R
WIRELESS MICROPHONE SYSTEM
rod antenna
(2 rod antenna should be
stretched to the longest.)
PDWN-2100
VHF BAND WIRELESS MICROPHONE RECEIVER
RF A
AF A
VOLUME A
WIRELESS RECEIVER
power source (AC110V) plug
AF A lamp (green)
HOW TO INSERT BATTERY
slide switch of power source
battery cover
2
9V (9F22)
INSTRUCTION
SYSTEM PARTS
RF B
AF B
VOLUME B
RF B lamp (green)
3
dry cell
Point
¢Turn round the battery cover to open.
¢Put in the battery according to the
direction seal. The battery should be
9V and please make sure the correct
direction.
¢Put the slide switch to "ON" to check
the power source, if the pilot lamp
is bright, the microphone is ready.
According to different situation, the battery
can use about 10 hours.
pilot lamp
slide switch
battery room
