FSG2200HNU
Multiservice Gateway IAD with 802.11n Wireless
Default Login Details
IP Address
https://192.168.1.1
User Name
Admin account: admin
User account: user
Password
Admin account: admin
User account: user
Firmware Version 1.00
www.zyxel.com
Edition 2, 10/2010
www.zyxel.com
Copyright © 2010
ZyXEL Communications Corporation
