Lift-Off Oven Door; Oven Shelves - GE JMP28GR Use And Care Manual

Oven Shelves

Shelves can be cleaned by hand using soap and water or with an abrasive cleanser.
After cleaning, rinse the shelves with clean water and dry. To remove heavy,
burned-on soil, you may use scouring pads. After scrubbing, wash with soapy
water, rinse and dry. Shelves may also be cleaned in self-cleaning oven, but
will discolor and lose some luster. See the Self-Cleaning section.

Lift-Off Oven Door

The oven door is removable
but it is heavy. You may need
help removing and replacing
the door.
To remove the door, open it a
few inches to the special "stop"
position that will hold the door
open. Grasp firmly on each side
and lift the door straight up and off the hinges.
NOTE: Be careful not to place hands between the
spring hinge and the oven frame as the spring hinge
could snap back and pinch your fingers.
To replace the door, make sure the hinges are in the
"out" position. Position the slots in the bottom of the
door squarely over the hinges. Then lower the door
slowly and evenly over both hinges at the same time.
TO CLEAN THE DOOR:
(Do not immerse door in water.)
Inside of door:
Because the area inside the gasket is cleaned during
the self clean cycle, you do not need to clean this by
hand. Any soap left on the liner causes additional
stains when the oven is heated.
a scouring pad.
26
CARE AND CLEANING
(continued)
Do not rub or clean the
door gasket-the
of the gasket has
an extremely low
resistance to abrasion.
An intact and well-
fitting oven door
gasket is essential for
Inside
Gasket
––-–
' 0,
operation and good
baking results. If you notice the gasket becoming
worn, frayed or damaged in any way or if it has
become displaced on the door, you should have
it replaced.
Outside of door:
Use soap and water to thoroughly clean the top, sides
and front of the oven door. Rinse well. You may also
use a glass cleaner to clean the glass on the outside
of the door.
Spillage of marinades, fruit juices, tomato sauces and
basting materials containing acids may cause
discoloration and should be wiped up immediately.
When surface is cool, clean and rinse.
Do not use oven cleaners, cleansing powders or
harsh abrasives on the outside of the door.
/ 'ki l l m l B
\
/ \
Outside
Gasket
Gasket
