LUGGAGE NET
(continued)
Fitting the luggage net
behind the rear seats
(behind the second row rear seats on
the long chassis version)
Inside the vehicle on each side:
– lower cover 2 to access the luggage
net upper mounting rail;
– insert upper rod 3 of the net into the
rail;
6
2
– secure net strap hook 4 to the lower
ring located underneath the luggage
compartment carpet;
– adjust net strap 5 so that it is taut.
Note: cut-out 6 should be on the side of
the centre seat belt feed.
3
5
4
7
If fitted to the vehicle, remove the an-
choring rings 7 before installing a lug-
gage net.
Fitting a luggage net is for-
bidden if there is already a
child seat fitted to the ring
(refer to the information on
Child safety in Section 1).
Risk of injury in the case of an
impact.
3.51
