Figure 9 shows a configuration with the Polycom CX5000 device (1) and three display devices (2).
The circular table is 5 feet in diameter.
2
1
2
2
Figure 9. Circular table with multiple display devices
Figure 10 shows a configuration with a rectangular table in a conference room capable of holding 12 to
16 people, and one display device (3). The table shown is approximately 5 feet x 10 feet. In this
configuration, two satellite microphones (2) are shown connected to the Polycom CX5000 device (1).
1
2
2
3
Figure 10. Rectangular table with one display device
