Vehicle Connector

The mating connector is
a standard MVCI, High
Density DB-26.
Pin # Function
1 CAN2 Single Wire
2 J1850PWM+
J1850VPW
3 CAN2+
4 Case Ground
5 Signal Ground
6 CAN+ (CAN-C only)
SCI A Engine
5v-20v out
7 ISO-9141 K-line
SCI A Engine
SCI A Trans
SCI B Engine
8 No Connect
9 SCI B Trans
5v-20v out or short-to-ground
10 J1850PWM-
11 CAN2-
5v-20v out
12 SCI B Engine
5v-20v out or short-to-ground
13 5v-20v out
14 CAN- (CAN-C only)
SCI A Trans
5v-20v out
15 ISO L Line
SCI B Trans
Short-to-ground
16 Battery In (150mA @ 12 VDC)
17 Cable ID 2
18 Cable ID 1
23 +5 output (50mA fused)
26 Ground
Robert Bosch LLC

Ethernet Lights

Use the standard Ethernet cable
(black) to connect to an existing
network, or use the crossover
cable (blue with red ends) to
connect directly to a laptop.
Color
Left Green
Right Green

Analog Connector

The 12-bit analog inputs are setup
for an input range of 0 to 27.5VDC
and are electrically protected
against reverse voltage and over
voltage conditions. The Mating
connector is a High Density DB-15
Pin # Function
2 Channel 6
4 Channel 3
6 Battery
Voltage
8 Channel 4
10 Channel 1
12 Channel 5
14 Channel 2
1, 3, 5, Ground
7, 9, 11,
13, 15
Flasher-PRO User's Manual | August 2008
Description
Ethernet Activity
Ethernet Link Light
Direction
In
In
Out (200mA
max)
In
In
In
In
