Using the Polycom CX5000 System
Status
Indicators Description
Indicates whether the
external dial pad is
connected.
Indicates whether a
computer is connected.
Indicates whether a phone
line is connected.
Indicates whether Ethernet
is connected.
Shows the
Backspaces when
length of time
you are using the
in the call.
touch-screen.
Flash button for three-
way calling
and call waiting if
enabled by your
Volume Up and
telephone service
Volume Down
provider.
buttons for adjusting
the volume of the
On/Off Hook button
ringer and speakers.
for placing and
answering phone calls.
Privacy button for
Information button for
muting and unmuting
accessing the tutorial,
the microphone and
software version,
pausing the video.
diagnostics, and
speed dialing.
Microphones
LED Indicators
Description
Blinking green
Call is incoming.
Blinking red
Audio is muted;
video is paused.
Steady green
Call is in progress.
Quick Tips for the
®
Polycom
CX5000
System
1725-64347-001/A
