LED Indicator

The LED indicators give you instant feedback on status of the
converter:
LEDs
Power
(PWR)
100 Mbps
(100)
TX Port (TX)
FX Port (FX)
FDX/COL
TX Port (TX)
FX Port (FX)
LINK/ACT
The optional Management Chassis that can control this Smart
Media Converter through the management system, this Smart
Media Converter can be controlled through Web Browser,
SNMP management utility and terminal emulation program.
State
Steady
Off
Steady
Off
Steady
(FDX)
Lights off Connection in half duplex mode
Blinking
(COL)
Steady

(LINK)

Lights off Not Linking
Blinking
(ACT)
Indication
Power on
Power off
Runs at 100Mbps on TX port
Runs at 10Mbps on TX port
Connection in full duplex mode
FDX stands for FULL-DUPLEX
Data collision
A valid network connection
established
Transmitting or receiving data
ACT stands for Activity
6
