TRENDnet 14dBi User Manual

Outdoor wireless access point
Hide thumbs Also See for 14dBi:
Table of Contents

Advertisement

Quick Links

Download this manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 14dBi and is the answer not in the manual?

Questions and answers

Related Manuals for TRENDnet 14dBi

Summary of Contents for TRENDnet 14dBi

  • Page 2: Table Of Contents

    Table of Contents Chapter 1. System Overview.......................... 1 1.1 Introduction of TEW-455APBO……………………………………………………………………………………………………….1 1.2 System Concept………………………………………………………………………………………………………………………………2 1.3 Applications in Wireless Network……………………………………………………………………………………………………3 1.4 Product Benefit……………………………………………………………………………………………………………………………….7 1.5 Specification……………………………………………………………………………………………………………………………………8 Wireless Performance Considerations……………………………………………………………………………………….11 Chapter 2. Basic Installation…………………………………………………………………………………………………………………….12 2.1 Hardware Installation……………………………………………………………………………………………………………………12 2.1.1 Package Contents…………………………………………………………………………………………………………………..12 2.1.2 Panel Function Descriptions…………………………………………………………………………………………………..12 2.2 Web Management Interface Instructions………………………………………………………………………………………13 Chapter 3.
  • Page 3 5.1.4 Site Survey……………………………………………………………………………………………………………………………..67 5.2 Access Control List…………………………………………………………………………………………………………………………68 5.2.1 IP Filter Setup…………………………………………………………………………………………………………………………68 5.2.2 MAC Filter Setup…………………………………………………………………………………………………………………….70 5.3 Resource Sharing……………………………………………………………………………………………………………………………71 5.3.1 DMZ……………………………………………………………………………………………………………………………………….71 5.3.2 Virtual Server (Port Forwarding)…………………………………………………………………………………………….72 5.4 System Status…………………………………………………………………………………………………………………………………74 5.4.1 System Overview……………………………………………………………………………………………………………………74 5.4.2 DHCP Clients………………………………………………………………………………………………………………………….78 6. Command Line Interface(CLI)………………………………………………………………………………………………………………79 6.1 Accessing the CLI with Telnet…………………………………………………………………………………………………………79 6.2 Accessing the CLI with SSH Utility…………………………………………………………………………………………………..80 6.3 Using the CLI………………………………………………………………………………………………………………………………….81 Appendix A.

  • Page 4: Chapter 1. System Overview

    User Manual TEW-455APBO High Power Wireless Outdoor PoE Access Point Chapter 1. System Overview 1.1 Introduction of TEW-455APBO The 802.11 b/g compliant TEW-455APDO is an outdoor wireless device that can be used for five different purposes in three different modes. In the AP mode, it can be deployed either as traditional fixed wireless Access Point (AP), or combination of AP and WDS(AP+WDS).

  • Page 5: System Concept

    User Manual TEW-455APBO High Power Wireless Outdoor PoE Access Point 1.2 System Concept The TEW-455APDO is not only designed and used as traditional outdoor AP, but also with rich features tailored for WISP applications. The two-level management capability and access control ease WISP and owners to maintain and manage wireless network in a more controllable fashion.

  • Page 6: Applications In Wireless Network

    User Manual TEW-455APBO High Power Wireless Outdoor PoE Access Point 1.3 Applications in Wireless Network TEW455APBO is a multiple mode system which can be configured either as a wireless gateway or an access point as desired. It also can be used WDS link for Ethernet network expansion. This section depicts different applications on AP Mode, WDS Mode, and CPE Mode.
  • Page 7 User Manual TEW-455APBO High Power Wireless Outdoor PoE Access Point Configuration in WDS Mode (Pure WDS)  An access point can be either a main, relay or remote base station. A main base station is typically connected to a wired network via the Ethernet port. A relay base station relays data between main base stations and relay stations or remote base stations with clients.
  • Page 8 User Manual TEW-455APBO High Power Wireless Outdoor PoE Access Point Example 2 : Point-to-Multi-Point  Example 3 : Multi-Point Repeating bridge ...
  • Page 9 User Manual TEW-455APBO High Power Wireless Outdoor PoE Access Point Configuration in CPE Mode  It can be used as an Outdoor Customer Premises Equipment (CPE) to receive wireless signal over last mile application, helping WISPs deliver wireless broadband Internet service to residents and business customers.

  • Page 10: Product Benefit

    User Manual TEW-455APBO High Power Wireless Outdoor PoE Access Point 1.4 Product Benefit High Adjustable Output Power up to 27dBm (FCC version)/6dBm (EU version)  Topology : Point to Point ; Point to Multi Point  Operation Modes :  Access Point Mode : Pure Access Point Function and Access Point /Bridge(WDS) Function ...

  • Page 11: Specification

    User Manual TEW-455APBO High Power Wireless Outdoor PoE Access Point 1.5 Specification Wireless Architecture Mode  AP Mode  Pure AP Mode   It can be deployed as a tradition fixed wireless Access Point  It allow wireless clients or Stations(STA) to access AP/WDS Mode ...
  • Page 12 User Manual TEW-455APBO High Power Wireless Outdoor PoE Access Point Virtual Server (IP / Port Forwarding)  Support MAC Filter (max 20 entries)  Support IP Filter (max 20 entries)  Bandwidth traffic Shaping  Wireless Feature  Transmission power control : 9 Levels (max 27dBm for FCC, 6dBm for CE) ...
  • Page 13 User Manual TEW-455APBO High Power Wireless Outdoor PoE Access Point 802.11i WPA2 (PSK + CCMP/ AES)  802.11i WPA2 (802.1x certification + CCMP/ AES)  Setting for TKIP/ CCMP/ AES key’s refreshing period  Hidden ESSID support  Setting for “ Deny ANY “ connection request ...

  • Page 14: Wireless Performance Considerations

    User Manual TEW-455APBO High Power Wireless Outdoor PoE Access Point Administrative Access : HTTP/ HTTPS  UPnP (Universal Plug and Play)  1.6 Wireless Performance Considerations There are a number of factors that can impact the range of wireless devices. 1.

  • Page 15: Chapter 2. Basic Installation

    Green LED ON indicates power on, and OFF indicates power off. 3. WLAN: Yellow LED FLASH indicates Wireless Transmit. 4. Ethernet Red LED ON indicates connection, OFF indicates no connection 5. PoE: For connecting to PSE 6. EXT: For connection of optional N-Type antenna (example: TRENDnet TEW-AO19D)

  • Page 16: Web Management Interface Instructions

    User Manual TEW-455APBO High Power Wireless Outdoor PoE Access Point 2.2 Web Management Interface Instructions TEW-455APBO supports web-based configuration. Upon the completion of hardware installation, TEW- 455APBO can be configured through a PC/NB by using its web browser such as Internet Explorer version 6.0 or higher.
  • Page 17 User Manual TEW-455APBO High Power Wireless Outdoor PoE Access Point Launch Web Browser  Launch a web browser to access the web management interface of system by entering the default IP Address, http://192.168.10.100, in the URL field, and then press Enter. System Login ...
  • Page 18 User Manual TEW-455APBO High Power Wireless Outdoor PoE Access Point  Login Success System Overview page will appear after successful login.

  • Page 19: Chapter 3. Ap Mode Configuration

    User Manual TEW-455APBO High Power Wireless Outdoor PoE Access Point Chapter 3. AP Mode Configuration When AP mode is chosen, the system can be configured as an Access Point. This section provides detailed explanation for users to configure in the AP mode with help of illustrations. In the AP mode, functions listed in the table below are also available from the Web-based GUI interface.

  • Page 20: Configure Lan Ip

    User Manual TEW-455APBO High Power Wireless Outdoor PoE Access Point 3.1.2 Configure LAN IP Here are the instructions to setup the local IP Address and Netmask. Please click on System  LAN and follow the below setting. Mode: Check either “Static IP” or “Dynamic IP” button as desired to set up the system IP of LAN port. ...
  • Page 21 User Manual TEW-455APBO High Power Wireless Outdoor PoE Access Point DNS: Check either “No Default DNS Server” or “Specify DNS Server IP” button as desired to set up the  system DNS. Primary: The IP address of the primary DNS server. ...

  • Page 22: Wireless Lan Network Creation

    User Manual TEW-455APBO High Power Wireless Outdoor PoE Access Point 3.2 Wireless LAN Network Creation The network manager can configure related wireless settings, General Settings, Advanced Settings, Virtual AP (VAP) Setting, Security Settings, and Access Control Settings. 3.2.1 Wireless General Setup The administrator can change the data transmission, channel and output power settings for the system.
  • Page 23 User Manual TEW-455APBO High Power Wireless Outdoor PoE Access Point Tx Power: You can adjust the output power of the system to get the appropriate coverage for your wireless  network. Select the LEVEL 1 to LEVEL 9 that you need for your environment. If you are not sure from which setting to choose, then use the default LEVEL 9 setting.

  • Page 24: Wireless Advanced Setup

    User Manual TEW-455APBO High Power Wireless Outdoor PoE Access Point 3.2.2 Wireless Advanced Setup To achieve optimal wireless performance, it is necessary to tweak advance setting per requirements properly, not necessary higher the better or lower. The administrator can change the RTS threshold and fragmentation threshold settings for the system. Please click on Wireless ->...
  • Page 25 User Manual TEW-455APBO High Power Wireless Outdoor PoE Access Point ACK Timeout: ACK timeout is in the range of 1~372 and set in unit of microsecond. The default value is 48  microsecond. All data transmission in 802.11b/g request an “Acknowledgement” (ACK) send by receiving radio.
  • Page 26 User Manual TEW-455APBO High Power Wireless Outdoor PoE Access Point RSSI Threshold: RSSI Threshold is in the range of -128~127.The default value is 24.  RSSI is defined as Received Signal Strength Indication, when the received signal strength from peer is below this threshold, the peer will be consider as disconnected.
  • Page 27 User Manual TEW-455APBO High Power Wireless Outdoor PoE Access Point to occur. The pros is obvious, the cons is the overhead for transmission. So, in a clean environment, higher fragment threshold can be an option to increase throughput. Fragmentation will be triggered by setting the Fragment Threshold, usually in Byte-length. Only when the frame size is over the Threshold, fragmentation will take place automatically.

  • Page 28: Create Virtual Ap (Vap)

    User Manual TEW-455APBO High Power Wireless Outdoor PoE Access Point 3.2.3 Create Virtual AP (VAP) The TEW-455APBO support broadcasting multiple SSIDs, allowing the creation of Virtual Access Points, partitioning a single physical access point into 8 logical access points, each of which can have a different set of security, VLAN tag(ID) and network settings.
  • Page 29 User Manual TEW-455APBO High Power Wireless Outdoor PoE Access Point VAP: Indicate the system's available Virtual AP  ESSID: Indicate the ESSID of the respective Virtual AP  Status: Indicate the Status of the respective Virtual AP. The VAP0 always On ...

  • Page 30: Virtual Ap Setup

    User Manual TEW-455APBO High Power Wireless Outdoor PoE Access Point 3.2.3.2 Virtual AP Setup For each Virtual AP, administrators can configure SSID, VLAN tag (ID), SSID broadcasting, Maximum number of client associations, security type settings. Click Edit button on the VAP Edit column, and then a Virtual AP setup page appears. ESSID: Extended Service Set ID, when clients are browsing for available wireless networks, this is the SSID ...
  • Page 31 User Manual TEW-455APBO High Power Wireless Outdoor PoE Access Point Diffserv/IP TOS and 802.1p will be mapped into 4 Access Categories of WMM, packets without QOS header will be assigned to Best Effort queue, see table below. 802.1p/IP TOS mapping to WMM: Data Transmitted 802.1P Queue...
  • Page 32 User Manual TEW-455APBO High Power Wireless Outdoor PoE Access Point Key Length: The available options are 64 bits, 128 bits or 152 bits.  WEP auth Method: Enable the desired option among Open system and Shared.  Key Index: key index is used to designate the WEP key during data transmission. 4 different WEP ...
  • Page 33 User Manual TEW-455APBO High Power Wireless Outdoor PoE Access Point Cipher Suite: By default, it is TKIP. Select either AES or TKIP cipher suites  Group Key Update Period: By default, it is 600 seconds. This time interval for rekeying GTK, ...
  • Page 34 User Manual TEW-455APBO High Power Wireless Outdoor PoE Access Point authentication. Main and secondary Authentication RADIUS Server Settings :   Authentication Server: Enter the IP address of the Authentication RADIUS server.  Port: By default, it’s 1812. The port number used to communicate with RADIUS server. ...
  • Page 35 User Manual TEW-455APBO High Power Wireless Outdoor PoE Access Point WEP 802.1X: When WEP 802.1x Authentication is enabled, please refer to the following Dynamic WEP  and RADIUS settings to complete configuration. Dynamic WEP Settings :   WEP Key length: The available options are 64 bits or 128 bits. The system will automatically generate WEP encryption keys.
  • Page 36 User Manual TEW-455APBO High Power Wireless Outdoor PoE Access Point  Accounting Server: Enable or Disable accounting features in RADIUS server. Main and secondary Accounting RADIUS Server Settings :   Accounting Server: Enter the IP address of the Accounting RADIUS server. ...

  • Page 37: Mac Filter Setup

    User Manual TEW-455APBO High Power Wireless Outdoor PoE Access Point 3.2.4 MAC Filter Setup Continued from the 3.2.3.1 Virtual AP Overview section, Click Setup button on the MAC Filter Setup column, and then a Virtual AP MAC Filter setup page appears. The administrator can allow or reject clients to access each Virtual AP.

  • Page 38: Wireless Network Expansion

    User Manual TEW-455APBO High Power Wireless Outdoor PoE Access Point 3.3 Wireless Network Expansion The administrator could create WDS Links to expand wireless network. When WDS is enabled, access point functions as a wireless bridge and is able to communicate with other access points via WDS links. A WDS link is bidirectional and both sides must support WDS.
  • Page 39 User Manual TEW-455APBO High Power Wireless Outdoor PoE Access Point Note that VLAN ID in the WDS MAC List setting will only be tagged to egress packets on the wired Ethernet port. Ensure to match VLAN ID used on the network of the peer. WDS link won’t carry tags at all. WMM: By default, it’s “Disable”.
  • Page 40 User Manual TEW-455APBO High Power Wireless Outdoor PoE Access Point Key Length: The available options are 64 bits, 128 bits or 152 bits.  WEP auth Method: Enable the desired option among Open system and Shared.  Key Index: key index is used to designate the WEP key during data transmission. 4 different WEP ...

  • Page 41: System Management

    User Manual TEW-455APBO High Power Wireless Outdoor PoE Access Point 3.4 System Management 3.4.1 Configure Management Administrator could specify geographical location of the system via instructions in this page. Administrator could also enter new Root and Admin passwords and allow multiple login methods. Please click Administrator ->...
  • Page 42 User Manual TEW-455APBO High Power Wireless Outdoor PoE Access Point The system supports two management accounts, root and admin. The network manager is assigned with full administrative privileges, when logging in as root user, to manage the system in all aspects. While logging in as an admin user, only subset of privileges is granted such as basic maintenance.
  • Page 43 User Manual TEW-455APBO High Power Wireless Outdoor PoE Access Point Click “Continue to this website” to access the system's WMI. The system's Overview page will appear.

  • Page 44: Configure System Time

    User Manual TEW-455APBO High Power Wireless Outdoor PoE Access Point 3.4.2 Configure System Time System time can be configured via this page, and manual setting or via a NTP server is supported. Please click on System -> Time Server and follow the below setting. Local Time : Display the current system time.

  • Page 45: Configure Upnp

    User Manual TEW-455APBO High Power Wireless Outdoor PoE Access Point 3.4.3 Configure UPnP Universal Plug and Play (UPnP) is an architecture to enable pervasive peer-to-peer network connectivity between PCs, intelligent devices and appliances when UPnP is supported. UPnP works on TCP/IP network to enable UPnP devices to connect and access to each other, very well adopted in home networking environment.

  • Page 46: Configure Snmp Setup

    User Manual TEW-455APBO High Power Wireless Outdoor PoE Access Point 3.4.4 Configure SNMP Setup SNMP is an application-layer protocol that provides a message format for communication between SNMP manager and agent. By enabling SNMP function, the administrator can obtain the system information remotely.
  • Page 47 User Manual TEW-455APBO High Power Wireless Outdoor PoE Access Point SNMP ro user : Set a community string to authorize read-only access.  SNMP ro password : Set a password to authorize read-only access.  SNMP rw user : Set a community string to authorize read/write access. ...

  • Page 48: Backup / Restore And Reset To Factory

    User Manual TEW-455APBO High Power Wireless Outdoor PoE Access Point 3.4.5 Backup / Restore and Reset to Factory Backup current configuration, restore previously saved configuration or reset back to factory default configuration can be executed via this page. Please click on Utilities -> Profile Setting and follow the below setting. Save Settings To PC : Click Save button to save the current configuration to a local disk.

  • Page 49: Firmware Upgrade

    User Manual TEW-455APBO High Power Wireless Outdoor PoE Access Point 3.4.6 Firmware Upgrade Firmware is the main software image that system needs to respond to requests and to manage real time operations. Firmware upgrades are sometimes required to include new features or bugs fix. It takes around 8 minutes to upgrade due to complexity of firmware.

  • Page 50: Network Utility

    User Manual TEW-455APBO High Power Wireless Outdoor PoE Access Point 3.4.7 Network Utility The administrator can diagnose network connectivity via the PING utility. Please click on Utilities -> Network Utility and follow the below setting. Ping : This utility will help ping other devices on the network to verify connectivity. Ping utility, using ICMP ...

  • Page 51: Reboot

    User Manual TEW-455APBO High Power Wireless Outdoor PoE Access Point 3.4.8 Reboot This function allows user to restart system with existing or most current settings when changes are made. Click Reboot button to proceed and take around three minutes to complete. A reminder will be available for remaining time to complete.

  • Page 52: System Status

    User Manual TEW-455APBO High Power Wireless Outdoor PoE Access Point 3.5 System Status This section breaks down into subsections of System Overview, Associated Clients Status, WDS Link Status, Extra Information and Event Log. 3.5.1 System Overview Display detailed information of System, Network, LAN and Wireless in the System Overview page. System : Display information of the system.
  • Page 53 User Manual TEW-455APBO High Power Wireless Outdoor PoE Access Point Mode : Supports Static or Dynamic modes on the LAN interface.  IP Address : The management IP of system. By default, it’s 192.168.10.100.  IP Netmask : The network mask. By default, it’s 255.255.255.0. ...

  • Page 54: Associated Clients Status

    User Manual TEW-455APBO High Power Wireless Outdoor PoE Access Point 3.5.2 Associated Clients Status It displays ESSID, on/off Status, Security Type, total number of wireless clients associated with all Virtual AP. VAP Information : Highlights key VAP information.  VAP : Available VAP from VAP0 to VAP7. ...

  • Page 55: Wds Link Status

    User Manual TEW-455APBO High Power Wireless Outdoor PoE Access Point 3.5.3 WDS Link Status On/Off Status, peers MAC Address, Received Signal Strength Indicator(RSSI) and Last TX Time for each WDS are available. WDS : Maximum supported WDS links.  Status : On/Off. ...

  • Page 56: Extra Information

    User Manual TEW-455APBO High Power Wireless Outdoor PoE Access Point 3.5.4 Extra Information Users could pull out information such as Route table, ARP table, MAC table, Bridge table or STP available in the drop-down list from system. The “Refresh” button is used to retrieve latest table information. Route table information : Select “Route table information”...
  • Page 57 User Manual TEW-455APBO High Power Wireless Outdoor PoE Access Point Bridge MAC information : Select “Bridge MACs Information” on the drop-down list to display MAC table.  This table displays local MAC addresses associated with wired or wireless interfaces, but also remember non-local MAC addresses learned from wired or wireless interfaces.

  • Page 58: Event Log

    User Manual TEW-455APBO High Power Wireless Outdoor PoE Access Point 3.5.5 Event Log The Event log displays system events when system is up and running. Also, it becomes very useful as a troubleshooting tool when issues are experienced in system. Time: The date and time when the event occurred.

  • Page 59: Chapter 4. Wds Mode Configuration

    User Manual TEW-455APBO High Power Wireless Outdoor PoE Access Point Chapter 4. WDS Mode Configuration Please refer to illustrations of the section 1.3 for possible applications in the WDS mode. This section provides detailed explanation for users to configure in the WDS mode with help of illustrations. In the WDS mode, functions listed in the table below are also available from the Web-based GUI interface.

  • Page 60: Wds Setup

    User Manual TEW-455APBO High Power Wireless Outdoor PoE Access Point 4.1.2 WDS Setup The administrator could create WDS Links to expand wireless network. When WDS is enabled, access point functions as a wireless bridge and is able to communicate with other access points via WDS links. A WDS link is bidirectional and both side must support WDS.
  • Page 61 User Manual TEW-455APBO High Power Wireless Outdoor PoE Access Point Note that VLAN ID in the WDS MAC List setting will only be tagged to egress packets on the wired Ethernet port. Ensure to match VLAN ID used on the network of the peer. WDS link won’t carry tags at all. WDS MAC List ...

  • Page 62: System Status

    User Manual TEW-455APBO High Power Wireless Outdoor PoE Access Point 4.2 System Status This section breaks down into subsections of System Overview, WDS Link Status, Extra Information and Event Log. 4.2.1 System Overview Detailed information on System, Network, LAN Information and Wireless Information can be reviewed via this page.
  • Page 63 User Manual TEW-455APBO High Power Wireless Outdoor PoE Access Point Mode : Supports Static or Dynamic modes on the LAN interface.  IP Address : The management IP of system. By default, it’s 192.168.10.100.  IP Netmask : The network mask. By default, it’s 255.255.255.0. ...

  • Page 64: Wds Link Status

    User Manual TEW-455APBO High Power Wireless Outdoor PoE Access Point 4.2.2 WDS Link Status The administrator can obtain detailed Information such as MAC Address, Signal Strength of all WDS link via this page. WDS : Maximum supported WDS links.  Status : On/Off.

  • Page 65: Chapter 5. Cpe Mode Configuration

    User Manual TEW-455APBO High Power Wireless Outdoor PoE Access Point Chapter 5. CPE Mode Configuration When CPE mode is chosen, the system can be configured as a Customer Premises Equipment (CPE). This section provides detailed explanation for users to configure in the CPE mode with help of illustrations. In the CPE mode, functions listed in the table below are also available from the Web-based GUI interface.

  • Page 66: Configure Wan Setup

    User Manual TEW-455APBO High Power Wireless Outdoor PoE Access Point 5.1.2 Configure WAN Setup There are three connection types for the WAN port : Static IP, Dynamic IP and PPPoE, Please click on System -> WAN and follow the below setting. In CPE mode, the WAN Port is the Wireless interface.
  • Page 67 User Manual TEW-455APBO High Power Wireless Outdoor PoE Access Point Hostname : The Hostname of the WAN port  Static IP : Users can manually setup the WAN IP address with a static IP provided by WISP.  IP Address : The IP address of the WAN port. By default, the IP address is 192.168.1.254 ...
  • Page 68 User Manual TEW-455APBO High Power Wireless Outdoor PoE Access Point DNS : Check “No Default DNS Server” or “Specify DNS Server IP” radial button as desired to set up system  DNS. Primary : The IP address of the primary DNS server. ...

  • Page 69: Configure Ddns Setup

    User Manual TEW-455APBO High Power Wireless Outdoor PoE Access Point 5.1.3 Configure DDNS Setup Dynamic DNS allows you to map domain name to dynamic IP address. Please click on System -> DDNS Setup and follow the below setting. Enable: Default setting is “Disable”. Select “Enable” for the device to automatically update its WAN IP ...

  • Page 70: Site Survey

    User Manual TEW-455APBO High Power Wireless Outdoor PoE Access Point 5.1.4 Site Survey Use this tool to scan and locate WISP Access Points and select one to associate with. Please click on Wireless -> Site Survey. Below depicts an example for site survey. ESSID : Available Extend Service Set ID of surrounding Access Points.

  • Page 71: Access Control List

    User Manual TEW-455APBO High Power Wireless Outdoor PoE Access Point 5.2 Access Control List 5.2.1 IP Filter Setup Allows to create deny or allow rules to filter ingress or egress packets from specific source and/or to destination IP address on wired (LAN) or Wireless (WAN) ports. Filter rules could be used to filter unicast or multicast packets on different protocols as shown in the IP Filter Setup.
  • Page 72 User Manual TEW-455APBO High Power Wireless Outdoor PoE Access Point Active : Deny to drop and Pass to allow per filter rules  Interface : The interface that a filter rule applies  All packets are allowed by default. Deny rules could be added to the filter list to filter out unwanted packets and leave remaining allowed.

  • Page 73: Mac Filter Setup

    User Manual TEW-455APBO High Power Wireless Outdoor PoE Access Point 5.2.2 MAC Filter Setup Allows to create MAC filter rules to allow or deny unicast or multicast packets from limited number of MAC addresses. Important to note that MAC filter rules have precedence over IP Filter rules. Please click on Advance ->...

  • Page 74: Resource Sharing

    User Manual TEW-455APBO High Power Wireless Outdoor PoE Access Point 5.3 Resource Sharing 5.3.1 DMZ DMZ is commonly work with the NAT functionality as an alternative of Virtual Server(Port Forwarding) while wanting all ports of DMZ host visible to Internet users. Virtual Server rules have precedence over the DMZ rule.

  • Page 75: Virtual Server (Port Forwarding)

    User Manual TEW-455APBO High Power Wireless Outdoor PoE Access Point 5.3.2 Virtual Server (Port Forwarding) “Virtual Server” can also referred to as “Port Forward” as well and used interchangeably. Resources in the network can be exposed to the Internet users in a controlled manner including on-line gaming, video conferencing or others via Virtual Server setup.
  • Page 76 User Manual TEW-455APBO High Power Wireless Outdoor PoE Access Point While creating multiple Virtual Server rules, the prior rules have higher priority. The Virtual server rules have precedence over the DMZ one while both rules exist. Example 1 and 2 demonstrate proper usage of DMZ and Virtual Server rules.

  • Page 77: System Status

    User Manual TEW-455APBO High Power Wireless Outdoor PoE Access Point 5.4 System Status This section breaks down into subsections of System Overview, DHCP Clients, Extra Information and Event Log. 5.4.1 System Overview Detailed information on System, WAN Information, LAN Information and CPE Wireless Information can be reviewed via this page.
  • Page 78 User Manual TEW-455APBO High Power Wireless Outdoor PoE Access Point Mode : Supports Static, Dynamic, and PPPoE modes.  Reconnect Mode : The current reconnect mode of the PPPoE.  MAC Address : The MAC address of the WAN port. ...
  • Page 79 User Manual TEW-455APBO High Power Wireless Outdoor PoE Access Point CPE Wireless Information : Display the information of the Wireless interface.  ESSID : Display Extended Service Set ID of the wireless currently.  Security : Display security type of the wireless currently. ...
  • Page 80 User Manual TEW-455APBO High Power Wireless Outdoor PoE Access Point MAC Address : The MAC address of the LAN port.  IP Address : The IP address of the LAN port.  IP Netmask : The IP netmask of the LAN port. ...

  • Page 81: Dhcp Clients

    User Manual TEW-455APBO High Power Wireless Outdoor PoE Access Point 5.4.2 DHCP Clients Users could retrieve DHCP server and DHCP clients’ IP/MAC address via this page. IP address : IP addresses to LAN devices by DHCP server.  MAC address : MAC addresses of LAN devices. ...

  • Page 82: Command Line Interface(Cli)

    User Manual TEW-455APBO High Power Wireless Outdoor PoE Access Point 6. Command Line Interface(CLI) Help, showinfo, pwinfo, set, reboot, default and password functions are available via Telnet session. 6.1 Accessing the CLI with Telnet Follow these steps to access CLI via Telnet in the Windows XP: Click Start ->...

  • Page 83: Accessing The Cli With Ssh Utility

    You could access CLI with SSH Utility. Below is an example using “PuTTY” utility, which is a freeware. Please  see license agreement at this link http://www.chiark.greenend.org.uk/~sgtatham/putty/licence.html . TRENDnet does not provide support and warranty for using this software. Execute Putty.exe to prompt the “PuTTY Configuration“ window. Enter IP address 192.168.10.100 on the ...

  • Page 84: Using The Cli

    User Manual TEW-455APBO High Power Wireless Outdoor PoE Access Point 6.3 Using the CLI After accessing the CLI, the administrator can use command on the system.  Using help command : Display all commands and descriptions  Using showinfo command : Display System and LAN informations ...
  • Page 85 User Manual TEW-455APBO High Power Wireless Outdoor PoE Access Point CPE Mode : Display CPE device(Interface) ath0.  'Q'uit : Type Q to close this utility.  'W'ireless : Type W to open Choose Device window.  'S'ignal : Type S to open Peer MAC Address window. Type the desired MAC address of associated peer ...
  • Page 86 User Manual TEW-455APBO High Power Wireless Outdoor PoE Access Point Using : The used device of system currently.  Watching : The MAC address of specified peer currently.  Signal : Indicate signal strength of specified peer currently.  S'T'op-Signal : Type T to stop display signal strength. ...
  • Page 87 User Manual TEW-455APBO High Power Wireless Outdoor PoE Access Point  Using reboot command : Restart the system  Using default command : Restore system default settings  Using password command : Change root password...

  • Page 88: Appendix A. Web Gui Valid Characters

    User Manual TEW-455APBO High Power Wireless Outdoor PoE Access Point Appendix A. WEB GUI Valid Characters Table A WEB GUI Valid Characters Block Field Valid Characters IP Address IP Format; 1-254 IP Netmask 128.0.0.0 ~ 255.255.255.252 IP Gateway IP Format; 1-254 Primary IP Format;...
  • Page 89 User Manual TEW-455APBO High Power Wireless Outdoor PoE Access Point Block Field Valid Characters Management System Name Length : 32 0-9, A-Z, a-z Space ~ ! @ # $ % ^ * ( ) _ + - { } | : < > ? [ ] / ; ` , . = Description Length : 40 0-9, A-Z, a-z...
  • Page 90 User Manual TEW-455APBO High Power Wireless Outdoor PoE Access Point Block Field Valid Characters General Setup ESSID Length : 31 (CPE Mode) 0-9, A-Z, a-z ~ ! @ # $ % ^ * ( ) _ + - { } | : < > ? [ ] / ; ` , . = WEP Key 10, 26, 32 HEX chars Pre-shared Key...
  • Page 91 User Manual TEW-455APBO High Power Wireless Outdoor PoE Access Point Block Field Valid Characters Description Length : 32 0-9, A-Z, a-z Space ~ ! @ # $ % ^ * ( ) _ + - { } | : < > ? [ ] / ; ` , . = WEP Key 10, 26, 32 HEX chars AES Key...

  • Page 92: Appendix B. Network Manager Privileges

    User Manual TEW-455APBO High Power Wireless Outdoor PoE Access Point Appendix B. Network manager Privileges There are two system management accounts for maintaining the system; namely, the root and admin accounts are with different levels of privileges. The root manager account is empowered with full privilege to Read & Write while the admin manager account is Read only.

  • Page 93: Appendix C. Enabling Upnp In Windows Xp

    User Manual TEW-455APBO High Power Wireless Outdoor PoE Access Point Appendix C. Enabling UPnP in Windows XP Open the “Add/Remove Programs” control panel, and then click on “Add/Remove Windows Components” in the sidebar. Scroll down and find “Networking Services”, highlight it, and then click Details. In the “Networking Services”...
  • Page 94 User Manual TEW-455APBO High Power Wireless Outdoor PoE Access Point Next, in the “Control panel”, open the “Administrative Tools” and then open “Services”. Scroll down until you find the “SSDP Discovery Interface”. If the Status is not Started, double-click on SSDP Discovery Interface to open the service properties. Change the startup type to Automatic, then close the properties.

  • Page 95: Limited Warranty

    TRENDnet products. Products that are sent to TRENDnet for RMA service must have the RMA number marked on the outside of return packages and sent to TRENDnet prepaid, insured and packaged appropriately for safe shipment. Customers shipping from outside of the USA and Canada are responsible for return shipping fees.
  • Page 96 Download section and look for the desired TRENDnet product to access to the GPL Code or LGPL Code. These codes are distributed WITHOUT WARRANTY and are subject to the copyrights of the developers. TRENDnet does not provide technical support for these codes.
  • Page 97 User Manual TEW-455APBO High Power Wireless Outdoor PoE Access Point...
