• Select "Show Details." The unit does not calculate the
route, but will simply display the address using the
map browser mode. From here you can select this
address as your destination or move around the
map to find another destination.

Next instruction

The information that you need for the next turn—the
direction and distance to the turn—is displayed clearly in
this view. You must select a destination before you can
use this view. Refer to the "Setting Your Destination"
section on page 21 to calculate a route.
Direction of
next turn
GPS strength
indicator
The street you are traveling on
1. From the main menu, select "Map."
2. Press until you see the screen above.
3. You can cancel your current route at any time.
To return to the main menu, press
"Route Information" followed by "Cancel Route."

Next four instructions

The next four turns are described by the direction of the
turn, the next street name, and the distance to the turn.
The next turn is highlighted, and is always at the top of
the list. The current street name is displayed at the
bottom of the screen. As with the next instruction
screen, you must select a destination before you can
use this screen.
Next street name
Direction of
next turn
GPS strength
indicator
The street you are traveling on
Back-On-Track is a trademark of NAVMAN Mobile Limited.
27
Next instruction
Distance to next turn
Additional information can
be displayed here. Press the
left/right function of the
toggle button to scroll
through the options:
• Current speed
• Current time
• Current bearing/heading
(HDG)
• Distance to next turn
• Distance to go to destina-
tion (DTG)
• Expected time of arrival at
destination (ETA)
• Time to go to destination
(TTG)
and select
Distance to turn
Additional information can
be displayed here. Press the
left/right function of the
toggle button to scroll
through the options:
• Current speed
• Current time
• Current bearing/heading
(HDG)
• Distance to next turn
• Distance to go to destina-
tion (DTG)
• Expected time of arrival at
destination (ETA)
• Time to go to destination
(TTG)
1. From the main menu, select "Map."
2. Press until you see the next four instructions screen.
3. You can cancel your current route at any time.
To return to the main menu, press
"Route Information" followed by "Cancel Route."
Back-On-Track™ feature
Delphi Mobile Navigation is designed to replan your route
automatically if you take a wrong turn or are detoured.
When Delphi Mobile Navigation is recalculating a route,
"Back-On-Track" will appear on the lower bar of the map
screens.

Automatic restart feature

1. If you shut off the power after a route has been
calculated, the unit will automatically return to your
chosen map screen when you restart. The route will be
recalculated from your current position.
2. If you shut off the power while you are in the process
of changing settings, the changes you have made will
be lost.
3. If you shut off the power while entering a destination
address (before the unit has calculated the route), the
information will be lost.
4. If you do not wish to use the programmed route after
you restart the unit, press
menu. Select "Route Information" followed by "Cancel
Route."
5. Do not remove an MMC or SD memory card while
navigating or the unit may reset. Remove memory
cards only when no route is set.

Route information

Delphi Mobile Navigation allows you to view information
pertaining to your route before actually entering instruc-
tions mode. This option functions only when a route is
programmed.

Show route

Selecting "Show Route" displays the entire route on the
map browser screen at a zoom level that best displays
the entire route. If the entire route is larger than the
maximum zoom level, then the middle section of the
route will be displayed at maximum level.
and select
to return to the main
