Polycom CX5000 Deployment Manual page 34

Polycom CX5000 Deployment Guide
Property
HCD1: Initialize
HCD3: Initialize
LCD VERIFY
NANDFLASH VERIFY
NORFLASH VERIFY
OS REV
POST Version
PSTN
RTC VERIFY
SDRAM TEST
System Cable
TOUCHCTL VERIFY
UFN1: Initialize
USBF ENUM STATUS
USBH ENUM STATUS
VDSP ENUM STATUS
When component = VDSP, only the Property, Value2, and Value3 columns are used.
The Property column contains the name of the test. The Value2 column contains the status (PASS |
FAIL | NOT DONE | NA). The Value3 column contains the detailed status code. These entries indicate
the general health of the video subsystem.
Table 19 shows the possible values in the Property, Value2, and Value3 columns when the Component
value is VDSP.
Table 19.
Property
Calibration
Camera ID
Camera Video
30
Value2
PASS | FAIL
PASS | FAIL
PASS | FAIL
PASS | FAIL
NOT DONE
NA
NA
PASS | FAIL
PASS | FAIL
PASS | FAIL
PASS | FAIL
PASS | FAIL
PASS | FAIL
PASS | FAIL
PASS | FAIL
PASS | FAIL
Properties and Values for POST Logging, Component == VDSP
Value2
PASS | FAIL
PASS | FAIL
PASS | FAIL
Value3
the format of 1.0.xxxx.x
Status code
Status code
Status code
Status code
Reserved
Revision number for working version nk.bin in the
format of 1.0.xxxx.x
Reserved
Initialization
Status code
Status code
Status code
Status code
Status code
Status code
Status code
Status code
Value3
OK | FAIL
The camera ID
XXXXX
The health of each of the five cameras. X can be Y or N,
