PERIODIC MAINTENANCE AND ADJUSTMENT
Removing and installing
panels
The panels shown need to be remo-
ved to perform some of the mainte-
nance jobs described in this chapter.
Refer to this section each time a
panel needs to be removed and insta-
lled.
6
1. Panel A
EAU18771
1
1. Panel B
1
Panel A
To remove the panel
1. Remove the screws, and then
take the panel off.
2
1. Panel A
2. Screw
To install the panel
1. Place the panel in the original
Panel B
To remove the panel
1. Remove the screw, and then take
EAUS1490
1
1. Panel B
2. Screw
To install the panel
1. Place the panel in the original
6-7
position, and then install the
screws.
the panel off.
2
1
position, and then install the
screw.
