Changing Position And Color Of Title And Status Indicators
Camera Titles: To change the color and position of the camera
titles, select a camera for full screen display, then press the Enter
button to advance to the next display setting. Repeatedly pressing
the Enter button advances the display settings through the
sequence show in the table on the right.
Example: Select Camera 1 for full screen display. Using the
Enter button, cycle through the sequence shown on the right.
Each time the position cycle is completed, the unit advances the
Status Indicator color. Choose Black, White or Gray.
Status Indicators
Status indicators are displayed on the upper right hand corner of the screen.
Status indicators include:
Time and Date (these can be turned off in the menu system, see section 3.8). The Time and
Date format can also be changed in the menu system.
Time remaining on Hard Disk(s).
Conditional Indicators
Condition
Alarm
Autolist™ Program
mode
Freeze
Macro Record mode
Motion Detection
Videoloss
Zoom
Status Display Box
A Status Display Box can be viewed by pressing the Camera Number button twice. Status Indicators
include:
On Live Fullscreen:
Archive Status: Not Connected, Not Ready, Ready, Ejecting, Play, and timeleft. Timeleft
indicates the amount of time before the archive medium is full (Only available if the unit has
Background Archiving turned On).
Network: Displays all current Network connections. Normal connection is displayed as ip.ip or ---
if there is no connection. Live connections are displayed as E1: ip.ip, E2: ip.ip, etc. (where ip.ip
represents the last 2 bytes of the IP Address). POTS connection is displayed as IP 1.1.
On Playback Fullscreen:
All the above, including Image Quality Setting: High, Medium, Standard.
0150-0229D
Full Screen Indicator
ALM
PGM
FRZ
F followed by macro number
M
VDL
ZOOM
24
Position
Top Left
Top Left
Top Left
Bottom Left
Bottom Left
Bottom Left
Title not displayed
Multiscreen Indicator
A in cameo of camera in alarm
PGM
(Asterisk) in frozen cameo
*
F followed by macro number
M in cameo w/ motion detection
V in cameo with videoloss
ZOOM
Kalatel DVMRe StoreSafe
Color
Black
White
Gray
Black
White
Gray
