Summary of Contents for Car Solutions QPI_BM16
- Page 2 •Specification Car Compatibility : 2017 BMW CAR with Evo2 I-Drive5 1,2,3,4,5,6,7 Series, Mini, X3, X4, X5 8.8”, 10.2” ※ Monitors with/without OEM touch are supported Components : Interface* 1ea Multimedia interface Input/output spec Input : Analog RGB*1, A/V*3, CVBS(Rear camera)*1 CVBS(Front camera)*1 Output : To LCD*1 Power spec...
- Page 3 •Product Exterior •Components A/V * 1ea RGB * 1ea POWER * 1ea LCD* 1ea (HAVCAB0002) (HPOWER0096) (HLCDCA0019) (HRGBCA0013) MT option * 1ea IR OUT * 1ea Remote * 1ea REAR * 1ea BUTTON * 1ea IR * 1ea (HARETC0233) (REMOTE0001) (HARETC0002) (HIRCAB0007) (HARETC0001)
- Page 4 •DIP SWITCH ※ ON : DOWN / OFF : UP Function Dip S/W OFF : RGB mode display RGB mode ON : RGB mode OFF : AV1 mode display AV1 mode ON : AV1 mode skip OFF : AV2 mode display AV2 mode ON : AV2 mode skip 4-OFF, 5-OFF : 1440*540...
- Page 5 •Factory setting Adjust a current screen position and size. Menu of FACTORY IMAGE H-POSITION H-POSITION : Move display horizontally PARK V-POSITION UTIL1 H-SIZE(NAVI) V-POSITION : Move display vertically UTIL2 H-SIZE(NAVI) : Adjust the image of navigation INFO horizontally MENU to Return SEL to Select/Save Menu of FACTORY Adjust rear view camera setting.
-
Page 6: System Version Information
•Factory setting Navigation & Car model setting up Menu of FACTORY CAR MODEL IMAGE NAVI MODEL : Choose RGB navigation AVOUT SELECT PARK FCAM FUNC AVOUT SELECT : Selecting background sound UTIL1 AV3 SKIP UTIL2 via car AUX FACTORY RESET INFO FCAM FUNC : MENU to Return... - Page 7 •OEM button ※ Able to switch the mode or activate the function by OEM button <I-Drive> <Steering wheel> <Memory Button> Section Button Operation Function Short press Mode switch VOICE Short press PIP mode choice Steering Wheel Wheel up Short press Multimedia Channel UP Wheel Down Short press...
- Page 8 •A/V mode PIP Able to display OEM&AV image together in A/V mode - Setting : Push I-Drive south for a long time to activate PIP mode ※ Image order : Full AV mode → PIP image<1> → PIP image<2> Display Full AV mode Full AV mode Display AV&OEM mode together AV image is bigger than OEM...
- Page 9 •Installation Diagram IR cable Mode cable NAVIGATION In case of Rear lamp connection...
- Page 10 •CAN/Power cable ※Two ways to connect CAN/POWER cable 1. In case of connecting the cable from I-Drive, TV free is not supported(Dip switch #8-Off) 2. In case of connecting the cable from the Headunit TV free is supported(Dip switch #8-On) •I-Drive OEM cable Detach OEM cable from I-Drive and...
- Page 11 •Q-ROI RGB&Uart Touch ※Connect IR-NAVI wire from RGB-In cable of QPI-BM16-7S to Uart wire from RGB-Out of Q-ROI RGB The first pin from the right of RGB Out is Uart wire Old IR-NAVI label for New IR-NAVI label for QPI-BM16-7S QPI-BM16-7S...
- Page 12 •Q-ROI2& Uart Touch ※Connect IR-NAVI wire from RGB-In cable of QPI-BM16-7S to Red wire of Uart-touch cable from QROI2 multi cable There are three wires for Uart-touch cable from QROI2 multi cable. Old IR-NAVI label for New IR-NAVI label for QPI-BM16-7S QPI-BM16-7S...
- Page 13 •LVDS IN/OUT Connection ※ Remove OEM LCD cable from the monitor behind and connect it to LVDS IN of the interface. The supplied LCD cable shall be connected between the monitor behind and LVDS OUT of the interface. Supplied LCD cable OEM LCD cable...
