Page 1: User Manual
Release date : 2011.07.14 Model : QVI-BM09-MAIN-V5.1 IF / Product code : QVI-BM-1107-004 Video Interface for BMW 3/5/6/7 Series V5.1 User Manual www.car-solutions.com support@carsolutions.com... -
Page 2: Table Of Contents
Contents 1. Before installation 1.1 Main specification 1.2 Features 1.3 System diagram 1.4 Components 1.5 Exterior 1.6 POWER cable 2. Setup 2.1 DIP switch 2.2 Setup for car model & navigation 2.3 Factory mode 2.4 Original buttons usage 2.5 Remote controller usage 2.6 Keypad usage 2.7 Setup for rear camera 2.8 OSD (on screen display) -
Page 3: Main Specification
1.1 Main specification 1. Compatibility Most of brand-new cars coming with CIC Navigation Computer System including BMW 3,5,6,7,Xseries 2. Product composition Multimedia Interface (made for specific models) * 1ea Most TV-Free (displaying original DVD and navigation) – optional 3. MULTIMEDIA INTERFACE input spec. 3 * A/V input (external video input) 1 * CVBS input (rear camera source input) 1 * Analog RGB input (navigation system output) -
Page 4: Features
1.2 Features 800 x RGB x 480 24bit wide display of high definition LED backlight device (600cd) – able to adjust brightness Stereo sound support via headphone input ZOOM Function ( 16:9 -> 4:3 ) Able to connect external video/audio device ... -
Page 5: System Diagram
1.3 System diagram Switch for source toggle Keypad OEM Button (Can Intrface) NAVIGATION Input (Analog RGB) DISPLAY Car Installation A/V 1 OEM LCD VIDEO MUX A/V 2 VIDEO CIRCUIT A/V 3 CVBS (Rear camera) Car Screen Input POWER A/V OUT (CAR MAIN BOARD) CIRCUIT HEADREST... -
Page 6: Components
1.4 Components Mode cable * 1EA LCD cable * 1EA IR cable * 1EA Remote control * 1ea A/V cable * 1EA REAR CAMERA POWER cable * 1EA Modified POWER cable (7P) * 1EA RGB cable * 1ea www.car-solutions.com... -
Page 7: Exterior
1.5 Exterior Dimension ⑩ ⑨ ⑧ ⑦ ⑥ ⑤ Horizontal length 164.4mm Vertical length 94.4mm Height 28.2mm ① POWER ② RGB(IN) ③ REAR CAMERA POWER ④ A/V(IN/OUT) ⑤ LCD-OUT ⑥ LCD-IN ⑦ IR ⑧ MODE ⑨ LED ① ② ③ ④... -
Page 8: Power Cable
1.6 POWER cable This has to be connected The original power& to the spot located at the NOISE FILTER BOX CAN cable has to be back of the monitor which connected to this the original power & CAN part. cable originally connected. Noise filter box CAN(H) -
Page 9: Dip Switch
2.1 DIP switch ※ ON : DOWN / OFF : UP Function Dip S/W Selection default : ON (DIP #8) ON : displaying RGB mode Displaying RGB input OFF : hiding RGB mode ※ DIP S/W usage example ON : displaying A/V 1 - Input Mode : A/V2, A/V3 Displaying A/V 1 OFF : hiding A/V1... -
Page 10: Setup For Car Model & Navigation
2.2 Setup for car model & navigation FACTORY mode – Press ◀ button 2 seconds long on the remote controller. Setup for car model Setup for navigation UTIL - CAR MODEL UTIL – NAVI MODEL IMAGE Selecting model of the car Definition of the navigation Adjusting the position and the size of navigation... -
Page 11: Factory Mode
2.3.1 FACTORY mode FACTORY mode – Press ◀ button 2 seconds long on the remote controller. UTIL- DMB SKIP UTIL - A/V SELECT UTIL - FACTORY RESET For domestic use only Selecting background sound while Resetting factory mode navigation is displayed on the screen ON : deactivating DMB YES : resetting factory mode OFF : activating DMB... - Page 12 2.3.2 FACTORY mode FACTORY mode – Press ◀ button 2 seconds long on the remote controller. I_DRV - I_DRV REMOTE I_DRV/ I_DRV CONTROL Selecting model of navigation and Selecting whether to use I_DRV DMB respectively to control I_DRV function or not function ON / OFF ML 740T...
-
Page 13: Original Buttons Usage
2.4 Original buttons usage I-Drive buttons Mode Operation Function (whole model) Press this button 2 seconds long Changing modes Whole MENU Getting back to Original mode Press this button short image Press this button 2 seconds long in the direction of 12 O’clock Scanning channel △... -
Page 14: Remote Controller Usage
2.5 Remote controller usage Function POWER & PIP Unavailable MENU Activating OSD menu Making a selection, changing image display Moving upward ▲ (If you press this button 2 seconds long, “Hot key” function will activate/ deactivate.) ▼ Moving downward Moving leftward ◀... -
Page 15: Keypad Usage
2.6 Keypad usage Select one between the remote controller and the keypad FACTORY MODE (Interface setting) : Press these buttons on OSD keypad in the following sequence; UP→DOWN→UP →MENU Function MENU/EXIT Activating OSD menu and Getting back to the previous state after setting mode SEL/INPUT Making a selection and hanging modes Moving leftward or upward (If you press this button 2 seconds long, you can get access... -
Page 16: Setup For Rear Camera
2.7.1 Setup for rear view camera FACTORY mode – Press ◀ button 2 seconds long on the remote controller. UTIL - REAR SELECT PARK Selecting how to detect the rear view PARK ENABLE : Selecting whether to display the parking guide line or not camera on rear gear (default : ON) LAMP : Detecting the rear view... - Page 17 2.7.2 Setup for rear view camera Positioning transparent PDC image Setup for displaying rear view Press button on the steering wheel and select a series5 : Press button on the steering position of PDC image among 3 options as shown wheel and select one from 4 options as below.
-
Page 18: Osd (On Screen Display)
2.8.1 OSD (on screen display) Analog RGB Mode IMAGE COLOR UTIL BRIGHTNESS RED : Adjusting red LANGUAGE : Choosing FACTORY RESET : Resetting interface language while all the data about the CONTRAST GREEN : Adjusting green changing mode between relevant mode A/V and DVD (applicable to navigation, SHARPNESS... - Page 19 2.8.2 OSD (on screen display) Video mode DMB mode (only for domestic use) IMAGE UTIL BRIGHTNESS LANGUAGE : Choosing interface FACTORY RESET : Resetting all the CONTRAST language while changing mode data about the relevant mode SHARPNESS between A/V and DVD (applicable to navigation, A/V, DMB, USER IMAGE : Selecting one among 4 TRANS : Adjusting transparency of...
-
Page 20: Installation Diagram
3.1 Installation diagram Connecting this to the spot which the original POWER & CAN cable was connected. Original Monitor Connecting the original POWER & CAN cable to this part. Original LCD cable Offered LCD cable Control box Noise filter box www.car-solutions.com www.car-solutions.com... -
Page 21: Cautions On Installation
3.2 Cautions on installation Ignition key should be taken off before starting installation, interface power connection must be the last step in installation. Power cable should be separated when connecting interface. Should be no any electronic devices or magnetic pole around installation place. ... -
Page 22: Installation
3.3 Installation 3.3.1 Connecting the monitor with the interface ① Connect LCD cable enclosed in our package to the spot that the original one is connected after disconnecting the original LCD cable from the monitor as shown left. ② Connect the original LCD cable to “LCD-IN” socket of the interface. www.car-solutions.com... - Page 23 3.3 Installation 3.3.3 Connecting CAN cable respectively CAN-High POWER CABLE CAN-Low Connect CAN-H cable (green+brown) enclosed in our package with the original CAN-H cable (green+orange). And connect CAN-L cable (green) enclosed in our package with the original CAN-L cable (green). www.car-solutions.com...
-
Page 24: Troubleshooting
4. Troubleshooting Q. I can not switch A/V sources A. Check IR or Ground cable connection. Check LED lamps in the interface, if it is not on, check power cable. Q. All I got on the screen is black. A. Check second LED lamp of the interface is on, if not, check A/V sources connected are working well. (Second lamp indicates AV sources connected works well.) Check interface connection has been done well.
