The HP GbE2c switch is installed in interconnect module bay 1 (IMB1) of the Workgroup System
Tower. It can be used as the system interconnect and also provides the infrastructure for the
administration and console network in Workgroup System Tower configurations.
Figure 1-3 shows an HP GbE2c Ethernet Blade Switch for c-Class BladeSystem.
Figure 1-3 HP GbE2c Ethernet Blade Switch
2
1
6
The following list describes the callouts in
1. Reset button
2. Health LED
3. UID LED
4. DB-9 serial management port
5. RJ-45 1Gb uplink ports
6. Release handle
Note:
If you do not choose the optional InfiniBand interconnect, you can use the In-Band Management
(administrative network) for MPI applications.
For user and service documentation about the HP GbE2c Ethernet Blade Switch for c-Class
BladeSystem, see Table
Table 1-1 HP GbE2c Ethernet Blade Switch for c-Class BladeSystem User and Service Documentation
Document Title
HP GbE2c Ethernet Blade Switch for
c-Class BladeSystem - overview
GbE2c Ethernet Blade Switch for HP
c-Class Quick Setup Instructions
HP GbE2c Ethernet Blade Switch for
c-Class BladeSystem Application Guide
HP GbE2c Ethernet Blade Switch for
c-Class BladeSystem Browser-based
Interface Reference Guide
HP GbE2c Ethernet Blade Switch for
c-Class BladeSystem Command Reference
Guide
HP GbE2c Ethernet Blade Switch for
c-Class BladeSystem User Guide
HP BladeSystem c7000 Enclosure
Maintenance and Service Guide
3
4
Figure
1-1.
URL
http://h18004.www1.hp.com/products/blades/components/ethernet/GbE2c/index.html
http://bizsupport.austin.hp.com/bc/docs/support/SupportManual/c00700745/c00700745.pdf
http://bizsupport.austin.hp.com/bc/docs/support/SupportManual/c00701973/c00701973.pdf
http://bizsupport.austin.hp.com/bc/docs/support/SupportManual/c00701566/c00701566.pdf
http://bizsupport.austin.hp.com/bc/docs/support/SupportManual/c00701969/c00701969.pdf
http://bizsupport.austin.hp.com/bc/docs/support/SupportManual/c00701541/c00701541.pdf
http://bizsupport.austin.hp.com/bc/docs/support/SupportManual/c00714237/c00714237.pdf
1.2 High Performance Computing – HP Cluster Platform Architecture
