9 Specifications

Minimum guaranteed Power
20 Hz - 20 kHz with 0.35% THd, all channels driven
2-ohm
2.7ohm
4-ohm
8-ohm
4-ohm Bridge
8-ohm Bridge
70Vrms Direct
100Vrms Direct
Performance
Input Sensitivity (volts RMS) for rated output
Voltage gain for full rated power at 8 ohms
Frequency Response (20Hz to 20kHz at 1 watt, 20Hz - 20 kHz)
Signal to Noise Ratio below rated full-bandwidth power, A-weighted
Total Harmonic Distortion (THD) at full rated power at 1 kHz
Intermodulation Distortion (IMD) 60 Hz and 7 kHz at 4:1,
from full rated output to –35 dB
Maximum Input Level
Latency
A/D, D/A Converters
Digital Input
Network
DSP
Attenuators
page 46
i-T4x3500Hd
20 Hz - 20 kHz 1 kHz 20ms Burst
3,500W
2,100W
3,800W
2,200W
4,000W
2,400W
1,900W
1,900W
7,000W
4,200W
6,000W
4,800W
2,100W
2,300W
i-T4x3500Hd
Adjustable in 0.1V steps from
1.28V to 8V
37.1 dB to 22.2 dB
± 0.25 dB
> -108 dB
< 0.35%
< 0.06%
+15 dBu or +21 dBu, depending on setting of
maximum input level
1.16 mS at 48 kHz, 1.13 mS at 96 kHz
24-bit 96 kHz Cirrus Logic
AES/EBU, 24-bit, 32-96 kHz.
Onboard sample rate converter.
Onboard HiQnet and TCP/IQ, compatible with
standard 100Mb Ethernet hardware
24-bit conversion with 32-bit, floating-point DSP
processing
Speed-sensitive rotary encoder, 0.5 dB steps,
range 0 to –100 dB.
