- Page 1 Quick Installation Guide Indoor / Outdoor Antenna, Antenna Cable & Surge Arrestor...
-
Page 2: Table Of Contents
Table of Contents English ........................... 1 Outdoor Antenna Installation ................How to install the surge arrestor ................ Weatherproof tape for outdoor installations ............Indoor Antenna Installation .................. Version 10.27.2006... -
Page 3: English
1. Outdoor Antenna Installation Before installation, please ensure you have the required products and that the contents of each product are complete. TEW-ASAK Jumper Cable Surge Arrestor TEW-L406/TEW-L412 TEW-L406 – cable (6 Meter) TEW-L412 – cable (12 Meter) One of the following Antennas: TEW-AO08O TEW-AO09D TEW-AO14D... - Page 4 1. Disconnect the default dipole antenna from your indoor access point or router. 2. Attach the blue sleeve (Reverse SMA) of the jumper cable to your Wi-Fi Device. 3. Connect the black sleeve (N-Type) of the jumper cable to the surge arrestor. (Please refer to Section 2: “How to install the surge arrestor”...
- Page 5 4. Connect remaining surge arrestor connector to the blue sleeve (N-Type) of the antenna cable (TEW-L406/ TEW-L412) 5. Connect the Green wire to grounding object. e.g. 1. Earth Driven rod 2. Grounded Electrical System 3. Building frame 6. Connect the remaining black sleeve (N-Type) of the Antenna Cable to the Antenna.
-
Page 6: How To Install The Surge Arrestor
2. How to install the surge arrestor 1. Before installing the antenna, make sure the low loss outdoor cable (TEW-L406/TEW-L412) can reach the location of your access point or router. Attach the enclosed cable adapter’s blue sleeve to the Wi-Fi device (Reverse SMA) and the cable adapters black sleeve (N-type) to the surge arrestor. -
Page 7: Weatherproof Tape For Outdoor Installations
3. Weatherproof tape for outdoor installations If your surge arrestor is installed outdoors, remember to wrap both connectors tightly with the enclosed weatherproofing tape. English... -
Page 8: Indoor Antenna Installation
4. Indoor Antenna Installation Before installation, please ensure you have the required products and that the contents of each product are complete. TEW-L202/TEW-L208 TEW-L202 – cable (2 meter) TEW-L208 – cable (8 Meter) One of the following Antennas: TEW-AO08O TEW-AO09D TEW-AO10O Note: The following Indoor Antennas come with cables or connect directly to your Wi-Fi Device. - Page 9 1. Disconnect the dipole antenna from your access point or router. 2. Attach the blue sleeve (Reverse SMA) of the indoor cable (TEW-L202/ TEW-L208) directly to the Wi-Fi Device. 3. Connect the remaining black sleeve (N-Type) of the antenna cable to the blue sleeve of the (N-type) antenna.
- Page 10 TEW-AO08O, TEW-AO10O, TEW-AO09D, TEW-AO14D, TEW-AO19D- 3 Year Warranty If a product does not operate as warranted above during the applicable warranty period, TRENDnet shall, at its option and expense, repair the defective product or part, deliver to customer an equivalent product or part to replace the defective item, or refund to customer the purchase price paid for the defective product.
- Page 11 CONNECTION WITH THE SALE, INSTALLATION MAINTENANCE OR USE OF TRENDnet'S PRODUCTS. TRENDnet SHALL NOT BE LIABLE UNDER THIS WARRANTY IF ITS TESTING AND EXAMINATION DISCLOSE THAT THE ALLEGED DEFECT IN THE PRODUCT DOES NOT EXIST OR WAS CAUSED BY CUSTOMER'S OR ANY...
- Page 12 Certifications This equipment has been tested and found to comply with FCC and CE Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference. (2) This device must accept any interference received. Including interference that may cause undesired operation.
- Page 13 TRENDnet Technical Support Product Warranty Registration Please take a moment to register your product online. Go to TRENDnet’s website at http://www.trendnet.com 20675 Manhattan Place Torrance, CA 90501 Copyright ©2006. All Rights Reserved. TRENDnet.
