AV Receiver
DTR-7.1
Instruction Manual
Thank you for purchasing the Integra AV Receiver.
Please read this manual thoroughly before making
connections and turning on the power.
Following the instructions in this manual will enable you
to obtain optimum performance and listening
enjoyment from your new AV Receiver.
Please retain this manual for future reference.
Contents
Before using
Facilities and connections
Setting OSD menu
Enjoying music or videos
Remote controller
Appendix
2
8
28
48
56
68

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DTR-7.1 and is the answer not in the manual?

Questions and answers

Related Manuals for Integra DTR-7.1

Summary of Contents for Integra DTR-7.1

  • Page 1 AV Receiver DTR-7.1 Instruction Manual Thank you for purchasing the Integra AV Receiver. Please read this manual thoroughly before making connections and turning on the power. Following the instructions in this manual will enable you to obtain optimum performance and listening enjoyment from your new AV Receiver.

  • Page 2: Before Using Important Safeguards

    WARNING: TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE. CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK). NO USER-SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.

  • Page 3: Precautions

    3. AC Fuse The fuse is located inside the chassis and is not user-serviceable. If power does not come on, contact your Integra/Onkyo authorized ser- vice station. 4. Care From time to time you should wipe the front and rear panels and the cabinet with a soft cloth.

  • Page 4: Table Of Contents

    5-3. OSD Position sub-menu ... 47 Enjoying music or videos Enjoying music in the remote zone ... 48 Controlling the DTR-7.1 from the remote zone ... 48 Controlling the DTR-7.1 without the remote controller ... 48 Listening to Radio Broadcasts ... 49 Listening to FM/AM Radio Stations ...

  • Page 5: Supplied Accessories

    Controlling an Integra/Onkyo DVD player ... 60 SAT, CABLE, VCR, and TV MODE buttons ... 60 Supplied accessories Check that the following accessories are supplied with the DTR-7.1. AM loop antenna × 1 Remote controller × 1 Batteries (AA, R6 or UM-3) × 2...

  • Page 6: Features

    Features I THX Surround EX ® I THX ® Select Certified I Dolby ® Digital, DTS ® , Dolby I Theater-Dimensional I Cinema Re-EQ Circuitry I 100 W×2 (Front), 100 W (Center), 100 W×2 (Surround), 100 W (Surround Back) at 8 Ω, 20Hz-20kHz, 0.08% THD (FTC) I Wide Range Amplifier Technology (WRAT) I All Discrete Output Stage...

  • Page 7: Before Using This Unit

    • The life of the batteries supplied is about six months but this will vary depending on usage. Using the remote controller DTR-7.1 Point the remote controller toward the remote control sensor. The STANDBY indicator lights up when the unit receives a signal from the remote controller.

  • Page 8: Front Panel Facilities

    Front panel facilities Here is an explanation of the controls and displays on the front panel of the DTR-7.1. Front panel Standby/On Standby Zone 2 Power O f f Rec Out Zone 2 Phones Audio Selector Front panel display See illustration below...

  • Page 9: Front Panel

    Rec Out is selected. Rec Out/Zone 2 buttons These buttons allow you to use the DTR-7.1 to output to a remote zone (Zone 2) or to another component for recording purposes (Rec Out). Press the Rec Out button to output the audio and video signals to a recording component for recording purposes.

  • Page 10: Front Panel Display

    Menu button Press to bring up the OSD menu. The OSD menu will apear on the TV monitor as well as the front display on the DTR-7.1. buttons When selecting items in the OSD Menu, press these buttons to move the on-screen cursor (or the highlighted portion) upward and downward.

  • Page 11: Remote Controller

    Displays the component being operated or the operation status. ON/STNBY button ON: Turns on the DTR-7.1. STNBY: Places the DTR-7.1 in the standby state. Be aware that pressing the STNBY button only places the DTR- 7.1 in standby and does not turn the power completely off.

  • Page 12: Rear Panel Facilities

    Rear panel facilities Here is an explanation of the terminals found on the rear of the DTR-7.1 and how they are used. Before connecting your audio and video components, be sure to read this section carefully and then proceed to the explanations on how to connect each individual component (see pages 16).
  • Page 13 • The RC-418M remote controller does not support turntables. • If the connected component has two z connectors, you can use either one to connect to the DTR-7.1. The other one can be used to daisy chain with another component.
  • Page 14 The DTR-7.1 is supplied with AC mains outlets for connecting the power cords from other devices so that their power is supplied through the DTR-7.1. By doing this, you can use the STANDBY/ ON button on the DTR-7.1 to turn on and off the connected devices as well. Caution:...
  • Page 15 (supplied) • Do not use a power cord other than the one supplied with the DTR-7.1. The power cord supplied is designed for use with the DTR-7.1 and should not be used with any other adevice. • Never have the power cord disconnected from the DTR-7.1 while the other end is plugged into the wall outlet.

  • Page 16: Example Of How To Connect Your Equipment

    Example of how to connect your equipment Tape deck, MD recorder, DAT deck, CD recorder, (TAPE) 3. Refer to page 18 CD player (CD) 2. Refer to page 18 Turntable (PHONO) 1. Refer to page 18 Analog signal Digital signal Signal flow DVD recorder or other digital video...

  • Page 17: Standard Connections

    Standard connections Here is explanation of how to connect the main components to the DTR-7.1 in the standard manner. There are many ways that any one component can be connected, and it is up to you to decide which method best fits your situation. The directions given here are only one option and should only be thought of as such.

  • Page 18: Connecting Your Audio Components

    Using an RCA-type video connection cable, connect the video output terminal (composite) on the device to the DVD VIDEO IN jack on the DTR-7.1. If there is an S video output terminal on the device, connect it to the DVD S VIDEO IN jack using an S video cable.
  • Page 19 Using an RCA-type video connection cable, connect the video output terminal (composite) on the satellite tuner or television to the VIDEO 3 IN jacks on the DTR-7.1. If there is an S video output terminal on the satellite tuner or television, connect it to the S VIDEO 3 IN jack using an S video cable.

  • Page 20: Connecting Speakers

    Connecting speakers Before connecting the speakers, place them correctly by consulting the instruction manuals that came with them. For surround playback, the configuration and placement of your speakers are very important. For THX surround EX playback, we recommend that you use a THX speaker system that is certified by Lucasfilm Ltd.

  • Page 21: Connecting Speakers

    Connecting speakers Connecting speakers Notes: • The DTR-7.1 is designed to produce optimum sound quality when speakers with impedances within the specified ranges are connected. Check the following information and choose speakers with appropriate impedances for the connections. CAUTION: SPEAKER IMPEDANCE 6 min.

  • Page 22: Connecting Antennas

    Connecting antennas To the use the tuner of DTR-7.1, it is necessary to prepare the supplied FM and AM antennas. • Adjustment and placement of the FM and AM antennas for better reception must be done while listening to a station broadcast.

  • Page 23: Connecting An Fm Outdoor Antenna

    Connecting antennas Connecting an FM outdoor antenna Please make sure that you follow the considerations: • Keep the antenna away from noise sources (neon signs, busy roads, etc.). • It is dangerous to put the antenna close to power lines. Keep it well away from power lines, transformers, etc.

  • Page 24: Connecting To The Remote Zone Input

    Connecting to the remote zone (Zone 2) input Outline The IR IN ZONE 2 input allows you to control the DTR-7.1 from the remote zone (Zone 2) with the remote controller even though the remote zone is physically separated. The diagram below shows how to make the proper connections for the remote zone.

  • Page 25: When Using The Zone 2 Out Terminals

    Connecting to the IR IN MAIN input Outline If the DTR-7.1 is located inside a cabinet or other enclosure where the infrared beams from the remote controller cannot enter, then operation with the remote controller will not be possible. In such a...

  • Page 26: Connecting Power Amplifiers And Two Surround Back Speakers

    Front left speaker To connect two surround back speakers, connect a power amplifier to the PRE OUT SURR BACK terminals on the DTR-7.1, and connect the surround back speakers to that power amplifier. You will also need to make the appropriate setting in the OSD Menu: Speaker Setup →...

  • Page 27: Connecting The Power

    Turning the power on from the remote controller: Before you can use the remote controller, you must perform steps 1 and 2 above and place the DTR-7.1 in the standby state. 1. Press the AUDIO MODE button. 2. Press the ON button to turn on the DTR-7.1 (take it out of the standby state).

  • Page 28: The On-Screen Display (Osd) Menu

    The On-Screen Display (OSD) menu The OSD menu is a settings menu that is displayed on your TV monitor and allows you to perform your speaker settings, setup your input sources, set the listening modes, and much more. In most situations, you will only need to set this once during the installation and layout of your home theater, and it rarely needs to be changed later.

  • Page 29: Navigating Through The Osd Menu

    In addition to the display of the OSD Menu on your television monitor, the corresponding menu will also be displayed in the front display on the DTR-7.1. The buttons on the remote controller correspond to those on the DTR-7.1 as shown below.

  • Page 30: Speaker Setup

    Speaker Setup 1. Speaker Setup menu After you have installed the DTR-7.1, connected all the components, and determined the speaker layout, it is now time to perform the settings in the Speaker Setup menu for the optimum sound acoustics for your environment and speaker layout.

  • Page 31: Speaker Distance Sub-Menu

    Here you will enter the distance from each speaker to your normal listening position (Loudspeaker Position Time Synchronization*). This is important for the timing of the acoustics to create the proper sound space that the DTR-7.1 and today’s sound systems are able to produce. Note: Speakers that you selected “No”...

  • Page 32: Level Calibration Sub-Menu

    Left h.Subwoofer Calibrating the speaker levels (1) When this sub-menu is entered, the DTR-7.1 will emit a pink noise from the front left speaker. At this time, the Master volume automatically increases to the reference level (0dB). Remember the level of this noise and then press the button.

  • Page 33: Bass Peak Level Sub-Menu

    Speaker Setup 1-4. Bass Peak Level (Bass Peak Level Manager*) sub-menu Setting the bass peak level is important to keep your subwoofer from being damaged by preventing it from outputting over a set volume. If your subwoofer has a built-in limiter, set this setting to “Off.”...

  • Page 34: Input Setup

    2. Input Setup menu This menu allows you to setup the various input sources available with the DTR-7.1. Each input source may have a great number of settings that are difficult to keep track of, so we recommend making a chart to record what you have set and for which component to prevent confusion later.
  • Page 35 In such cases, try playing the source in the “DTS” selected. • The DTS indicator on the DTR-7.1 lights while a DTS source is played. When playback finishes and the DTS signal transmission stops, the DTR-7.1 remains in DTS mode and the DTS indicator remains lit.

  • Page 36: Video Setup Sub-Menu

    Input Setup 2-2. Video Setup sub-menu Menu 1.Speaker Setup 2.Input Setup 2.Input Setup Input:DVD 3.Listening Mode Setup 4.Preference a.Audio Setup 2-2.Video Setup 5.OSD Setup b.Video Setup Input:DVD c.Listening Mode Preset d.Tone Control a.Video e.IntelliVolume f.12V Trigger b.Component Video |ENTER| Quit:|OSD| |ENTER| Quit:|OSD| a.

  • Page 37: Listening Mode Preset Sub-Menu

    Input Setup 2-3. Listening Mode Preset sub-menu With the DTR-7.1, you can set a different listening mode for each different signal type that comes from each input source and also set the parameters for the listening mode itself. For example, if...

  • Page 38: Listening Modes

    Input Setup Listening Modes Stereo This mode has all input sound is output from the left and right front speakers. Direct This mode delivers pure sound with minimum sound quality adjustment and filtration. The sound recorded for the right and left front channels is output to the right and left front speakers only and not output to the subwoofer.
  • Page 39 Input Setup T-D (Theater-Dimensional) For the best enjoyment of your home theater, it is recommended that you have at least front left and right speakers, a center speaker, and surround left and right speakers. However, even if you only have front left and right speakers, you can still enjoy multichannel audio by using this mode.

  • Page 40: Tone Control Sub-Menu

    This sub-menu allows you to make the required settings to turn on the output from the 12V TRIGGER terminal to control another component or device with the DTR-7.1 for each input source. a. 12V Trigger A On: Select to activate the device connected to the 12V TRIGGER Off: Select when no device is connected to the 12V TRIGGER A b.

  • Page 41: Listening Mode Setup

    Dolby D 6.1 e DTS-ES * Surround Back can only be selected when two surround back speakers are connected to the DTR-7.1. 3-4. THX Setup Select this to modify the THX listening modes; the one that is currently set is the one that is modified. The parameters that can be set are shown in the table below.
  • Page 42 Small, Mid-small, Middle, Mid-large, Large * Surround Back can only be selected when two surround back speakers are connected to the DTR-7.1. 3-6. Enhanced 7 Setup Select this to modify the Enhanced 7 listening mode. The parameters that can be set are shown in the table below.

  • Page 43: Description Listening Mode Parameters

    This setting can only be selected when two surround back speakers are connected to the DTR-7.1. Sur L/R+Back: This outputs the sound to both the surround left and right speakers and the surround back speaker.
  • Page 44 Listening Mode Setup Listening angle The listening angle is the angle subtended by the front left and right speakers as seen from the listener. The setting of 20 and 40 degrees are only for nominal purposes, so select the setting that is closest to your actual listening angle.

  • Page 45: Preference

    –32 and +17 decibels. c. Power On Volume This sets a designated volume setting for the DTR-7.1 to be set every time that the power is turned on. This prevents the DTR-7.1 from being turned on while it is set to an extremely high volume and suddenly output very loud sounds.

  • Page 46: Osd Setup

    OSD Setup 5. OSD Setup menu This menu provides settings for you to customize the on-screen display (OSD) for the DTR-7.1 by setting different colors or positions for its display. Menu 1.Speaker Setup 5.OSD Setup 2.Input Setup 3.Listening Mode Setup 4.Preference...

  • Page 47: Osd Setup Sub-Menu

    OSD Setup 5-2. OSD Setup sub-menu This sub-menu allows you to customize the OSD menu to display in the manner you desire. Menu 1.Speaker Setup 5.OSD Setup 2.Input Setup 3.Listening Mode Setup 4.Preference 5-2.OSD Setup 1.OSD Config 5.OSD Setup 2.OSD Setup 3.OSD Position a.Background Color :Blue1...

  • Page 48: Enjoying Music In The Remote Zone

    SSC dial to adjust the volume to the desired level. When an amplifier is connected to the ZONE 2 OUT terminals, you cannot adjust the volume at the DTR-7.1. Adjust the volume at the amplifier in the remote zone (Zone 2). Caution:...

  • Page 49: Listening To Radio Broadcasts

    VCR 2 Listening to FM/AM Radio Stations One of the features of the DTR-7.1 that is most frequently used is its ability to play FM and AM broadcast radio stations. The DTR- 7.1 provides a number of listening modes perfect for listening to the radio and getting the most out of your audio system.

  • Page 50: Presetting A Radio Station

    Listening to Radio Broadcasts Presetting a radio station 1. Tune into the radio station you desire (see “Tuning into a radio station” ). 2. Press the Character/Memory button on the front panel. “Preset in?” appears in the front display. Press the SSC dial. 3.

  • Page 51: Enjoying Music Or Videos With The Dtr-7.1

    Input source buttons Phones Though the DTR-7.1 is often used to listen to the radio, it does not show you its true ability until it is used to play music or watch videos, LDs, DVDs, and the like. The DTR-7.1 has the latest in state-of-the-art features to play back today’s acoustic technologies...

  • Page 52: Using The Many Features Of The Dtr-7.1

    Using the sleep time: To set the sleep timer, press the SLEEP button on the remote controller and then set the time that you want the DTR-7.1 to enter the standby state (see page 57). Temporarily turning off the sound:...

  • Page 53: Recording A Source

    Zone 2 Phones Of course the DTR-7.1 can also be used to record an input source media. This allows you to make copies of the music or videos you like, copy them from one type of media to another, or even record what is being broadcast on television or radio.

  • Page 54: To Record An Input Source Signal Different From That You Are Currently Watching Or Listening To

    Recording a source To record an input source signal different from that you are currently watching or listening to This method outputs to the audio and video outputs the signal from the input source that you select here. This allows you to record an input source signal different from that which you are listening to or watching at the time of recording.

  • Page 55: Giving A Name To Each Input Source And Preset Radio Station

    Giving a name to each input source and preset radio station Giving a name to each input source You can program names for each input source (e.g., DVD, CD) and preset channel. Characters available for name entry A B C D E F G H I J K L M N O P Q R S T U V W X Y Z a b c d e f g h i j k l m n o p q r s t u v w x y z 0 1 2 3 4 5 6 7 8 9 –...

  • Page 56: Using Remote Controller

    STNBY button to put it back in the standby mode. When you press the STNBY button on the remote controller, it puts the DTR-7.1 in the standby state but does not turn it completely off. Controlling the DTR-7.1 “AUDIO”...
  • Page 57 LIGHT: Illuminates the buttons. SLEEP: Sets the sleep function. • The SLEEP buttons enables you to set the DTR-7.1 to turn off automatically after a specified time period. If you press it once, the DTR-7.1 will turn off after 90 minutes. Each time it is pressed thereafter, the remaining time until the DTR-7.1 turns off decreases by 10 minutes.

  • Page 58: Controlling An Integra/Onkyo Cd Player

    DIMMER + 10 HOME THEATER CONTROLLER RC-418M The RI connector of the Integra/Onkyo compact disc player must be connected to the DTR-7.1 (see page 13). 1. Press the CD MODE button. CD MODE 2. Press the desired operation button. The...

  • Page 59: Controlling An Integra/Onkyo Cassette Tape Deck

    HOME THEATER CONTROLLER RC-418M Controlling an Integra/Onkyo cassette tape deck The z connector of the Integra/Onkyo cassette tape deck must be connected to the DTR-7.1 (see page 13). 1. Press the AUDIO/TAPE MODE button. “AUDIO” appears in the remote controller display.

  • Page 60: Controlling An Integra/Onkyo Dvd Player

    ENT: Confirm You may also use the following buttons: : Adjusts the volume at the DTR-7.1 MUTING: Activates the muting function at the DTR-7.1 SAT, CABLE, VCR, and TV MODE buttons You may use the following buttons: : Adjusts the volume at the DTR-7.1...

  • Page 61: Programming The Commands Of Remote Controllers For Other Devices Into The Remote Controller

    Programming the commands of remote controllers for other devices into the remote controller The remote controller has two learning functions. One is a normal learning function that enables the remote controller to learn the codes from other remote controllers. The other is a macro learning function that enables you to program of series of operations into the remote controller so that they can all be performed at once by pressing one button.
  • Page 62 Programming the commands of remote controllers for other devices into the remote controller 4. Press and hold down the button (that corresponds to the command you are programming) on the remote controller of the other device until the SEND/LEARN lamp on the remote controller flashes twice and “SAVED”...

  • Page 63: Erasing The Programmed Command From One Button

    Programming the commands of remote controllers for other devices into the remote controller AUDIO MUTING TRACK DISC OPEN/COLSE V – STEREO DIRECT SURROUND Re-EQ CH SEL LEVEL + LEVEL – LATE NIGHT DIMMER + 10 HOME THEATER CONTROLLER RC-418M AUDIO MUTING TRACK DISC...

  • Page 64: Using A Macro Function

    1. Point the remote controller at the DTR-7.1 and 2. Press the MODE MACRO, and verify that the this case, the CD MODE button), press the MODE MACRO button, and then release both buttons.

  • Page 65: Programming The Direct Macro Function

    1. Point the remote controller at the DTR-7.1 and press the DIRECT MACRO button. It may take a while for the macro to finish transmitting, so be sure to continue pointing the remote controller at the device until the SEND/LEARN indicator turns off.

  • Page 66: Erasing A Macro From The Mode Macro Button

    Using a Macro function AUDIO TRACK STEREO DIRECT SURROUND Re-EQ CH SEL LATE NIGHT DIMMER + 10 HOME THEATER CONTROLLER RC-418M DIRECT MACRO MODE buttons AUDIO TRACK STEREO DIRECT SURROUND Re-EQ CH SEL LATE NIGHT DIMMER + 10 HOME THEATER CONTROLLER RC-418M 1.

  • Page 67: Erasing All Commands And Macros That Have Been Programmed

    Using a Macro function AUDIO MUTING TRACK DISC OPEN/CLOSE V – STEREO DIRECT SURROUND LEVEL + Re-EQ CH SEL LEVEL – LATE NIGHT DIMMER + 10 HOME THEATER CONTROLLER RC-418M Macro mode programming memo: MACRO MODE MODE MACRO MACRO ↓ ↓...

  • Page 68: Troubleshooting Guide

    Troubleshooting guide If a problem occurs while you are using the remote controller, first try to operate the controls on the front panel of the DTR-7.1 to make sure that it is not due to a malfunction (or worn out batteries) in the remote controller.

  • Page 69: Fm/Am Tuner

    Troubleshooting guide FM/AM TUNER AM stations cannot be received. • AM loop antenna is not connected. © Connect the included AM loop antenna to the AM antenna terminals. Buzzing noise on AM stations (particularly noticeable at night or with weak stations). •...

  • Page 70: Remote Controller

    • Batteries have worn out. © Replace batteries. • Remote controller is not pointed at the remote sensor of the DTR-7.1. © Point the remote controller at the remote sensor of the DTR-7.1. • Remote controller is too far from the DTR-7.1.

  • Page 71: Specifications

    Specifications AMPLIFIER SECTION Continuous Average Power output (FTC) All channels: 100 W per channel min. RMS at 8 , 2 channels driven from 20 H z to 20 kHz with no more than 0.08% total harmonic distortion. 130 W per channel min. RMS at 6 , 2 channels driven from 1 kHz with no more than 0.1% total harmonic distortion.
  • Page 72 Integra Division of ONKYO U.S.A. CORPORATION 200 Williams Drive, Ramsey, N.J. 07446, U.S.A. Tel: 201-825-7950 Fax: 201-825-8150 E-mail: integra@onkyousa.com Integra Division of ONKYO CORPORATION Sales & Product Planning Div. : 2-1, Nisshin-cho, Neyagawa-shi, OSAKA 572-8540, JAPAN Tel: 072-831-8111 Fax: 072-833-5222...
