Summary of Contents for DeDietrich G30
- Page 1 Le guide d’utilisation de votre table de cuisson Hob operating guide 4 feux gaz 4 gas ring 3 feux gaz + 1 foyer électrique 3 gas ring + 1 electric hotplate hob...
-
Page 2: Table Of Contents
List of contents Using your hob in complete safety What your hob looks like? Installing your hob in all simplicity Fitting recommendations 27-29 Electrical connections Gas connections 31-32 Changing the type of gas supply 33-37 Using your hob in all simplicity How to use your gas burners? Which pans are best adapted for use on the gas burner? - Page 3 Editorial Dear Customer, Thank you for buying a DE DIETRICH hob. Our research teams have designed a new generation of kitchen appliances. As a result of our unique expertise, we have produced a range of goods whose quality, design and technical advance are unsurpassed.
-
Page 4: Using Your Hob In Complete Safety
our hob in complete safety sing your hob in complete safety - We have designed your hob for private efficient ventilation by increasing the domestic use. power of the existing mechanical ventilation. With view constant improvement of our products, we reserve - Disconnect your hob from both electrical the right to make any changes in their and gas supplies before carrying out any... -
Page 5: What Your Hob Looks Like
hat your hob looks like? 4 gas ring hob Semi-fast Fast burner burner Right back burner switch Left back burner switch Front left burner switch Front right burner switch Double-crown Auxiliary burner burner Semi-fast Fast burner burner Right back burner switch Left back burner switch Front left burner switch Front right burner switch... -
Page 6: Installing Your Hob In All Simplicity
Installing your hob in all simplicity itting recommendations Depth Height Width Model Cut-out Depending on cupboard 56 cm 49 cm Outside 52 cm 5,6 cm 60 cm dimensions above the work surface Outside dimensions under 55 cm 47,5 cm 3,4 cm work surface This appliance should be installed by a qualified technician / installer. - Page 7 Installing your hob in all simplicity itting recommendations (cont'd) The hob must be built into the work- top of a support cupboard. This work- top must be at least 3 cm thick and heat-resistant or else coated with a heat resistant material. A side-clearance of at least 30 cm should be left to the right and left of the hob.
-
Page 8: Fitting Recommendations
Installing your hob in all simplicity itting recommendations (cont'd) - Place the hob in position in the worktop cut-out taking care to centre it as well as Mounting pad F RONT possible. - replace the burner heads, the burner caps and the pan stands. - Connect the hob power cable to your kitchen electricity supply (See "Elec- trical Connections"). -
Page 9: Electrical Connections
Installing your hob in all simplicity lectrical connections Mixed and all-gas hobs ROSS SECTION OF THE CABLE TO USE Hobs are delivered with a three-conduc- 220-240 V~ - 50 Hz tor (phase + ground + neutral) H05V2V2F - T90, 1mm section cable, All-gas and ref. -
Page 10: Gas Connections
Installing your hob in all simplicity as connections Preliminary remarks If the hob is to be installed above an oven If a flexible hose is used (in the case of or if other nearby heating appliances risk butane gas) then it must not be installed heating and damaging the gas hose then it in a place where it may be in contact with is essential that a rigid pipe be installed... -
Page 11: Gas Connections
Installing your hob in all simplicity as connections (Cont'd) BOTTLED TANKED BUTANE/PROPANE (BUTANE/PROPANE). Pressure regulator compulsory For the user's safety, we advise the connection to be made with a rigid pi- pe if this is possible, or with a reinfor- ced, braided, flexible gas hose (maxi- mum length 2 metres) (fig. -
Page 12: Changing The Type Of Gas Supply
Installing your hob in all simplicity hanging the type of gas supply Preliminary remarks Your hob is delivered regulated You can obtain an adapter sachet from your After-sales Service. for natural gas. Every time you change your gas The injectors for adapting the hob for use supply, mark the square on the label with butane or propane are in the wallet in the wallet that corresponds to the... - Page 13 Installing your hob in all simplicity hanging the type of gas supply (cont'd) When carrying out this operation, you should successively : Adapt the gas connection Change the injectors Adjust the retarder on the taps Grill to the new DAPT THE HOB CONNECTION gas adjustment.
- Page 14 Installing your hob in all simplicity hanging the type of gas supply (cont'd) loca- DJUST THE RETARDER ON THE TAPS ted under the knobs. Proceed as follows: • Work on one tap at a time. • Pull off all knobs and sealing rings. Knob CHANGING FROM NATURAL GAS TO BUTANE/PROPANE GAS .
- Page 15 Installing your hob in all simplicity hanging the type of gas supply (cont'd) Gaz rating FR-GB FR-GB FR-GB-ES ES-PT ES-PT Appliance designed for installation: Butane Propane Natural Natural Air-propane FR ......cat : III1C2E+3+ Air-butane ES-GB-PT....cat : II2H3+ G130 Hourly input -see below: 28-30mbar 37mbar 20 mbar 25 mbar 8 mbar...
- Page 16 Installing your hob in all simplicity hanging the type of gas supply (cont'd) Gaz rating (cond’t) MARK ON THE INJECTORS This table shows the position of the injec- Injector mark here tors on your hob depending on the type of gas you use.
-
Page 17: Using Your Hob In All Simplicity
Using your hob in all simplicity ow to use your gas burners? Lighting a hob • Each burner has its own gas tap which is opened by pressing down on the control knob and then turning it anti-clockwise. The gas tap is closed when in the “¡” position. •... - Page 18 Using your hob in all simplicity hich pans are best adapted for use on the gas burner ? • Recommended pan sizes: Extra burner Extra burner Medium burner Small burner double-crown Extra fast fast Semi-fast auxiliary burner 20 to 30 cm 18 to 28 cm 16 to 22 cm 12 to 20 cm...
-
Page 19: Which Pans Are Best Adapted For Use On The Electric Hotplate
Using your hob in all simplicity ow to use the electric hotplate • To heat it up Turn the knob to the point that corres- ponds to the cooking you want to do (See cooking table at the end of the instruction booklet). -
Page 20: How To Look After Your Hob
How to look after your hob? Keeping your hob in good condition is easy if you clean it before it is completely cold. Even so, never clean it when it is in use. Put all the electric and gas control knobs at zero. -
Page 21: Minor Troubleshooting
Minor troubleshooting You have doubts about whether your hob is working correctly ..this does not necessarily mean there is a breakdown. Nevertheless, check the following points : IF YOU REALIZE THAT WHAT SHOULD YOU DO? Lighting the burners: - Check the electrical connections on the hob. -
Page 22: Gas-Cooking Guide
Gas-cooking guide EXTRA- GRA ND SEMI- SEMI- DOUBLE- DOUBLE AUXILIARY DISHES TIME FAST PREPA RA TIONS TEMPS RA PIDE A UXILIA IRE RA PIDE FAST RA PIDE COURONNE FAST CROWN Bouillons 8-10 minutes Broths SOUPES SOUPS Thick soups Potages épais Court Bouillon 8-10 minutes Court-bouillon... - Page 23 BRANDT GROUP UK Ldt Intec 4 - Wade Road BASINGSTOKE RG24 8NE Tel. : 01 256 308 000 Fax : 01 256 325 888 Website : <www.dedietrich.co.uk> Réf. appareils :, Appliance ref : DTE310*/* - DTE312*/* - DTE313*/* - DTE316*/* - DTE317*/*...
