6.1 WaveBrowser Overview and Controls

Button Panel
The Main program window consists of the following areas:
The Main Viewing Area: The large blue area.
The Button Panel: The left side of the window.
The Drop Down Volume List: Allows the selection of available Disk volumes.
The Main Viewing Area
Pictures are displayed in this area in Multi-Camera, and Single-Camera formats. Picture display order
is according to the information encoded by the unit used to create the original video data file.
Choose from the following displays:
4-way Display
Single Camera Display Large
Single Camera Display Medium
Single Camera Display Small
0150-0229D 62
Main Viewing
Area
Drop Down
Volume List
