the following ranges.

  • Page 81: About Usb

    USB port Plug your USB mass storage device into the AV receiver’s USB port. (DTR-80.2) Press NET/USB repeatedly to select the “USB(Front)” or “USB(Rear)” screen. (DTR-70.2) Press NET/USB repeatedly to select the “USB” screen. USB(Front) USB Storage Supported Audio File Formats For USB mass storage device playback, the AV receiver supports music file formats.
  • Page 82 Random Playback Use / to select a music file, and press Enter or The Random function can only be set while the PLAY to start playback. screen is displayed. Playback starts and the following screen appears. To play songs in random order, while the list of songs is displayed, press Random.

  • Page 83: Multi Zone

    Multi Zone In addition to your main listening room, you can also enjoy playback in the other room, or as we call Multi Zone. And, you can select a different source for each room. Connecting Your Zone 2 Speakers to an Connecting Zone 2 Amp in Zone 2 There are two ways you can connect Zone 2 speakers:...

  • Page 84: Connecting Zone 3

    Zone 2 Video Output Connecting Zone 3 The AV receiver features a composite video output for There are two ways you can connect Zone 3 speakers: connection to a TV in Zone 2, so you can enjoy both audio 1. Connect them directly to the AV receiver. and video in that zone.

  • Page 85: Connecting Zone 4

    Connecting Your Zone 3 Speakers to an Connecting Zone 4 Amp in Zone 3 Connecting Your Zone 4 Speakers Directly This setup allows 9.2-channel playback in your main lis- to the AV receiver tening room and 2-channel stereo playback in Zone 3, with a different source in each room.

  • Page 86: Setting The Powered Zone 2/3/4

    Setting the Powered Zone 2/3/4 Setting the Multi Zone If you’ve connected your Zone 2/3/4 speakers to the AV Press Receiver followed by Setup. receiver, as explained in “Connecting Your Zone 2 Speak- The main menu appears onscreen. ers Directly to the AV receiver” (➔...

  • Page 87: Using Zone 2/3/4

    ■ Zone 2 Power On Volume, Using Zone 2/3/4 Zone 3 Power On Volume, Zone 4 Power On Volume This section explains how to turn Zone 2/3/4 on and off, Last, Min, 1 to 99 or Max (Absolute display) how to select an input source for Zone 2/3/4, and how to adjust the volume for Zone 2/3/4.
  • Page 88 Controlling Zone 2/3/4 with the Remote Adjusting the Volume for Zones Controller On the remote controller, press Zone repeatedly, Standby and then use VOL / . Zone On the AV receiver, press Zone 2, Zone 3 or Zone 4 (the Zone 2/3/4 indicator and Zone 2/3/4 Input selector on the display flashes) and press Zone Selector...

  • Page 89: Using The 12V Triggers

    Using the 12V Triggers Use / to select “12V Trigger A, B, or C Setup” and then press Enter. The 12V triggers A, B, and C can be used to turn on 12V The “12V Trigger A/B/C Setup” screen appears. trigger-capable components automatically when they are selected as the input source.

  • Page 90: Using The Remote Controller In Zone 2/3/4 And Multiroom Control Kits

    Using a Multiroom Kit with a Cabinet Using the Remote Controller in Zone 2/3/4 and Multiroom Control Kits In this setup, the IR receiver picks up the infrared signals from the remote controller and feeds them to the AV To control the AV receiver with the remote controller receiver located in the cabinet via the connecting block.

  • Page 91: Controlling Ipod & Other Components

    Controlling iPod & Other Components Controlling iPod Press NET/USB repeatedly to select the USB Connecting the iPod Directly to the input. USB Port Connect the USB cable that comes with the USB can be used to play music files stored on iPod/iPhone to the USB port at the front of the AV iPod/iPhone, which can be plugged into the AV receiver’s receiver.

  • Page 92: Connecting An Onkyo Dock

    Extended Mode control The content information is displayed (lists are displayed) • Songs • Composers on the on-screen, and you can select and manipulate the • Shuffle Songs content while looking at the screen. • Now Playing Top screen list: Displays a list.

  • Page 93: Using The Onkyo Dock

    ■ Using Your iPod models Alarm Clock Using the Onkyo Dock You can use your iPod models Alarm Clock function to automatically turn on your iPod and the AV receiver at a Dock is sold separately. specified time. The AV receiver’s input source will auto- For the latest information on the Onkyo Dock compo- matically be set to the Port selector.

  • Page 94: Controlling Your Ipod

    ■ System Function ■ Operating Notes Auto Power On • Use the AV receiver’s volume control to adjust the playback If you press the remote controller’s while the AV volume. receiver is on Standby, the AV receiver will automatically • While your iPod is inserted in the RI Dock, its volume con- turn on, select your iPod as the input source, and your trol has no effect.
  • Page 95 ✔: Available buttons Press the appropriate Remote Mode first. Onkyo Dock Buttons ✔ On, Standby ✔ Top Menu ✔ ✔ / / / Enter ✔ ✔ Playlist ✔ ✔ ✔ ✔ Repeat ✔ ✔ Random ✔ ✔ Play Mode ✔ ✔...

  • Page 96: Controlling Other Components

    For details on controlling these components, see the pages indicated. Use / / / to select a character, and then press Enter. BD/DVD Integra/Onkyo Blu-ray Disc player (➔ Repeat this step from the 1st character to the 3rd Tape Integra/Onkyo cassette tape deck with character of the brand name.
  • Page 97 When you searched for the model, a message “Successful” will appear. Now the transfer is • If you cannot access the database, a message “Cannot successful! connect to database.” will appear. Press Enter to Go to step 15. return to the previous step. •...

  • Page 98: Entering Remote Control Codes

    • The remote control codes provided are correct at the time of printing, but are subject to change. If you want to control an Integra/Onkyo component by pointing the remote controller directly at it, or you want to control an Integra/Onkyo component that’s not connected , use the following remote control codes: •...

  • Page 99: Resetting Remote Mode Buttons

    Resetting Remote Mode Buttons You can reset a Remote Mode to its default remote con- trol code. While holding down Remote Mode that you want to reset, press and hold down Home until Remote Mode button lights (about 3 seconds). Within 30 seconds, press Remote Mode again.
  • Page 100 ✔: Available buttons Press the appropriate Remote Mode first. Components Buttons ✔ ✔ ✔ ✔ ✔ ✔ On, Standby ✔ , Input, TV VOL / ✔ ✔ ✔ Guide ✔ Top Menu ✔ ✔ ✔ ✔ ✔ / / / Enter ✔...

  • Page 101: Activities Setup

    ■ Source Power On Activities Setup Enable: Via onscreen menu, you can specify what actions will be Source component will turn on. taken by the Easy macro command in the Easy macro Disable: mode (➔ 28). Source component will not turn on. This option enables the source component to turn Press Receiver followed by Setup.

  • Page 102: Learning Commands

    Press Enter. Learning Commands A message for transfer will appear. The AV receiver’s remote controller can learn the com- 8–2. Activities Setup My Movie mands of other remote controllers. By transmitting, for example, the Play command from your CD player’s remote controller, the remote controller can learn it, and Now we are ready to transfer data to the remote.

  • Page 103: Using Normal Macros

    Press the buttons whose actions you want to pro- are preprogrammed with commands for controlling gram into the macro in the order you want them Integra/Onkyo CD players, cassette decks, and DVD players. performed. However, they can learn new commands, and you can restore the For the CD example above, you’d press the following...

  • Page 104: Others

    Others Troubleshooting If you have any trouble using the AV receiver, look for a Audio solution in this section. If you can’t resolve the issue your- ■ self, contact the dealer from whom you purchased this There’s no sound, or it’s very quiet unit.
  • Page 105 ■ Only the center speaker produces sound Depending on the input signal, some listening modes 43–48 cannot be selected. If you use the Dolby Pro Logic IIx Movie, Dolby Pro — Logic IIx Music, or Dolby Pro Logic IIx Game lis- ■...
  • Page 106 ■ The beginning of audio received by an HDMI IN If your TV is connected to the analog outputs, set the can’t be heard “Monitor Out” setting to “Analog”. Since it takes longer to identify the format of an — ■...
  • Page 107 ■ Can’t control other components Music Server and Internet Radio If it’s an Integra/Onkyo component, make sure that ■ Can’t access the server or Internet radio cable and analog audio cable are connected properly. Connecting only an cable won’t work.
  • Page 108 1. While holding down the input selector button for the input reach up to a maximum of 30W (DTR-80.2)/ source that you want to set, press Setup. 90W (DTR-70.2): 2. Use to change the setting. 1. You are using the Universal Port jack.
  • Page 109 Important Note Regarding Video Playback The AV receiver can upconvert component video, S-Video, and composite video sources for display on a TV connected to the HDMI output. However, if the picture quality of the source is poor, upconversion may make the picture worse or disappear altogether.

  • Page 110: Specifications (Dtr-80.2)

    Specifications (DTR-80.2) Amplifier Section Tuner Section Rated Output Power FM Tuning Frequency Range (North American) All channels: (North American) 145 watts minimum continuous power 87.5 MHz - 107.9 MHz per channel, 8 ohm loads, 2 channels (Australian) driven from 20 Hz to 20 kHz, with a 87.5 MHz - 108.0 MHz, RDS maximum total harmonic distortion of 0.05% (FTC)
  • Page 111 ■ Audio Inputs Digital Optical: 3 (Rear), 1 (Front) Coaxial: 3 Analog BD/DVD, VCR/DVR, CBL/SAT, GAME, PC, TAPE, TV/CD, AUX, PHONO Multichannel Inputs ■ Audio Outputs Analog VCR/DVR, TAPE, ZONE 2 PRE OUT, ZONE 3 PRE OUT Analog Multichannel Pre Outputs Subwoofer Pre Outputs 2 Speaker Outputs Main (L, R, C, SL/Z4L, SR/Z4R, SBL/Z3L,...

  • Page 112: Specifications (Dtr-70.2)

    Specifications (DTR-70.2) Amplifier Section Tuner Section Rated Output Power FM Tuning Frequency Range (North American) All channels: (North American) 140 watts minimum continuous power 87.5 MHz - 107.9 MHz per channel, 8 ohm loads, 2 channels (Australian) driven from 20 Hz to 20 kHz, with a 87.5 MHz - 108.0 MHz, RDS...
  • Page 113 ■ Audio Inputs Digital Optical: 2 (Rear), 1 (Front) Coaxial: 3 Analog BD/DVD, VCR/DVR, CBL/SAT, GAME, PC, TAPE, TV/CD, AUX, PHONO Multichannel Inputs ■ Audio Outputs Analog VCR/DVR, TAPE, ZONE 2 PRE OUT, ZONE 3 PRE OUT Analog Multichannel Pre Outputs Subwoofer Pre Outputs 2 Speaker Outputs Main (L, R, C, SL/Z4L, SR/Z4R, SBL/Z3L,...

  • Page 114: About Hdmi

    About HDMI Designed to meet the increased demands of digital TV, HDMI (High Definition Multimedia Interface) is a new digital interface standard for connecting TVs, projectors, Blu-ray Disc/DVD players, set-top boxes, and other video compo- nents. Until now, several separate video and audio cables have been required to connect AV components. With HDMI, a single cable can carry control signals, digital video, and up to eight channels of digital audio (2-channel PCM, multichan- nel digital audio, and multichannel PCM).

  • Page 115: Using An Rihd-Compatible Tv, Player, Or Recorder

    , which stands for Remote Interactive over HDMI, is the name of the system control function found on Integra/Onkyo components. The AV receiver can be used with CEC (Consumer Electronics Control), which allows sys- tem control over HDMI and is part of the HDMI standard. CEC provides interoperability between various components, however, operation with components other than -compatible components cannot be guaranteed.
  • Page 116 ■ How to connect and setup Confirm the settings. 1. Turn on the power for all connected components. Confirm the connecting and setting. 2. Turn off the power of the TV, and confirm that 1. Connect the HDMI OUT MAIN jack to the the power of the connected components is turned HDMI input jack of the TV.

  • Page 117: Firmware Update

    Note that the Firmware Update option will be grayed whatsoever. out about 50 seconds after AV receiver is turned on. Please wait. Select “Via NET” and press Enter. See the Integra web site for latest information.
  • Page 118 Do not use On or Standby on the remote controller. sources, turn off and on the AV receiver. Then retry the Congratulations!! Now you have the latest firmware update. on your Integra AV receiver. Case6: If you do not have a wired connection to the network, Troubleshooting 120).

  • Page 119: Updating The Firmware Via Usb

    * Do not use ON or STANDBY on the remote control- there is any data in the USB storage, remove it. ler. Download the firmware file from the Integra Press On/Standby to turn on the AV receiver. web site. The file name is as follows: Congratulations!! Now you have the latest firm- ONKAVR0001_*******.zip...
  • Page 120 Others Retry the update procedure from the begin- ning. If the error persists, please contact Integra Support and provide the error code. Case3: If an error occurs during updating process, disconnect then reconnect the AC power cord and try again.

  • Page 121: Video Resolution Chart

    Video Resolution Chart The following tables show how video signals at different resolutions are output by the AV receiver. NTSC/PAL ✔: Output Output HDMI 1080p/24 1080p 1080i 720p 480p/ 480i/ SXGA XGA SVGA Input 576p 576i ✔ ✔ ✔ ✔ ✔...
  • Page 122 Memo...
  • Page 123 Memo...
  • Page 124 Integra Division of ONKYO U.S.A. CORPORATION 18 park Way, Upper Saddle River, N.J. 07458, U.S.A. Tel: 800-225-1946, 201-818-9200 Fax: 201-785-2650 http://www.integrahometheater.com Integra Division of ONKYO CORPORATION Sales & Product Planning Div.: 2-1, Nisshin-cho, Neyagawa-shi, OSAKA 572-8540, JAPAN Y1007-1 Tel: 072-831-8023 Fax: 072-831-8163 SN 29400442 (C) Copyright 2010 ONKYO CORPORATION Japan.

This manual is also suitable for:

Dtr-80.2

Table of Contents

Save PDF
