- Page 1 PDWM4300 VHF WIRELESS SYSTEM OPERATION MANUAL PDWM4300 VHF WIRELESS SYSTEM OPERATION MANUAL...
- Page 2 OPERATION MANUAL Avoid exposure of the system to rain or moisture. No user-serviceable parts inside the system. Refer all servicing to a qualified Thank you for buying the PDWM4300 Wireless System. Please technician only. read through these operation instructions so you will know how Handle the wireless system carefully, dropping or other shocks may cause to operate your model properly.
- Page 3 Condenser Microphone(Headset mic/clip-on mic) Antenna: Built-in housing(Handheld transmitter) External(Belt pack transmitter) RF Output: <10mW Spurious: <-40dB Battery: one 9V battery PDWM4300 VHF PROFESSIONAL FOUR CHANNELS WIRELESS MICROPHONE SYSTEM VOLUME VOLUME VOLUME VOLUME AF LEVEL AF LEVEL AF LEVEL AF LEVEL CHANNEL 1...
- Page 4 1. Unscrew the battery cover at the end of microphone, put a 9V battery into compartment with correct polarities, then close the cover. 2. Move "ON/OFF" switch to "ON" position, "PWR" indic ator will light for one s econd and then go off.
- Page 5 Using the supplied audio cable, connect from the MIXED jack socket to the "MIC IN" / "LINE IN" socket on amplifier. Alternatively, you can connect an optional XLR cable from the "XLR MIXED" socket on the receiver to a professional mixer. Connect the mains power adaptor from "DC 15V"...
-
Page 6: Front Panel
FRONT PANEL PDWM4300 VHF PROFESSIONAL FOUR CHANNELS WIRELESS MICROPHONE SYSTEM VOLUME VOLUME VOLUME AF LEVEL AF LEVEL CHANNEL 1 CHANNEL 2 CHANNEL 3 POWER 1. Power Indicator 7. CH-2 AF Indicator 13. CH-2 Volume Control 2. Power Switch 8. CH-3 RF Signal Indicator 14.
