1. Do not install portable or built-in grills in or on a recreational
vehicle, portable trailer, boat or in any other moving installa-
2. Always maintain minimum clearances from combustible
construction, see "Location Requirements" section.
3. The outdoor cooking gas appliance shall not be located under
overhead unprotected combustible construction.
4. This outdoor cooking gas appliance shall be used only
outdoors and shall not be used in a building, garage, or any
other enclosed area.
5. Keep any electrical supply cord and fuel supply hose away
from any heated surfaces.
6. Keep outdoor cooking and appliance area clear and free from
combustible materials, gasoline and other fl ammable vapors
and liquids.
7. Do not obstruct the fl ow of combustion and ventilation air.
Keep the ventilation openings of the cylinder enclosure free
and clear from debris.
8. Inspect the gas cylinder supply hose before each use of the
grill. If the hose shows excessive abrasion or wear, or is cut, it
MUST be replaced before using the grill. Contact your dealer
and use only replacement hoses specifi ed for use with the
grill. If removal of an access plate(s) or opening of a door(s) is
required for this inspection, instructions shall be provided on
how to gain access for the inspection.
9. Visually check the burner fl ames. They should be blue. Slight
yellow tipping is normal for L.P. gas.
10. Check and clean burner/venturi tube for insects and insect
nest. A clogged tube can lead to fi re under the grill.
If the following information is not followed exactly, a fire
causing death or serious injury may occur.
• Do not store a spare LP-gas cylinder under or near this side
• Never fill the cylinder beyond 80 percent full.
This side burner is manufactured for outdoor use only.
For side burners that are to be used at elevations above 2000 feet,
orifice conversion is required. See "Gas Supply Requirements"
It is the responsibility of the installer to comply with the minimum
installation clearances specified on the model/serial rating plate.
The model/serial rating plate can be found on the side panel.
Copies of the standards listed may be
obtained from:
National Fire Protection Association
One Batterymarch Park
Quincy, Massachusetts 02269
CSA International
8501 East Pleasant Valley Rd.
Cleveland, Ohio 44131-5575
Save These Instructions
11. The L.P. gas supply cylinder to be used must be:
• constructed and marked in accordance with the
Specifi cation for L.P. Gas Cylinders of the U.S. Department
of Transportation (DOT) or the National Standard of Canada,
CAN/CSA-B339, Cylinders, Spheres, and Tubes for
Transportation of Dangerous Goods; and Commission.
• provided with a listed overfi lling prevention device.
• provided with a cylinder connection device compatible with
the connection for outdoor grill appliances.
12. Always check connections for leaks each time you connect
and disconnect the L.P. gas supply cylinder. See "Installation
Instructions" section.
13. When the outdoor cooking gas appliance is not in use, the
gas must be turned off at the supply cylinder.
14. Storage of an outdoor gas grill appliance indoors is permis-
sible only if the cylinder is disconnected and removed from the
outdoor gas grill.
15. Cylinders must be stored outdoors and out of the reach of
children and must not be stored in a building, garage, or any
other enclosed area.
16. The pressure regulator and hose assembly supplied with the
outdoor gas grill must be used. A replacement pressure
regulator and hose assembly specifi c to your model is avail-
able from your outdoor grill dealer.
17. The cylinder supply system must be arranged for proper vapor
18. Gas cylinder must include a collar to protect the cylinder valve.
The California Safe Drinking Water and Toxic Enforcement
Act requires the Governor of California to publish a list of
substances known to the State of California to cause cancer,
birth defects, or other reproductive harm, and requires
businesses to warn of potential exposure to such substances.
WARNING: This product contains a chemical known to the
State of California to cause cancer, birth defects, or other
reproductive harm.
This appliance can cause low-level exposure to some of the
substances listed, including benzene, crystalline silica, carbon
monoxide, toluene, and soot.
In the State of Massachusetts, the following installation
instructions apply:
• Installations and repairs must be performed by a qualified or
licensed contractor, plumber, or gasfitter qualified or licensed
by the State of Massachusetts.
• If using a ball valve, it shall be a T-handle type.
• A flexible gas connector, when used, must not exceed 3 feet.
