Crown DriveCore I-Tech 4x3500 HD Operation Manual page 47

I-Tech HD DriveCore Series Power Amplifiers
9 Specifications
Performance
Damping Factor (8 ohms): 20 Hz to 100 Hz
Crosstalk (below rated power, 20 Hz to 1 kHz)
Common Mode Rejection (CMR) (20 Hz to 1 kHz)
DC Output Offset (Shorted input)
Input Impedance (nominal)
Load Impedance (Note: Safe with all types of loads)
Stereo
Bridge Mono
Required AC Mains
AC Line Connector
Construction
Ventilation
Cooling
Dimensions
Weight
Net
Shipping
Operation Manual
i-T4x3500Hd
> 5000
> 80 dB
> 55 dB, typically > 70 dB
< ± 3 mV
20 kilohms balanced, 10 kilohms unbalanced
2-4-8-16 ohms, 70V/100V
2-4-8 ohms, 70V//100V
Universal AC input, 100-240VAC +-10%,
50/60 Hz. Max. AC mains voltage.
USA, UK, European, Australia, India, Brazil, China
(USA ships with Hubbell L6-30)
i-T4x3500Hd
Flow-through ventilation from front to back
Dual-zone, microprocessor controlled,
continuously variable speed fans
EIA Standard 19-inch rack mount width (EIA
RS-310B), 3.5-inch (8.9-cm) height, 16.95-inch
(43.1-cm) depth behind front mounting surface
29 pounds (13.1 kg)
37 pounds (16.8 kg)
page 47
