Step 2
Install
Freezer
Water Line
• A cold water supply is required for automatic
icemaker operation. The water pressure must be
between 20 and 120 p.s.i.
• Route 1/4" OD copper or GE SmartConnect
between house cold water line and the water
connection location.
• Tubing should be long enough to extend to the front
of the freezer. Allow enough to accommodate bend
leading into the water valve.
NOTE: The only GE approved plastic tubing is supplied
™
in the GE SmartConnect Refrigerator Tubing Kits.
Do not use any other plastic water supply line because
the line is under pressure at all times. Other types of
plastic may crack or rupture with age and cause water
damage to your home.
™
GE SmartConnect Refrigerator Tubing Kits are
available in the following lengths:
2' (0.6 m) WX08X10002
6' (1.8 m) WX08X10006
15' (4.6 m) WX08X10015
25' (7.6 m) WX08X10025
Shut off the main water supply
Turn on the nearest faucet long enough to clear the line
of water.
Install a shut-off valve between the icemaker water
valve and cold water pipe in a basement or cabinet.
The shut-off valve should be located where it will be
easily accessible.
NOTE: Saddle type shut-off valves are included in many
water supply kits. Before purchasing, make sure a saddle
type valve complies with your local plumbing codes.
• Install optional water filter in the water line near the
freezer. A water filter is recommended in areas where
water supply contains sand or particles. Installation
instructions are packed with the filter.
Installation
36" Stainless Steel Refrigerators, Freezers
™
tubing
NOTE: Commonwealth of Massachusetts Plumbing
Codes 248CMR shall be adhered to. Saddle valves are
illegal and use is not permitted in Massachusetts.
Consult with your licensed plumber.
Floor
Tubing
9
