TROUBLE SHOOTING
Please read and check the following points before asking for service.
The wireless microphone fails fo work:
--Check the microphone battery by switching the microphone ON. If power LED indicator lights red, replace the battery.
--Check the POWER indicator on the receiver unit is ON. If not, check the mains power adapter is firmly plugged into a working
mains socket.
--Check the amplifier system is ON and the microphone controls set correctly.
--Check the radio microphone jack lead is firmly connected into the output socket on the rear panel of the receiver unit and
into the MIC input socket on your amplifier.
The working range is limited:
--Check the microphone battery condition(see above)
--Check the aerials are fully extended. Adjust the position of the aerials to achieve the best reception.
--Check the settings of the microphone controls on the amplifier. Adjust volume and tone to get the beat sound without any
trace of feedback.
www.pyleaudio.com
R
TWO CHANNELS VHF WIRELESS MICROPHONE
OPEN
R
VHF
P R O F E S S I O N A L
PDWM2700
W I R E L E S S M I C R O P H O N E
SIGNAL-A
AUDIO
POWER
SIGNAL-A
MIN
MAX
USER'S MANUAL
PDWM2700
AUDIO
MIN
MAX
Advertisement
Table of Contents
Related Manuals for Pyle Pro PDWM2700
Summary of Contents for Pyle Pro PDWM2700
- Page 1 TROUBLE SHOOTING PDWM2700 Please read and check the following points before asking for service. The wireless microphone fails fo work: --Check the microphone battery by switching the microphone ON. If power LED indicator lights red, replace the battery. TWO CHANNELS VHF WIRELESS MICROPHONE --Check the POWER indicator on the receiver unit is ON.
- Page 2 Thank you for choosing our VHF wireless microphone system. We strongly suggest that you carefully study these instructions SPECIFICATIONS before attempting to operate the system. CONTENTS A.Overall system B.Receiver 1.Oscillation mode: Quartz controlled 1.Sensitivity: 6dB¦V at SIN >70dB P1--------Precautions 2.Carrier Frequency Range VHF 160~270MHz 2.Image Rejection.
- Page 3 INSTALLATION HANDHELD MICROPHONE UNSCREW BATTERY COVER TO INSERT BATTERY AMPLIFIER SPEAKERS DC 12V ANT.B BALANCED AF.OUT ANT.A BATTERY CONDITION POWER SWITCH POWER COVER RADIO MIC INDICATOR RECEIVER UNIT MAINS POWER ADAPTER 1.Unscrew the battery cover at the end of the microphone. Install the provided 9 volt battery and then close the cover. Make To connect the wireless microphone to your amplifier system: sure to connect with the correct polarity.
- Page 4 BODYPACK TRANSMITTER BODYPACK TRANSMITTER VOLUME CONTROL (HIGH/LOW) ON/OFF MIC IN P R O F E S S I O N A L P D W M 2 7 0 0 W I R E L E S S M I C R O P H O N E SIGNAL-A AUDIO POWER...
